  • Page 1 Blokhus 40011609-1545 Blokhus ENG...
  • Page 2 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 3 I n s t a l l a t i o n I n s t r u c t i o n s...

  • Page 4: Dear Customer

    Ensure that the concentric flue pipes are supported every meter, so that the weight of the pipes is not supported by the Glen Dimplex Benelux certifies that this Faber fire complies with the fire. essential requirements of the gas appliances directive.

  • Page 5: Preparation And Installation Instructions

    I n s t a l l a t i o n I n s t r u c t i o n s 4 Preparation and installation self-tapping screw • Wall and roof terminals can also be cut to length. instructions •...

  • Page 6: Annual Maintenance

    I n s t a l l a t i o n I n s t r u c t i o n s 9 Annual maintenance Checking the burner pressure and primary pressure Checking and cleaning: Check that the burner pressure and primary pressure match the information listed in the manual, Chapter 14 Technical specificati- •...
  • Page 7 These are 30° or 45° bends with a vertical offset of less than 45° (Fig.12.1 B and D). A simple way to calculate whether the exhaust configuration is possible in combination with your fire, use the free “Faber Flue App” • Pipes under a tilt angle: and download from: These are pipes which are vertically ascending at an angle of 30°...
  • Page 8 I n s t a l l a t i o n I n s t r u c t i o n s 11.1 Restrictor table Starting length (STL) Vertical (TVH) and Horizontal (THL)
  • Page 9 I n s t a l l a t i o n I n s t r u c t i o n s Examples flue materials fig. 12.1 fig.12.2 fig. 12.3...
  • Page 10 I n s t a l l a t i o n I n s t r u c t i o n s Calculation sheet Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m...
  • Page 11 I n s t a l l a t i o n I n s t r u c t i o n s found value Search in the table at TVH and THL and enter the value that is found. ………………………………...

  • Page 12: Technical Data

    I n s t a l l a t i o n I n s t r u c t i o n s Technical data II2H3+ II2H3+ II2H3+ Gas category Type appliance C11/C31/C91 C11/C31/C91 C11/C31/C91 Reference gas Input Efficiency class NOx-class Inlet pressure mbar...

  • Page 13: Terminal Position

    I n s t a l l a t i o n I n s t r u c t i o n s Terminal position > Please note: These rules apply only for the proper functioning of the unit, for ventilation and environmental protection you need to comply with the applicable rules Short roof terminal. as defined in the building regulations. Only for existing Chimney connection Extension pipe over roof Location Position outlet Distance mm...

  • Page 14: Troubleshooting Guide

    I n s t a l l a t i o n I n s t r u c t i o n s Troubleshooting guide - See inst. manual. - Learn a new code for remote. Light the pilot flame with - 1x 9V Alkaline.
  • Page 15 I n s t a l l a t i o n I n s t r u c t i o n s - Check the complete - Short circuit in the Pilot stays lit wiring of thermocouple thermocouple circuit. circuit.
  • Page 16 I n s t a l l a t i o n I n s t r u c t i o n s - RESET the receiver Optional: - Repaire the wiring. - Check the wiring from Step burner function can solenoid valve to receiver.

  • Page 17: Dimensional Drawings

    I n s t a l l a t i o n I n s t r u c t i o n s Dimensional drawings 17.1 Blokhus 17.2 Position gas connection...
  • Page 18 I n s t a l l a t i o n I n s t r u c t i o n s 18 Instruction extension Module(s)
  • Page 19 I n s t a l l a t i o n I n s t r u c t i o n s Instructions 19.1 Requirements • The distance to the ceiling must be at least 250mm. • When a single module is used in combination with double module(s), the single must be installed on top.
  • Page 20 I n s t a l l a t i o n I n s t r u c t i o n s Dimensional drawings 20.1 Extension module single 20.2 Extension module double...
  • Page 21 I n s t a l l a t i o n I n s t r u c t i o n s 20.3 Wall bracket...
  • Page 22 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 23 I n s t a l l a t i o n I n s t r u c t i o n s...
  • Page 24 Dealerinfo: www.faber.nl info@faber.nl Saturnus 8 NL - 8448 CC Heerenveen Postbus 219 NL - 8440 AE Heerenveen...
