Main Board; Wire Connection - Astralpool POOL BASIC Installation Manual

EXP
- -
+ +
INPUT INPUT
pH RX
1 2 3 4 5
1
1) Input pH Probe
2) Input Redox Probe
3) Input Temperature Probe (PT100)
4) Input Level Probe Redox (Product Tank)
5) Input Level Probe pH (Product Tank)
6) Input Flow Rate (High Voltage 230 Vac)
7) Output Relay Solenoid Valve pH (Dry contact, Relay 250 Vac 10 A)
8) Output Relay Alarm remote (Dry contact, Relay 250 Vac 10 A)
9) Output Relay Solenoid Valve Redox (Dry contact, Relay 250 Vac 10 A)
10) Power Supply 230 Vac
11) Switch Power Supply
12) Fuse 500 mA Delay
13) Output pH and Redox pumps
0000137934
NOT
USED
LEV
NOT
pH
USED
LEV
TEMP
RX
PROBE

Wire Connection:

Main board

13
pH
RX
PUMP
PUMP
RELAY
INPUT
RL pH
FLOW
6 7 8
rev. 1.0
FUSE
RELAY RELAY
ALARM
RL RX L N
9 10
12
11
3
