Adventure Kings AKEP-DC20A_01 User Manual page 4

"STATUS" LED CHARGING INFORMATION
1 Green flash
2 Green flash
3 Green flash
4 Green flash
5 Green flash
Solid Green
"STATUS" LED FAULT CODES INFORMATION
1 Red flash
2 Red flash
3 Red flash
4 Red flash
Solid Red
1 Green/1 Red
flash
1 Green/2 Red
flash
1 Green/3 Red
flash
1 Green/4 Red
flash
Charger Idle
Charger testing mode
Bulk charging
Absorption stage
Float Stage
Charging Complete
Aux Battery Temperature error
Aux Battery outside Operational
Temp range: -10oC - 50oC
Bulk & Absorption Charging
stages timed out (>10hrs)
Battery under Voltage
Internal System Fault
Charger over Temperature
Aux Battery over Voltage
Aux Battery low Voltage warning
Charging Input over Voltage
Normal - no action required
Normal - no action required
Normal - no action required
Normal - no action required
Normal - no action required
Normal - no action required
Temperature sensor may be damaged
Charging will recommence after
Aux Battery returns to operational
temperature
Aux Battery may be old or high output
load attached
Aux Battery voltage is too low to
charge
Internal electronics damaged - unit
inoperable
Self-protection shutdown, will re-start
when cooled
Charging stopped to prevent damage
to Aux Battery
Aux Battery Voltage at ~50%.
Recharge ASAP to prevent damaging
the Aux Battery
Charging stopped to prevent damage
to Aux Battery
4
