CHARGING VOLTAGE LIMITS
BATTERY TYPE
Wet Lead Acid/GEL
AGM
Calcium
RECOMMENDED FUSES
Vehicle Starter Battery – 50A Fuse
Auxiliary Battery – 50A Fuse
Solar – 50A Fuse
Ignition Wire – 2A Fuse
Note – Fit the fuse as close as possible to the item it is protecting!
CABLE IDENTIFICATIONS
MULTI-CHEMISTRY BATTERY
SELECTION
WHITE = Calcium
YELLOW = Wet, Lead Acid/GEL
ORANGE = AGM
BLACK with Ring Terminal = Aux Battery
Temperature Sensor
CHARGING VOLTAGE AT
25°C
14.2 V
14.6 V
15.3 V
BLUE = Ignition Wire
BROWN = OUTPUT to Aux Battery
BLACK = Common Ground
RED = Vehicle INPUT
GREEN = Solar INPUT (25A DC-DC/MPPT
model)
FLOAT VOLTAGE AT
25°C
13.3 V
13.3 V
13.3 V
POWER CABLES
5
