7.3 Video Settings

User can adjust the parameters of the video stream by clicking on "Video" in the Menu List. The details of
video setting should appear in the Main Display area.
7.3.1 IE User
Fixed Quality: User might decide the video quality by selecting the degree of the video quality.
Mega Pixel Wi-Fi Camera supports up to 11 degrees of video quality.
QMax/QMin: The quality range supported by video server is from 0 to 51.
Resolution: Select the video resolution.
- NTSC: 176x120/ 352x240/ 720x480
- PAL: 176x144/ 352x288/ 720x576
Framerate: Select the frame rate of the video. The range of frame rate supported by video server
is from 1 to 30 fps.
IPInterval: Select the interval between two I-Frames in the video stream. The higher this value,
the easier the video is vague.
Audio Input: Enable/Disable the audio input of video server.
Brightness: Set the video brightness (0~15).
Contrast: Set the video contrast (0~50).
Sharpness: Set the video sharpness (0~15).
Save button: Save the configuration. All configurations should be available after the
configurations are successfully saved.
16
7.3.2 iPhone User
Wi-Fi Video Server Pro supports iPhone's browser, Safari. If user uses an iPhone to access to the Wi-Fi
Video Server Pro, the Video Setting page should appear as below.
Quality: Select the video quality. The degrees of the video quality supported by Mega Pixel IP
Camera are from 1 to 100.
Resolution: Select the video resolution.
- NTSC: 176x120/ 352x240/ 720x480
- PAL: 176x144/ 352x288/ 720x576
Framerate: Select the frame rate of the video.
Audio Input: Enable/Disable the audio input of video server.
Brightness: Set the video brightness (0~15).
Contrast: Set the video contrast (0~50).
Sharpness: Set the video sharpness (0~15).
Save button: Save the configuration. All configurations should be available after the
configurations are successfully saved.
