Summary of Contents for S-WORKS MY20 TURBO CREO SL

  • Page 1 MY20 TURBO CREO SL...
  • Page 2 CREO SL UNBOXING The following document covers the unboxing and setup of the MY20 CREO SL.
  • Page 3 CREO SL - UNBOXING EXPECTED WORKING TIME This is the time that the entire process should take, assuming the mechanic has all proper tools, a clean and organized work area, no distractions and no unforeseen problems. Proficient: 30 - 45 minutes First time: 90 minutes...
  • Page 4 CREO SL - UNBOXING COMPONENT INSTALLATION All CREO SL components vary with different models. Please consult the individual component manuals supplied with your CREO SL for the most up to date installation guides.

  • Page 5: Tools Required

    CREO SL - UNBOXING TOOLS REQUIRED...
  • Page 6 CREO SL - UNBOXING Repair Stand. Standard bike tools (Allen keys, etc.). Torque wrench covering 0.8 - 6.2 Nm. Cable & housing cutter. Measuring tool. Small zip ties. Grease and carbon paste. PC with Turbo Studio installed. Micro USB cable for data transmission.
  • Page 7 CREO SL - UNBOXING Index Links Unpack and unwrap Mount the handlebars Attach the front wheel Connect the Di2 connector Connect the brakes Adjust the cockpit Wrap the handlebars Set up the Dropper Post Update the firmware (Without RE) 10. Update the firmware (With RE) Charge the battery 12.
  • Page 8 CREO SL - UNBOXING UNPACK AND UNWRAP BACK SKIP...
  • Page 9 CREO SL - UNBOXING Open the bike box and remove the small parts box, the front wheel, seatpost assembly and charger box.
  • Page 10 CREO SL - UNBOXING Open the small parts box to retrieve all the parts and manuals required for the build.
  • Page 11 CREO SL - UNBOXING Open the small parts box to retrieve all the parts and manuals required for the build.
  • Page 12 CREO SL - UNBOXING Attach the seat post assembly to the bicycle while still inside the box.
  • Page 13 CREO SL - UNBOXING Remove the bicycle from the box and place in a stable repair stand. Be careful not to clamp onto the carbon frame as it may damage the frame, clamp only on the seatpost.
  • Page 14 CREO SL - UNBOXING BLE: 599716 Remove the Peel Me sticker from the frame.
  • Page 15 CREO SL - UNBOXING Place the Peel Me sticker on the last page of the manual.
  • Page 16 CREO SL - UNBOXING Remove all of the protective packaging from the bicycle.
  • Page 17 CREO SL - UNBOXING Remove the spoke protector from the rear wheel. Use side cutters or a pair of strong scissors to break the plastic.
  • Page 18 CREO SL - UNBOXING Place the handlebars on a surface so the bars do not hang off the cables.
  • Page 19 CREO SL - UNBOXING MOUNT THE HANDLEBARS BACK SKIP...
  • Page 20 CREO SL - UNBOXING Remove the stem faceplate from the stem with a 4 mm Allen key.
  • Page 21 CREO SL - UNBOXING Attached the handlebar onto the stem, and loosely tighten the faceplate with a 4 mm Allen key.

  • Page 22: Attach The Front Wheel

    CREO SL - UNBOXING ATTACH THE FRONT WHEEL BACK SKIP...
  • Page 23 CREO SL - UNBOXING Attach the front wheel and tighten with a 6 mm Allen key to 15 Nm.
  • Page 24 CREO SL - UNBOXING CONNECT THE Di2 CONNECTOR (NOTE: NOT ALL CREO SL’S WILL HAVE ELECTRONIC SHIFTING) BACK SKIP...
  • Page 25 CREO SL - UNBOXING On certain models you will need to connect the electronic controllers. See the individual manuals supplied with your bike for this process.
  • Page 26 CREO SL - UNBOXING CONNECT THE BRAKES (NOTE: ALL CREO SL MODELS WILL VARY PLEASE SEE THE MANUFACTURER’S MANUAL FOR DETAILED INSTALLATION INSTRUCTIONS) BACK SKIP...
  • Page 27 CREO SL - UNBOXING Place the rubber sealing ferrule over the brake cable. (CREO SL Evo)
  • Page 28 CREO SL - UNBOXING Remove the sealing stopper from the end of the brake cable on the lever side. (CREO SL Evo)
  • Page 29 CREO SL - UNBOXING Remove the compression screw from the brake cable (CREO SL Evo). Place the compression screw over the brake hose on the brake side with the thread pointing to the end of the cable.
  • Page 30 CREO SL - UNBOXING Place the hydraulic brake hose into the joiner (CREO SL Evo) and tighten the compression screw with an 8 mm spanner.
  • Page 31 CREO SL - UNBOXING Check the brakes and adjust/bleed if necessary.
  • Page 32 CREO SL - UNBOXING Check the shifting and adjust if necessary.
  • Page 33 CREO SL - UNBOXING ADJUST THE COCKPIT BACK SKIP...
  • Page 34 CREO SL - UNBOXING Adjust the vertical angle of the handlebars.
  • Page 35 CREO SL - UNBOXING Tighten the bolts using a 4 mm Allen key to 5 Nm.
  • Page 36 CREO SL - UNBOXING Adjust the horizontal angle of the handlebars (stem in-line with front wheel).
  • Page 37 CREO SL - UNBOXING Tighten the bolts using a 4 mm Allen key to 5 Nm.
  • Page 38 CREO SL - UNBOXING Check if the movement of the cockpit is smooth and rotates freely. Make sure the headset play is adjusted correctly (refer to the Future Shock manual) LINK...
  • Page 39 CREO SL - UNBOXING WRAP THE HANDLE BARS BACK SKIP...
  • Page 40 CREO SL - UNBOXING All Creo SL models, except the S-WORKS and Expert, have the bartape pre-wrapped.
  • Page 41 CREO SL - UNBOXING SET UP THE DROPPER POST (CREO SL EVO ONLY) BACK SKIP...
  • Page 42 CREO SL - UNBOXING For this process you will need to remove the bicycle from the repair stand and place the bicycle in a stable floor stand with the seatpost removed. BACK SKIP...
  • Page 43 CREO SL - UNBOXING Slide the DP cable through the barrel adjuster and seat the barrel adjuster on the DP housing on the lever end.
  • Page 44 CREO SL - UNBOXING Slide the cable from the cockpit end through the DP housing so that it emerges from the seat tube.
  • Page 45 CREO SL - UNBOXING Rotate the cockpit to set the minimum exposed dropper housing.
  • Page 46 CREO SL - UNBOXING Remove the cable from the DP housing and cut the excess DP housing in line with the seat tube opening.
  • Page 47 CREO SL - UNBOXING Pull the DP housing out of the frame equivalent to the depth of the seat tube.
  • Page 48 CREO SL - UNBOXING Cut the housing again in line with the seat tube opening.
  • Page 49 CREO SL - UNBOXING Thread the DP cable back through the housing so it exits the seatpost end.
  • Page 50 CREO SL - UNBOXING Thread the plastic ferrule over the cable and slide it over the end of the DP housing.
  • Page 51 CREO SL - UNBOXING Slide the DP cable through the barrel until it is approx 15 mm from the end of the ferrule. Tighten with a 2.5 mm and 3 mm Allen key.
  • Page 52 CREO SL - UNBOXING Trim the excess cable with a pair of side cutters.
  • Page 53 CREO SL - UNBOXING Place the barrel into the DP trigger and locate the DP housing into the bottom seat.
  • Page 54 CREO SL - UNBOXING Insert the seat post to the desired depth, pulling the excess housing out through the bicycle at the cockpit end.
  • Page 55 CREO SL - UNBOXING Tighten the seat post collar with a 4 mm Allen key to 6.2 Nm.
  • Page 56 CREO SL - UNBOXING Adjust the barrel roller to make sure the DP engages properly.
  • Page 57 CREO SL - UNBOXING Test the DP by holding down the lever and pushing the saddle down and up.
  • Page 58 CREO SL - UNBOXING Test the DP by holding down the lever and pushing the saddle down and up.
  • Page 59 CREO SL - UNBOXING Test the DP by pushing the lever and the saddle down, releasing the lever at the lowest point, then pressing the lever to release the dropper post.
  • Page 60 CREO SL - UNBOXING Test the DP by pushing the lever and the saddle down, releasing the lever at the lowest point, then pressing the lever to release the dropper post.
  • Page 61 CREO SL - UNBOXING Use small cable ties to neaten up the cables in the cockpit area.

  • Page 62: Update The Firmware

    CREO SL - UNBOXING UPDATE THE FIRMWARE (NO RANGE EXTENDER CONNECTED) BACK SKIP...
  • Page 63 CREO SL - UNBOXING Unscrew the TCU on the top tube using a T10 driver.
  • Page 64 CREO SL - UNBOXING BLE: 599716 BLE PAIRING CODE Take note of the serial number on the side and the base of the TCU, you will need this for BLE pairing. This code is also printed on the Peel Me lable.
  • Page 65 CREO SL - UNBOXING Log into Turbo Studio. (Download Turbo Studio at www.service.specialized.com)
  • Page 66 CREO SL - UNBOXING Open the rubber door located at the front of the TCU and connect a data micro USB cable into the port.
  • Page 67 CREO SL - UNBOXING Connect the other end of the cable with a standard USB to a PC running Turbo Studio.
  • Page 68 CREO SL - UNBOXING Power on the CREO SL.
  • Page 69 CREO SL - UNBOXING Follow the steps as shown on Turbo Studio.
  • Page 70 CREO SL - UNBOXING Power off the CREO SL.
  • Page 71 CREO SL - UNBOXING UPDATE THE FIRMWARE (RANGE EXTENDER CONNECTED) BACK SKIP...
  • Page 72 CREO SL - UNBOXING Insert the RE connector into the socket.
  • Page 73 CREO SL - UNBOXING Secure the cable into the cable guide.
  • Page 74 CREO SL - UNBOXING Slide the range extender into the Zee Cage.
  • Page 75 CREO SL - UNBOXING Make sure the RE is securely in place.
  • Page 76 CREO SL - UNBOXING Lift the sprung lid of the charge port...
  • Page 77 CREO SL - UNBOXING Plug the range extender into the charge port of the CREO SL.
  • Page 78 CREO SL - UNBOXING Turn the lever on the connector clockwise to lock the plug into the socket.
  • Page 79 CREO SL - UNBOXING Turn the lever on the connector clockwise to lock the plug into the socket.
  • Page 80 CREO SL - UNBOXING Fit the RE retention strap around the range extender to secure it into the bottle cage.
  • Page 81 CREO SL - UNBOXING Fit the RE retention band around the range extender to secure it into the bottle cage.
  • Page 82 CREO SL - UNBOXING Run Turbo Studio.
  • Page 83 CREO SL - UNBOXING Power on the CREO SL.
  • Page 84 CREO SL - UNBOXING Follow the steps as shown on Turbo Studio.
  • Page 85 CREO SL - UNBOXING Power off the CREO SL.
  • Page 86 CREO SL - UNBOXING Unplug the Micro USB and reseal the rubber door on the TCU.
  • Page 87 CREO SL - UNBOXING Replace the TCU into the top tube and tighten with a Torx 10 Driver to 0.8 Nm.

  • Page 88: Charge Battery

    CREO SL - UNBOXING CHARGE BATTERY BACK SKIP...
  • Page 89 CREO SL - UNBOXING Connect the charger to a wall outlet, then connect the charger plug into the charge port on the CREO SL.
  • Page 90 CREO SL - UNBOXING Make sure the TCU indicates that the battery is charging. The TCU will show green bars on the display if the Range Extender is connected.
  • Page 91 CREO SL - UNBOXING CHARGE ELECTRONIC COMPONENTS (REAR DERAILLEUR) BACK SKIP...
  • Page 92 CREO SL - UNBOXING Make sure all electronic components are charged and the firmware updated before handing over to the rider.
  • Page 93 CREO SL - UNBOXING Make sure all electronic components are charged before handing over to the rider.
  • Page 94 CREO SL - UNBOXING CREATE A RIDER PACK BACK...
  • Page 95 CREO SL - UNBOXING Place the charger, all the manuals, and extra small parts into the zip case provided with the bicycle.
  • Page 96 CREO SL - UNBOXING Make sure to connect the case to the correct CREO SL so the rider later receives the right case.
