- Page 1 PX163+ DRIVER LED 48 x 700mA MANUAL...
-
Page 2: Table Of Contents
16. Technical data....................Declaration of conformity..................Manufacturer reserves the right to make modifications in order to improve device operation. tel.: +48 12 385 83 06 PXM Marek Żupnik spółka komandytowa fax: +48 12 626 46 94 Podłęże 654 E-mail: info@pxm.pl Rev.1.1... -
Page 3: General Description
1. GENERAL DESCRIPTION PX163+ is a 48-channel voltage driver designed for the RGB matrix systems, ideally suited for controlling lighting in large areas consisting of multiple modular elements. An example can be here the façade - LED screens or illuminated floors. It is possible to control all 48 channels through the DMX-512 protocol with the use of the in-built DMX signal receiver. -
Page 4: Model Description
3. MODEL DESCRIPTION Driving outputs: 48 (OUTPUTS) DMX OUT DMX IN Power supply LED display Driving buttons Diode of DMX signal... -
Page 5: Connection Diagram
4. CONNECTION DIAGRAM power supply 12-24V DC Power supply The receivers are connected to the driving and power supplying outputs as shown in the figure. The specified number of light sources can be on each line, depending on consumed power, and the load of each line is max. 700mA. -
Page 6: Dmx Signal Connection
5. DMX SIGNAL CONNECTION PX163+ must be connected to DMX line in series. This means that DMX IN terminals in the device must be provided with a driving cable, and then from DMX OUT connector the driving cable must be provided to other DMX receivers. If PX163+ is the last device in DMX line, "DMX+"... -
Page 7: Programming Of Group Parameters
the program playing speed liquidity level of changing the steps in the program setting of brightness of the program frequency of PWM signals switching on of the screen backlight the memory error message the restore default settings menu in the device the function of smoothing of transitions between different values minimum level of brightness 7. -
Page 8: Operation Mode
7.2. Operation mode PX163+ driver can operate in the effective mode (EFF) and the 48-channel mode (48b). In order to select the colour mode, in ALL menu enter Cbn function, and then select 48b for 48- channel or EFF for 4-channel mode (effective). ENTER ENTER NEXT... -
Page 9: Response To The Lack Of Dmx Signal
7.3. Response to the lack of DMX signal This function is used both to protect the system against the disappearance of DMX signal and to gain the driving of LEDs without connecting an external driver. After it has been activated, in case of the lack of DMX signal, the module will perform the selected function by itself. -
Page 10: The Smoothing Function
7.4. The smoothing function The device has also the smoothing option. Smoothing allows for smooth brightness and colour changes. When the function is on, the transition between further DMX values sent to the lamp (e.g. responsible for brightness) occurs smoothly without obvious jerks, which prevents the effects of "vibrations"... -
Page 11: Frequency Of Pwm Signals
9. FREQUENCY OF PWM SIGNALS The Frq function allows you to set the base frequency to drive LEDs. This function is extremely useful for applications in the television industry. By using the "flicker free" technology, you can avoid an unpleasant image flicker effect caused by a lack of appropriate synchronization of LED driving signal. -
Page 12: Screen Timeout
11. SCREEN TIMEOUT The device has been equipped with the option of switching off the backlight of the screen. This is provided by the SCr option. By using it, the display is switched off after approx. 1 min. of inactivity (buttons unused). -
Page 13: Default Settings And Memory Error
reversed screen normal position In order to restore the standard setting, hold the m i d d l e b u t t o n s f o r approximately 3s. 12.2. Default settings and memory error The device has been equipped with the option of restoration of the default settings. In order to use this option, disconnect PX163+ from power supply. -
Page 14: Rdm Description Of Available Parameters
13. RDM DESCRIPTION OF AVAILABLE PARAMETERS PX163+ supports the DMX-RDM protocol. The DMX protocol has been designed to allow one- direction flow of data, while its extension, the RDM protocol, can send information in two directions. For this reason, it is possible to simultaneously receive and send information, and hence the possibility of monitoring the operation of the devices compliant with the RDM protocol, and possible reconfiguring of their operating parameters. - Page 15 Description Parameter name NO_SIG_P1- 0x801C choice of work mode for No DMX signal; Minimal Value is 1, maximal 21. For values 1- 18|SC_19|ON_20|OFF_21 * 18 menu allows to chose program from 1 to 18 which is played during no DMX signal detection.
-
Page 16: Programming
14. PROGRAMMING ENTER ENTER ENTER NEXT NEXT ENTER NEXT NEXT PREVIOUS ENTER ENTER ENTER ENTER NEXT NEXT NEXT NEXT PREVIOUS ENTER NEXT ... NEXT NEXT PREVIOUS ENTER NEXT ENTER ENTER ENTER NEXT NEXT NEXT NEXT NEXT NEXT PREVIOUS ENTER ENTER NEXT NEXT NEXT... -
Page 17: Dimensions
15. DIMENSIONS 16. TECHNICAL DATA DMX channels: power supply: 12 - 24V DC current consumption: Max. 34A output channels number: outputs load capacity: Max. 0,7A / channel output sockets: terminal blocks dimensions: Width: 151 mm Height: 158,5 mm Depth: 30 mm... -
Page 18: Declaration Of Conformity
30-701 Kraków fax: 12 626 46 94 DECLARATION OF CONFORMITY according to guide lines 2004/108/WE Name of producer: PXM Marek Żupnik sp. k. Manufacturer’s address: ul. Przemysłowa 12 30-701 Kraków We declare that our product: Product name: DRIVER LED 48x700mA/OC...
