7.5 Network Settings

User can configure the network setting by clicking the "Network" in the Menu List. The details of network
setting should appear in the Main Display area.
Wireless Interface:
-DHCP Client: Enable/Disable the DHCP Client function. If the user wants to use dynamic IP
address for Wi-Fi Video Server Pro, please select "On" here.
-IP Address, Subnet Mask and Gateway: If the user wants to use a static IP address for Wi-Fi
Video Server Pro, please enter the IP Address, Subnet Mask and Gateway
Ethernet Interface:
-DHCP Client: Enable/Disable the DHCP Client function. If the user wants to use dynamic IP
address for Wi-Fi Video Server Pro, please select "On" here.
-IP Address, Subnet Mask and Gateway: If the user wants to use a static IP address for Wi-Fi
Video Server Pro, please enter the IP Address, Subnet Mask and Gateway
-DNS Settings: Enter the DNS servers to Wi-Fi Video Server Pro for name resolution.
Save button: Save the configuration. All configurations should be available after the
configurations are successfully saved.
20

7.6 Wireless Network Settings

Wi-Fi Video Server Pro supports 802.11b/g wireless network. User might configure the wireless setting by
clicking on "WLAN" in the Menu List. The details of network setting should appear in the Main Display
area. Please note, if the user wants to user the wireless network, he should turn the WLAN/LAN switch to
the WLAN side.
Mode: Select the wireless connection mode, whether Infrastructure or Ad-Hoc.
-AD-Hoc: If the user wants to use a wireless peer-to-peer connection, please select "Ad-Hoc".
-Infrastructure: If the user wants to connect Wi-Fi Video Server Pro with a wireless access point,
please choose "Infrastructure".
Operation Mode: Select the protocol that Wi-Fi Video Server Pro uses in the wireless network.
Wi-Fi Video Server Pro supports 802.11b/g protocol.
Channel: Select the RF channel used in the wireless network.
SSID: Enter the SSID of the wireless network.
Preamble Type: Select the type of preamble. The default value is long.
RTS Threshold: Set the RTS threshold. The default value is 2347.
Fragmentation Threshold: Set the Fragmentation Threshold. The default value is 2346.
Authentication: Select the authentication method used in the wireless network. Wi-Fi Video
Server Pro supports Open System, Share Key, WPA-PSK and WPA2-PSK authentication
methods.
WEP Key Setting: Wi-Fi Video Server Pro supports 64bit and 128bit WEP encryption. Please
configure the WEP parameters according to the user's wireless network.
WPA Encryption: Wi-Fi Video Server Pro supports TKIP and AES encryption for WPA enabled
wireless network. Please configure this value according to the wireless network.
WPA PSK: If the WPA-PSK, WPA2-PSK is enabled, please enter the key according to the wireless
network.
Save button: Save the configuration. All configurations should be available after the
configurations are successfully saved.
