Display Interface (Tcu); Turbo Connect Unit (Tcu); Starting The System On The Tcu - S-WORKS Creo SL User Manual

7.1
All Turbo CREO SL models are all equipped with the TCU display.
The display turns on the motor, and provides access to the support modes options, as well as the battery state of
charge and error codes.
The six-digit BLE code for bluetooth pairing is found underneath the TCU on the top tube, as well as on the "Peel
Me" Sticker. (Fig. 4.1)
7.2
9

7. DISPLAY INTERFACE (TCU)

7.1. TURBO CONNECT UNIT (TCU)

MODE CHANGE
BATTERY LEVEL
ERROR CODES
POWER

7.2. STARTING THE SYSTEM ON THE TCU

To start the system, press and hold the POWER
button located on the TCU top tube LED display unit,
until the horizontal LEDs glow blue.
To turn the battery (and support) off again, press and
hold the POWER button until the LEDs turn off.
BATTERY
COMPARTMENT
BLE PAIRING CODE
