- Page 1 WAL-L412 BP LED spotlight...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 25.11.2019, ID: 461723...
-
Page 3: Table Of Contents
Installation..............................19 4.1 Dealing with lithium batteries..................... 24 Starting up..............................26 Connections and controls........................28 Operating..............................34 7.1 Starting the device........................... 34 7.2 Main menu............................34 7.3 Menu overview..........................40 7.4 Functions in 4-channel DMX mode................... 41 WAL-L412 BP LED spotlight... - Page 4 Table of contents 7.5 Functions in 6-channel DMX mode................... 41 7.6 Functions in 9-channel DMX mode................... 42 Technical specifications........................48 Plug and connection assignments....................51 Troubleshooting............................52 Cleaning............................... 55 Protecting the environment......................56 WAL-L412 BP LED spotlight...
- Page 5 WAL-L412 BP LED spotlight...
-
Page 6: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. WAL-L412 BP LED spotlight... -
Page 7: Further Information
Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. WAL-L412 BP LED spotlight... -
Page 8: Notational Conventions
Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. WAL-L412 BP LED spotlight... - Page 9 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – dangerous optical radiation. WAL-L412 BP LED spotlight...
- Page 10 General information Warning signs Type of danger Warning – suspended load. Warning – danger zone. WAL-L412 BP LED spotlight...
-
Page 11: Safety Instructions
Extend the life of the device by regular breaks in operation and avoid switching it on and off frequently. This device is not suitable for continuous use. WAL-L412 BP LED spotlight... - Page 12 Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. WAL-L412 BP LED spotlight...
- Page 13 WARNING! Eye damage caused by high light intensity Never look directly into the light source. WARNING! Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. WAL-L412 BP LED spotlight...
- Page 14 Follow the advice on the correct handling of lithium batteries in the present sec‐ tion. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. WAL-L412 BP LED spotlight...
- Page 15 Ensure that proper polarity is observed when inserting batteries. NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period. WAL-L412 BP LED spotlight...
- Page 16 Store the equipment at a tempera‐ ture between 10 °C and 32 °C in as dry an environment as possible. During extended storage periods, charge the batteries to 50 % approximately every three months. WAL-L412 BP LED spotlight...
-
Page 17: Features
Additional diffusion filters available: 20° (item no. 461726), 40° (item no. 461727), 15x60° (item no. 471120) Compatible charging station (Item no. 461728, optionally available). Compatible Touring Case 4in1 (Item no. 461732) or 6in1 (Item no. 461733) with power supply for charging optionally available. WAL-L412 BP LED spotlight... - Page 18 For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. You can extend the service life of the illuminants by providing adequate ventilation and operating the LEDs with the lowest possible brightness. WAL-L412 BP LED spotlight...
-
Page 19: Installation
Risk of injury caused by falling objects Make sure that the installation complies with the standards and rules that apply in your country. Always secure the device with a secondary safety attachment, such as a safety cable or a safety chain. WAL-L412 BP LED spotlight... - Page 20 Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. WAL-L412 BP LED spotlight...
- Page 21 Always work from a stable platform whenever installing, moving or servicing the unit. In doing so, the area underneath the unit must be cordoned off. The safety cable must be threaded through the cut-outs in the housing. WAL-L412 BP LED spotlight...
- Page 22 Please note that this device must not be connected to a dimmer. Infrared sensor for the remote The infrared receiver for the remote control signals is located in the display. Make sure it's not control obstructed. WAL-L412 BP LED spotlight...
- Page 23 Slide the battery holder back into the remote until it clicks into place. When shipping, the battery is already installed in the remote and protected against discharge by a transparent plastic foil. Remove the plastic foil prior to first use. WAL-L412 BP LED spotlight...
-
Page 24: Dealing With Lithium Batteries
You must wear protective rubber gloves when doing so. Clean your hands and the affected surface thoroughly with cold water. WAL-L412 BP LED spotlight... - Page 25 Before disposing of the device remove the lithium batteries. Protect used lithium batteries against potential short circuits, e.g. by covering the poles with adhesive tape. Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning lithium battery. WAL-L412 BP LED spotlight...
-
Page 26: Starting Up
Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. WAL-L412 BP LED spotlight... - Page 27 Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain is terminated with a resistor (110 Ω, ¼ W). WAL-L412 BP LED spotlight...
-
Page 28: Connections And Controls
Connections and controls Connections and controls WAL-L412 BP LED spotlight... - Page 29 The display gets locked and shows the current operating mode if no key is pressed during 30 s. Simultaneously press [MODE] and [SET] for 3 s, to unlock. [ON / OFF] Switches the unit to standby mode or activates it. Button [MODE] Activates the main menu and toggles between menu items. Closes an opened submenu WAL-L412 BP LED spotlight...
- Page 30 Toggles between the menu items of a menu level, increases or decreases the displayed value by one [SET] button Selects an option of the respective operating mode, confirms the set value Button To disconnect the wireless DMX connection 9 Sensor for IR remote control WAL-L412 BP LED spotlight...
- Page 31 Connections and controls Remote control A remote control is optional accessory (item # 354223) and not included. WAL-L412 BP LED spotlight...
- Page 32 Allows to set the running speed of programmes 02…17 11 [PRG] Enables the Programme mode 12 [STROBE] Turns the Stroboscope effect on and off 13 [Dimming] Brightness control 14 [–] Decreases the displayed value by one WAL-L412 BP LED spotlight...
- Page 33 9 = warm white 16 Buttons for colour selection 17 [+] Increases the displayed value by one 18 [SOUND] No function Press [OFF] and then [9], [8] and [7] to reset the device to factory settings. WAL-L412 BP LED spotlight...
-
Page 34: Operating
DMX signal is being received. All previously made settings are retained even when you disconnect the device from the power grid. To restart with default values, use the function ‘Factory’ . The following table shows the setting options. WAL-L412 BP LED spotlight... - Page 35 4-channel mode 6-channel mode 9-channel mode ‘Channels’ ‘4-CH’ 4-channel DMX mode ‘6-CH’ 6-channel DMX mode ‘9-CH’ 9-channel DMX mode ‘W-DMX’ ‘On’ / ‘Off’ ‘Slave’ Slave mode ‘AUTO’ Automatic programme run ‘Program’ ‘Mode’ ‘1…17’ Preprogrammed programme sequence WAL-L412 BP LED spotlight...
- Page 36 Linear (proportional) course ‘Square Law’ Non-linear curve with a distinctive flat profile at the beginning and end ‘Inv Square Law’ Inverted quadratic curve with a steep profile at the beginning and flat profile at the end WAL-L412 BP LED spotlight...
- Page 37 Switches to dimmer mode ‘Program’ Switches to preprogrammed programme mode ‘Working Time’ Setting the battery runtime ‘Off’ Device operates with highest performance ‘1…15’ The light output is reduced so far that the set run‐ time can be achieved. WAL-L412 BP LED spotlight...
- Page 38 ‘DMX Sync’ Setting the DMX synchronisation ‘On’ Enabled ‘Off’ Disabled ‘Lock’ Lock screen ‘On’ Turned on ‘Off’ Turned off Calibration Colour calibration, white balance ‘0…255’ Green ‘0…255’ Blue ‘0…255’ White ‘0…255’ Factory Reset to factory defaults WAL-L412 BP LED spotlight...
- Page 39 Meaning ‘ Information’ ‘V: x.x.x’ Show firmware version of the device ‘Temperature: xx ° C’ Display of device temperature and protection against overheating ‘WDMX: On / off’ Wireless DMX display ‘Work Time: xxxxxh’ Work time display WAL-L412 BP LED spotlight...
-
Page 40: Menu Overview
Operating 7.3 Menu overview WAL-L412 BP LED spotlight... -
Page 41: Functions In 4-Channel Dmx Mode
Intensity white (0 % to 100 %) 7.5 Functions in 6-channel DMX mode Channel Value Function 0…255 Dimmer (0 % to 100 %) 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) WAL-L412 BP LED spotlight... -
Page 42: Functions In 9-Channel Dmx Mode
No function 11…255 Increasing speed 7.6 Functions in 9-channel DMX mode Channel Value Function 0…255 Dimmer (0 % to 100 %) 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) WAL-L412 BP LED spotlight... - Page 43 R255 G015 B000 W000 28…33 R255 G050 B000 W000 34…39 R255 G125 B000 W000 40…45 R255 G170 B000 W000 46…51 R255 G210 B000 W000 52…57 R255 G255 B000 W000 58…63 R200 G255 B000 W000 64…69 R160 G255 B000 W000 WAL-L412 BP LED spotlight...
- Page 44 R000 G255 B040 W000 106…111 R000 G255 B070 W000 112…117 R000 G255 B120 W000 118…123 R000 G255 B255 W000 124…129 R000 G100 B255 W000 130…135 R000 G000 B255 W000 136…141 R020 G000 B255 W000 142…147 R050 G000 B255 W000 WAL-L412 BP LED spotlight...
- Page 45 R255 G000 B220 W000 184…189 R255 G000 B070 W000 190…195 R255 G000 B020 W000 196…201 R255 G000 B007 W000 202…207 R000 G000 B000 W255 208…213 R255 G000 B000 W255 214…219 R125 G000 B000 W255 220…225 R000 G255 B000 W255 WAL-L412 BP LED spotlight...
- Page 46 R000 G000 B100 W255 244…255 R000 G000 B050 W255 Preprogrammed programme sequences 0…15 No function 16…30 Programme 02 31…45 Programme 03 46…60 Programme 04 61…75 Programme 05 76…90 Programme 06 91…105 Programme 07 106…120 Programme 08 WAL-L412 BP LED spotlight...
- Page 47 Programme 11 166…180 Programme 12 181…195 Programme 13 196…210 Programme 14 211…225 Programme 15 226…240 Programme 16 241…255 Programme 17 0…255 Speed increasing, if channel 7 = 16…255 Strobe effect 0…10 No function 11…255 Increasing speed WAL-L412 BP LED spotlight...
-
Page 48: Technical Specifications
XLR chassis socket, 5-pin Output connections DMX control XLR chassis socket, 5-pin Power consumption 75 W Operating supply voltage 20 V (via charging station Ignition WAL-L Single Charge, item no. 461728) Battery / rechargeable bat‐ Battery type Lithium-ion, chargeable tery Voltage 18.5 V... - Page 49 Protection class IP65 Mounting options hanging, standing Dimensions (W × H × D) 163 mm × 163 mm × 287 mm Weight 4.5 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 50 %, non-condensing WAL-L412 BP LED spotlight...
- Page 50 Technical specifications Further information Outdoor housing shape Flood light Floor housing Fanless Wireless DMX IR remote control Optionally available (item no. 354223) Charging station Optionally available (item no. 461728) Housing colour black WAL-L412 BP LED spotlight...
-
Page 51: Plug And Connection Assignments
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) WAL-L412 BP LED spotlight... -
Page 52: Troubleshooting
Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: WAL-L412 BP LED spotlight... - Page 53 Please contact our service centre. No connection can be established Hold down the W-DMX button on the device until the to a W-DMX transmitter. display expires. Press the Link button on your trans‐ mitter. WAL-L412 BP LED spotlight...
- Page 54 Troubleshooting If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. WAL-L412 BP LED spotlight...
-
Page 55: Cleaning
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐ ular basis. Before cleaning, switch off the device and disconnect mains-operated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. WAL-L412 BP LED spotlight... -
Page 56: Protecting The Environment
Remove lithium batteries from the device before disposal. Protect used lithium batteries against potential short circuits, e.g. by covering the poles with adhesive tape. Dispose the built-in lithium batteries together with the device. Please check for an appropriate reception facility. WAL-L412 BP LED spotlight... - Page 57 Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. WAL-L412 BP LED spotlight...
- Page 58 Notes WAL-L412 BP LED spotlight...
