INSTALLATION INSTRUCTIONS
DishDrawer
dishwasher
TM
DD24S 7 & DD24ST 7 models
US CA
590204C
03.12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DD24SCB7 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel DD24SCB7

Summary of Contents for Fisher & Paykel DD24SCB7

  • Page 1 INSTALLATION INSTRUCTIONS DishDrawer dishwasher DD24S 7 & DD24ST 7 models US CA 590204C 03.12...
  • Page 2 Integrated Designer Integrated DD24SCX7 DD24SCTX7 DD24SDFX7 DD24SI7 DD24STI7 DD24SCW7 DD24SCHTX7 DD24SDFTX7 DD24SHTI7 DD24SCB7 DD24SCTW7 DD24SCTB7 PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED + PARTS SUPPLIED PARTS SUPPLIED + EXTERNAL VENTING KIT EXTERNAL VENTING KIT PRODUCT & CABINETRY PRODUCT & CABINETRY PRODUCT &...

  • Page 3: Important Safety Instructions

    SAFETY AND WARNINGS - ALL MODELS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Installation of this dishwasher requires basic mechanical and electrical skills. Electrical hazard Be sure to leave these Instructions with the Customer. Installation must comply with your local building, electricity, and plumbing regulations. Before installing the dishwasher, remove the house fuse or open the circuit breaker.
  • Page 4 PARTS SUPPLIED - ALL MODELS Side mounting Wire clip (1) Clamp (1) Rubber Drain hose Drain hose Phillips 1½ ” (38 mm) Moisture protection bracket kit washer for support (1) joiner (1) 5⁄8” (16 mm) bottom fixing tape (1) (for securing (for securing (A and B) (2) inlet hose (1)
  • Page 5 ADDITIONAL PARTS SUPPLIED WITH INTEGRATED MODELS External Venting kit (1) Panel bracket (1) Panel mounting (attached to product) screws (6)

  • Page 6: Product Dimensions

    PRODUCT DIMENSIONS Plan Side Product dimensions inches (mm) STANDARD HEIGHT MODELS TALL HEIGHT MODELS overall height of product 16 1⁄8”( 16 1⁄8”( 16 1⁄8”( 17 7⁄8”( 18 13⁄16”( 17 7⁄8”( 18 13⁄16”( (incl. front panel height) overall width of product 23 9⁄16”( 23 9⁄16”( 23 9⁄16”(...

  • Page 7: Cabinetry Dimensions

    CABINETRY DIMENSIONS Plan Side Cabinetry dimensions inches (mm) STANDARD HEIGHT MODELS TALL HEIGHT MODELS inside height of cavity min. 16 ¼ ”( min. 16 ¼ ”( ) min. 16 ¼ ”( 18”( 18 7⁄8”( 18”( 18 7⁄8”( inside width of cavity 23 5⁄8”( 23 5⁄8”( 23 5⁄8”(...
  • Page 8 INTEGRATED MODELS ONLY - CUSTOM FRONT PANEL CALCULATIONS min. 1⁄16”(2mm) FRONT PANEL SPECIFICATIONS 5⁄8 - 13⁄16” (16-20 mm) panel thickness Adequately sealed to withstand moisture (122 F/ 50 C @ 80% RH) Maximum weight of panel: 20 lb (9 kg) The following calculations assume the top of the panel is aligned with the top of the adjacent cabinetry: min.
  • Page 9 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION REMOVE THE DRAWER REMOVE THE ACCESS COVER & POWER CORD Product may move. Mark chassis position on cavity Access cover To prevent kinked hoses, we recommend rotating the drawer counter-clockwise and resting it on its side after removal. WARNING! Press the release tabs in on Electrical Shock Hazard...

  • Page 10: Cavity Preparation

    CAVITY PREPARATION Important! COUNTERTOP The power outlet must be located in a cabinet adjacent to the dishwasher cavity. Moisture 110-120 VAC max. 15 A 3⁄8” (10mm) protection tape must Water Connection These marks indicate be applied. formed bracket screw Recommended HOT locations, if securing (Maximum 140°F/60°C).
  • Page 11 INTEGRATED MODELS ONLY - PREPARATION FOR EXTERNAL VENTING THROUGH SAME CABINET Services can be located either side of dishwasher External Venting kit (1) Shelf cutouts max. 3⁄16” (5 mm) VENT HOSE ø max. 1½ ” (38 mm) ø 2 3⁄8” (60 mm) ø...
  • Page 12 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE Left hand side Right hand side Drain hose - 78 ½" (2000 mm) Drain hose - 70 ½" (1800 mm) Inlet hose - 64 ¾" (1650 mm) Inlet hose - 49" (1250 mm) Power cord - 29 ½"...
  • Page 13 DESIGNER & INTEGRATED TALL MODELS FOR 18 7⁄8” (480 mm) CAVITY ONLY - ATTACH CAVITY BRACKET The enclosed cavity bracket is fi tted before installation in order to conceal the gap at the top of the cavity left after installation. Firmly push the bracket so that Important! the prongs engage with the top...
  • Page 14 NOW CHOOSE WHICH INSTALLATION METHOD (a) or (b) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (a) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS INTEGRATED ONLY - ATTACH VENTING HOSE Clip all four side mounting brackets into their slots Check that the fitted elbow is rotated using a flat-bladed...
  • Page 15 PULL THROUGH HOSES & MOVE INTO THE CAVITY SECURE THE DRAWER Open the drawer halfway. Using a flat-bladed screwdriver, prize Vent Hose the gray Replace the gray (Integrated rubber plug out rubber plug back into models only) of the trim moulding. the trim moulding and ensure the trim seal is facing forward.
  • Page 16 ALTERNATIVE METHOD (b) - SECURE BY DRAWER REMOVAL INTEGRATED ONLY - ATTACH VENTING HOSE PULL THROUGH HOSES & MOVE INTO THE CAVITY Check that the fitted elbow is rotated left or right (depending on the direction of the routing), then ensure the venting hose is securely attached to it.
  • Page 17 REMOVE THE DRAWER SECURE THE DRAWER TO THE CABINETRY The product has three pairs of fixing points: Product may move. Mark chassis position on cavity Ensure the sound insulation is repositioned correctly. To prevent kinked hoses, we recommend rotating the drawer counter-clockwise and resting it on its side after removal.
  • Page 18 INTEGRATED MODELS ONLY - INSTALLING THE FRONT PANEL ATTACH PANEL TO PANEL BRACKET REMOVE BRACKET FROM PRODUCT WARNING! Electrical Shock Hazard There must be at least Before continuing, ensure that the product is 3 screws used each side disconnected from the power supply. Failure to follow this warning may result in 5⁄8”...
  • Page 19 INTEGRATED MODELS ONLY - INSTALLING THE FRONT PANEL ADJUST PANEL HEIGHT TO ALIGN THE CABINETRY GAPS + or - 1⁄16” (2 mm) With the front panels fitted, insert an appropriately sized Philips screwdriver into the hole above the door pin and rotate the panels up or down to align the gaps in your cabinetry.
  • Page 20 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. Dishwasher and Standpipe Ø 1½ ” (38 mm) Dishwasher using Air Break with Drain Hose Joiner Dishwasher using sink trap with drain hose joiner If space is limited for fixing, push hose through drain If space is limited...

  • Page 21: Final Checklist

    FINAL CHECKLIST TROUBLESHOOTING Check all parts are installed. Excessive water remaining above the filter plate, after the rinse cycle Check for a kinked drain hose or blocked waste connection, highloop not Ensure product is level, securely fastened to the cabinetry and opens and properly installed or drain hose not routed correctly.
