SINGLE DISHDRAWER
TM
DISHWASHER
DD24SI, DD24STI & DD24SHTI models
INSTALLATION GUIDE
US CA
591386 A
08.17

Advertisement

Table of Contents
loading

Related Manuals for Fisher & Paykel SINGLE DISHDRAWER DD24SI

Summary of Contents for Fisher & Paykel SINGLE DISHDRAWER DD24SI

  • Page 1 SINGLE DISHDRAWER DISHWASHER DD24SI, DD24STI & DD24SHTI models INSTALLATION GUIDE US CA 591386 A 08.17...

  • Page 2: Grounding Instructions

    SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Electrical Shock Hazard Before installing the dishwasher, remove the house fuse or open the circuit Installation of this dishwasher requires basic mechanical and electrical skills. ● breaker. If permanently connecting the dishwasher, be sure the power is Be sure to leave these Instructions with the Customer.

  • Page 3: Parts Supplied

    PARTS SUPPLIED Drain hose Drain hose Wire clip (1) Clamp (1) Side mounting support (1) joiner (1) (for securing (for securing bracket kit mounting Drain hose joiner) Drain hose joiner) (A and B) (2) brackets (2) OPTIONAL OPTIONAL Phillips 38 mm Rubber washer Moisture protection Cavity Bracket Kit (1)
  • Page 4 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION REMOVE THE DRAWER REMOVE THE ACCESS COVER & REMOVE POWER To prevent kinked hoses Either sit the drawer down on the left hand side (recommended) or rotate the drawer clockwise, resting it on its side after removal.
  • Page 5 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION TERMINATE MAINS WIRING AS SHOWN AND REPLACE MODULE AND COVERS Fit a suitable cable clamp for the conduit through the metal knockout. Ensure wiring is routed through or under under housing ribs. Screw down the Live, Neutral and Earth wires correctly.

  • Page 6: Product Dimensions

    PRODUCT DIMENSIONS FRONT PROFILE STANDARD TALL HEIGHT HEIGHT MODELS MODELS DD24STI DD24SI DD24SHTI PRODUCT DIMENSIONS INCHES (MM) INCHES (MM) Overall height of product 16 1/8” (410) min. 17 7/8” (454) Overall width of product 23 9/16” (599) 23 9/16” (599) Overall depth of product 22 1/2”...

  • Page 7: Cabinetry Dimensions

    CABINETRY DIMENSIONS Bracket slots PLAN STANDARD TALL HEIGHT HEIGHT MODELS MODELS DD24STI PROFILE DD24SI DD24SHTI CABINETRY DIMENSIONS INCHES (MM) INCHES (MM) Custom Filler Panel Inside height of cavity min. 16 1/4” (412) min. 18” (456) Inside width of cavity 23 5/8” (600) 23 5/8”...
  • Page 8 CUSTOM DRAWER PANEL SPECIFICATIONS FRONT PANEL MATERIAL SPECIFICATIONS 1/16” (2mm) 5/8 - 13/16” (16 - 20mm) panel thickness ● Note: when the top of the dishwasher Adequately sealed to withstand moisture (122 F/50 C @ 80% RH) ● has to be lower than the adjacent Because of it being a hot and wet environment generally, the back and sides of the cabinetry, the top of the panel can panel should be completely sealed with a waterproof vapour barrier (ie polyurethane)

  • Page 9: Cavity Preparation

    CAVITY PREPARATION IMPORTANT! The power outlet must be located in a COUNTERTOP cabinet adjacent to the dishwasher cavity. 110-120 VAC max. 15 A Moisture 3/8” protection (10mm) tape must be applied. Water Connection Recommended HOT These marks indicate (Maximum 140°F/60°C). formed bracket screw locations, if Supplied hose to suit...
  • Page 10 PREPARATION FOR EXTERNAL VENTING THROUGH SAME CABINET External Venting Kit Shelf cutouts max. 3⁄16” (5mm) VENT HOSE ø max. 1 1⁄2” ø 2 3⁄8” Services can be located ø 2 3⁄8” (38mm) (60mm) either side of dishwasher (60mm) IMPORTANT! To prevent pooling of condensation from the DRAIN HOSE + 8 11⁄16”...
  • Page 11 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE LEFT HAND SIDE RIGHT HAND SIDE Drain hose - 70 1/2” (1800mm) Drain hose - 78 1/2” (2000mm) Inlet hose - 49” (1250mm) Inlet hose - 64 3/4” (1650mm) Power cord (excl.plug) - 29 1/2” (750mm) Power cord (excl.plug) - 27 1/2”...
  • Page 12 NOW CHOOSE WHICH INSTALLATION METHOD (A) OR (B) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (A) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS ATTACH VENTING HOSE Clip all four side mounting brackets into their slots using a flat-bladed screwdriver.
  • Page 13 PULL THROUGH HOSES & MOVE INTO THE CAVITY SECURE TO THE CABINETRY ON THE SIDES Open the drawer halfway. Using a flat bladed Replace the gray screwdriver, rubber plug back into prise the gray the trim moulding rubber plug out and ensure the trim of the trim seal is facing forward.
  • Page 14 ALTERNATIVE METHOD (B) - SECURE BY DRAWER REMOVAL ATTACH VENTING HOSE PULL THROUGH HOSES & MOVE INTO THE CAVITY Check that the fitted elbow is rotated left or right (depending on the direction of the routing), then ensure the venting hose is securely attached to it.
  • Page 15 REMOVE THE DRAWER SECURE TO THE CABINETRY ON THE SIDES To prevent kinked hoses The product has three Either sit the drawer down on the left pairs of fixing points: hand side (recommended) or rotate the drawer clockwise, resting it on its side after removal.
  • Page 16 REFIT THE DRAWER ONTO THE RUNNERS Lift or rotate counter-clockwise the drawer back onto the drawer runners on either side. Before refitting the drawer, ensure the hoses are not twisted and the latches at the rear of Pull the release tabs forward on both each drawer runner are sides 4”...
  • Page 17 INSTALLING A CUSTOM FRONT DRAWER PANEL REMOVE PANEL BRACKET FROM PRODUCT REMOVE THE KNOCK-TO-PAUSE MODULE WARNING! Electrical Shock Hazard Before continuing, ensure that the product is Knock-to-Pause module disconnected from the power supply. Failure to follow this warning may result in electrical shock, injury or fire.
  • Page 18 INSTALLING CUSTOM FRONT DRAWER PANELS ATTACH KNOCK-TO-PAUSE MODULE ATTACH CUSTOM PANELS TO PANEL BRACKETS TO CUSTOM PANEL There must be at least 3 screws used each side. Align bottom of each custom panel with the bottom of each 16mm (x3) bracket.
  • Page 19 INSTALLING CUSTOM FRONT DRAWER PANELS CONNECT THE KNOCK-TO-PAUSE MODULE RECONNECT THE GROUND WIRE TO THE TO THE CONTROLLER PANEL BRACKET WARNING! Electrical Shock Hazard To earth the panel bracket, connect the earth wire from the product to one of the tabs. Any custom metal component (e.g.
  • Page 20 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. DRAINAGE OPTION 1 Dishwasher and Ø 1 1/2” (38 mm) Standpipe Screw Drain hose support to back wall at correct height If space is limited for fixing, push hose through drain hose support to required height...
  • Page 21 DRAINAGE OPTION 2 Dishwasher using Air Break with Drain Hose Joiner Secure drain hose to drain hose joiner and secure to Air Break 37 3/8” (950mm) Max. height to top of Air Break step 19 (countertop or wall mounted) min. R 8” (200mm) IMPORTANT! Ensure that drain...
  • Page 22 DRAINAGE OPTION 3 Dishwasher using drain hose joiner onto sink trap/waste tee Screw Drain hose support to back wall at correct height Supplied drain hose joiner to suit Ø 3/4” (19 mm) If space is limited waste tee for fixing, push hose through drain hose support to required height...
  • Page 23 CONNECT INLET HOSE TO HOT WATER SWITCH PRODUCT ON No leaks! Ensure the supplied Tighten coupling rubber washer is fitted inside the with spanner. coupling.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Excessive water remaining above the filter plate, after the rinse cycle. (This is displayed as an A3 fault. See user guide ‘How to attend to a fault’) ● Check for a kinked drain hose, blocked or incorrectly drilled out waste connection, highloop not properly installed, drain hose not routed correctly or spray arm not in place. No water supply.

  • Page 25: Final Checklist

    FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Turn on the power and water supplies, then open the drawer. You should hear a Check all parts are installed. beep and see a program indicator light up on the control panel. Ensure that all panels and parts thereof are secure and final electrical tests have been Check the spray arms are in place, mounted correctly and free to rotate, by conducted in accordance with local electrical regulations.
  • Page 27 CONTROLS AND INDICATORS QUICK START GUIDE Control Panel DISHDRAWER DISHWASHER NZ AU US CA GB IE Keep this document handy for easy reference. For detailed information on the features of your dishwasher, see your ‘User guide’. ● Before using your dishwasher, make sure you read the full ‘User guide’, with special attention to the ‘Safety and warnings’ section. ●...

  • Page 28: Preference Options

    DURING AND AFTER THE WASH PREFERENCE OPTIONS You can change the setting of these options to suit your preferences or circumstances. We recommend selecting the most suitable During the wash the button on the dishwasher door will be illuminated. At the end of the wash the dishwasher will beep six times and the button will stop being illuminated. settings before you start using your dishwasher.

  • Page 29: Specifications

    SPEC SHEET › DD24SI9_N › Single DishDrawer™ Dishwasher, 7 Place Settings, Panel Ready Date: 16.05.2019 › 1 Dimensions Specifications Accessories Depth 22 1/2" • Height 16 1/8" Cutlery basket Width 23 9/16" • Knife clip & Multipurpose clip 513545 D3 front mount Features &...
  • Page 30 SPEC SHEET › DD24SI9_N › Single DishDrawer™ Dishwasher, 7 Place Settings, Panel Ready Date: 16.05.2019 › 2 Features Wash programs • • Fan assisted drying Delicate • • Flow through detergent dispenser • • Quiet operation Extra Dry • • SmartDrive™...
