10.1.4 Camera Setup
The buttons in the bottom of each channel are the functions for current channel only.
10.1.4.1 Setup
Press the button and the TSVideo Parameters window will be displayed.
(1) CH. Name: Enter the channel name.
(2) Login: Enter the User ID of the camera (default login: root).
(3) Password: Enter the password of the camera (default
password: admin).
(4) Encorder IP: Enter the IP address of the camera.
(5) CGI Port: Enter the CGI port of the camera (default CGI port:
80).
(6) Dev. Name: Select the connected device (select to the IP
Camera).
(7) Resolution: Select the resolution among 160x120/ 320x240/
640x480/ 1280x1024.
(8) Flip: Vertically rotate the video.
(9) Mirror: Horizontally rotate the video.
(10) I-Frame Only: Enable/ disable the I-Frame function.
(11) Audio Enable: Enable/ disable the audio function.
(12) Auto Connect: Automatically connect to the camera when execute the program.
(13) More...: Directly open the build-in Web for more configurations.
NOTE: Press the OK button to save and apply the configuration.
10.1.4.2 Connect: Click the button to connect the video server directly, the image of video server
will display in the preview window.
42
10.1.4.3 Refresh: To refresh the videos, the recording process will be stopped and restart again.
If the video is unstable after some high CPU resource programs, CPU usage may come to 100% and all
the resources are taken. In that case, the system may run in slower mode than ever. Please click
"Refresh" to renew the system and get it backs to higher performance.
10.1.4.4 Record: Record the current channel only.
10.1.4.5 Snapshot: Take a snapshot of live video.
10.1.4.6 Scheduler: Set the recording mode based on the weekday hour.
(1) Please click on the weekday hour block to change the recording mode or just drag the mode to the
weekday hour block.
(2) Enable Motion Detection: Enable/ Disable the motion detection function.
(3) Post-Alarm Recording: Enter the recording duration (seconds) after motion is detected
NOTE: If you want to use the motion detection recording function, be sure to enable the Motion
Detection function and set the Post-Alarm Recording, and confirm the Motion Detection (refer to
section 7.12) and the Alarm Picture (refer to section 7.12) have been enabled.
(4) Please save the file before exiting the setting dialog.
(5) Press the Apply button to update the current scheduler, and press the SAVE or Save As button to
save the configuration. Press the QUIT button to exit.
(6) Repeat the above steps to set up the other channels.
(7) After setting, press the Record button on the right side of the screen to start scheduled recording.
