TECHNICAL DATA
Max. Charging Current
Solar Input Voltage Range (25A DC-DC/MPPT model)
Min. Input start-up Voltage - Solar (25A DC-DC/MPPT model)
Ideal 12V Nominal Solar Panel Size (25A DC-DC/MPPT model) Voc
<25V
Vehicle Input Voltage Range
Min. Input start-up Voltage - Vehicle
Vehicle Input Voltage Range (Ign wire NOT fitted)
Min. Input start-up Voltage - Vehicle (Ign Wire NOT fitted)
Min. Aux Battery Voltage
Idle Current Draw
Operation Temperature - Aux Battery
Dimensions
Weight
Temperature Compensation
LEDS & FAULTS INDICATIONS
"BATTERY", "CAR" & "SOLAR" (25A DC-DC/MPPT model only)
LED = Green = Terminals connected correctly
LED = Red = Terminals REVERSE connected (Check connections)
"CALCIUM", "AGM", & "LEAD ACID"
LED = Green = indicates Battery Selection wire connected
25A DC-DC/MPPT model shown
20A / 25A
9 - 25V
14.5V
360W
11.9 - 25V
12.2V
12.8 - 25V
13.8V
5V
20-30mA
-10 °C - 50 °C
142mm x 125.6mm
x 33.5mm
~750g
Yes
3
