SL230MP
Condenser Microphone Kit

PRODUCT SPECIFICATION

Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Low Noise FET
Polar Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cardioid
High Pass Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 Hz/ 12dB per Octave
Attenuation PAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -15dB
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8mV/Pa
Maximum SPL at 1 .0% THD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135dB SPL
Maximum SPL with PAD engaged at 1 .0% THD . . . . . . . . . . . . . . . .150dB SPL
Equivalent Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 22dB SPL
Typical Load Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .> 1000 Ohm
Microphone Output Impedance . . . . . . . . . . . . . . . . . 200 Ohm Transformerless
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +48V Phantom Power
Dimensions (Physical microphone) . . . . . . . . . . . 5 .9" long, 0 .87" Max Diameter
Matched Pair Tolerance . . . . . . . . . ≤1dB Frequency Response and Sensitivity

FREQUENCY RESPONSE

RECORDING TIPS: www.sterlingaudio.net
Sterling Audio
P .O . Box 5111
Thousand Oaks, CA 91359-5111
(150mm long, 22mm Max Diameter)
1805-18271481
CONDENSER
SL230MP
MICROPHONE
KIT
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL230MP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sterling SL230MP

Summary of Contents for Sterling SL230MP

  • Page 1 CONDENSER SL230MP MICROPHONE SL230MP OWNER’S MANUAL Condenser Microphone Kit PRODUCT SPECIFICATION Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Low Noise FET Polar Response .
  • Page 2 -15dB Pad Shock Mount Reduces volume: set to -15dB only if source is too loud for your preamp . Isolates your Sterling SL230 mic from noise due to vibrations received through mic stands . Low Cut (-12dB/octave @ 75Hz) Reduces low frequencies for a more focused sound .
