Table of Contents
Advertisement
This Instruction Book Contains Information
For Several Models. Read And Keep This Book For
Future Reference. This Book Contains Important Information On:
SAFETY, ASSEMBLY, OPERATION AND MAINTENANCE.
PRODUCT INFORMATION
The owner must be certain that all the product information is included with this unit.
This information includes the INSTRUCTION BOOKS, the REPLACEMENT PARTS
and the WARRANTIES. This information must be included to make
sure local laws are followed.
Model
12530
Record The Following Information About Your Unit. This Information
Is Necessary When Ordering Parts Or In Case Of Loss Or Theft.
WHERE PURCHASED:
.
DATE PURCHASED: Month
Day
Year
.
MODEL NO.:
DATE OF MANUFACTURE:
.
1
Advertisement
Table of Contents
Related Manuals for Webb 12530
Summary of Contents for Webb 12530
- Page 1 WARRANTIES. This information must be included to make sure local laws are followed. Model 12530 Record The Following Information About Your Unit. This Information Is Necessary When Ordering Parts Or In Case Of Loss Or Theft. WHERE PURCHASED:...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........OPERATING TIPS . -
Page 3: Responsibility Of The Owner
OWNER’S INFORMATION This instruction book is for several different models. The instructions are written for a person with some mechanical ability. Like most service books, not all the steps are described. Steps on how to loosen or tighten fasteners are steps anyone can follow with some mechanical Engine Exhaust, some of its constituents, and ability. - Page 4 OWNER’S INFORMATION c. Do not turn sharply. Use care when backing. d. Use counterweights or wheel weights when suggested in the Instruction Book. 18. Do not operate this machine if you are taking drugs or other medication which can cause drowsiness or affect your ability to operate this machine.
- Page 5 SAFE MOWING GUIDE Each person that operates power controls and how they work. In an equipment must learn to use the correct emergency, it is important that you can and safe mowing procedures. Therefore stop the blade quickly. Learn how to control carefully read the following pages.
- Page 6 SAFE MOWING GUIDE of the mower. Stop the engine. Let the mower was completely assembled by the When you mow, be careful of bystanders seller, you must still check the mower especially children Always use caution when engine and transmission cool before according to the assembly instructions.
- Page 7 SAFE MOWING GUIDE Also, the grass bagger will function better feel new or excessive vibration, sharp or at a slow engine speed you can immediately stop the engine and check for damage the grass. Move the throttle control when the engine is operating at maximum speed.
- Page 8 STEPS TO FOLLOW BEFORE MOWING • Be sure to dress correctly. Wear hard shoes, not sandals, trainers or tennis shoes. • Examine the blade. A blade that is bent, cracked, or damaged must be replaced with a factory replacement blade. •...
- Page 9 INTERNATIONAL SYMBOLS INTERNATIONAL SYMBOLS IMPORTANT: Some of the following Flush Eyes Immediately With Water. 10 DANGER: No Step. symbols are located on your unit or on Get Medical Help Fast. 11 DANGER: Keep Feet And Hands manuals supplied with the product. IMPORTANT: Read Owner’s Manual Away From Rotating Blade.
-
Page 10: Assembly
ASSEMBLY ASSEMBLY WARNING: Before doing any assembly or Read and follow the assembly and adjustment instructions for your maintenance to the mower, remove the wire from the mower. All fasteners are in the parts bag. Do not discard any parts spark plug. -
Page 11: How To Install The Seat
ASSEMBLY HOW TO INSTALL THE SEAT Check the operating position of the seat. If the seat needs to be adjusted, loosen the two wing bolts (A). Slide the seat Use the fasteners shown below to install the seat. forward or backward along the seat adjusting holes as shown. Tighten the wing bolts (A). -
Page 12: Maintenance Free Battery
ASSEMBLY Remove the protective cap from the battery terminal. MAINTENANCE FREE BATTERY Use a 12 volt battery charger to charge the battery. Charge at IMPORTANT: Before you attach the battery cables to the a rate of 6 amperes for one hour. If you do not have a battery battery, check the battery date. -
Page 13: How To Prepare The Engine
ASSEMBLY IMPORTANT! BEFORE YOU START MOWING - Check the engine oil. WARNING: Before doing any assembly or maintenance to the mower, remove the wire from the - Fill the fuel tank with petrol. spark plug. - Check the air pressure of the tires. - Check the level of the mower housing. -
Page 14: Operation
OPERATION Clutch / Brake Ignition Key Switch Pedal Blade Rotation Control Parking Brake Shift Lever Lift Lever Throttle Control Lever Figure 4 LOCATION OF CONTROLS BLADE ROTATION CONTROL: SHIFT LEVER: Use the blade rotation Use the shift lever to change the speed of the control to start and stop the rotation of the blade. -
Page 15: Attachments
OPERATION ATTACHMENTS This unit can use many different attachments. See the attachment weight is 200 pounds. Gross weight is the weight of the attachment page in this book. This unit can pull attachments like a lawn or trailer and any load that might be on or in it. sweeper, a lawn aerator, a hopper spreader, or a small trailer. -
Page 16: How To Use The Throttle / Choke Control
OPERATION HOW TO USE THE THROTTLE / CHOKE CONTROL Use the throttle/choke control to choke the engine for cold starts and increase or decrease the speed of the engine (see Figure 6). Move the throttle/choke control completely forward to the CHOKE position to start a cold engine. -
Page 17: How To Use The Shift Lever
OPERATION HOW TO USE THE SHIFT LEVER To change the forward speed or the direction of the unit, follow the To go forward, move the shift lever to a forward speed setting. steps below. To go backward, move the shift lever to reverse. Always CAUTION: Before you move the shift lever, completely push Disengage the blades and look down and behind before and while the clutch/brake pedal forward to stop the unit. -
Page 18: How To Set The Parking Brake
OPERATION HOW TO SET THE PARKING BRAKE Completely push the clutch/brake pedal forward. Parking Brake Lift the parking brake lever (Figure 11). Clutch/Brake Remove your foot from the clutch/brake pedal and then release Pedal the parking brake lever. Make sure the parking brake will hold the unit. -
Page 19: How To Install The Side Discharge Attachment
OPERATION HOW TO INSTALL THE SIDE DISCHARGE ATTACHMENT Remove the fasteners that secure the mulcher cover (see WARNING: To prevent the engine from starting, Figure 13). disconnect the wire from the spark plug. Make sure the blade rotation control is in the DISENGAGE position. Lift the mulcher cover. -
Page 20: Before Starting The Engine
OPERATION CAUTION: A mixture of alcohol (ethanol or methanol) and BEFORE STARTING THE ENGINE petrol (called gasohol), will attract moisture and cause acid deposits during storage. While the unit is in storage, the acids CHECK THE OIL in the fuel can damage the fuel system. NOTE: The engine was shipped from the factory filled with oil. -
Page 21: How To Operate With The Mower Housing
OPERATION HOW TO OPERATE WITH THE MOWER HOUSING WARNING: The deflector is a safety device. Do not Slowly move the blade rotation control to the ENGAGE remove the deflector. The deflector forces the position. discharged material toward the ground. Always keep Push the clutch/brake pedal completely forward. -
Page 22: Operating Tips
OPERATION OPERATING TIPS Check the blade rotation control for correct adjustment for the Before you make an inspection, adjustment (except for the blade to disengage correctly, the adjustment must be correct. carburetor) or repair, make sure the wire from the spark plug is disconnected. -
Page 23: Maintenance
MAINTENANCE MAINTENANCE CHART FREQUENCY MAINTENANCE REQUIRED COMMENTS Daily or before each Maintenance the engine. Refer to the Engine Owner’s Manual. Examine blade(s). Check for cracks, wear, and damage. Remove debris from unit and mowing area Examine all rotating and sliding parts. Check tire inflation. -
Page 24: How To Remove And Install The Blade
MAINTENANCE 9. Tighten the nut that holds the blade to a torque of 35 foot INSPECT BLADE pounds (47,5 N-m). WARNING: Before you inspect or remove the blade, 10. Install the mower housing. See “How To Install The Mower disconnect the wire to the spark plug. If the blade hits an object, stop the engine. - Page 25 MAINTENANCE CHECK THE BLADE ROTATION CONTROL Check the blade(s). Keep a sharp edge on the blade(s). A blade that is not sharp will cause the tips of the grass to become WARNING: To prevent an injury, the blade rotation brown. control must operate correctly.
-
Page 26: How To Check And Adjust The Drive Brake
MAINTENANCE HOW TO CHECK AND ADJUST THE DRIVE BRAKE Completely push the clutch/brake pedal forward. Set the parking Drive Brake brake. Move the shift lever to the neutral (N) position. Push the unit. If the rear wheels rotate, adjust or replace the brake pads. Adjust the drive brake as follows. -
Page 27: How To Adjust The Shift Lever
MAINTENANCE HOW TO ADJUST THE SHIFT LEVER If the NEUTRAL position on the shift lever does not match neutral on the gearbox, adjust the shift lever as follows. Stop the engine. Adjuster Nut Disconnect the adjuster nut from the shifter yoke (Figure 22). Make sure the shift lever is in the NEUTRAL position. -
Page 28: Where To Lubricate
MAINTENANCE WHERE TO LUBRICATE Apply grease with a brush to the areas shown. Lubricate the areas shown with engine oil. NOTE: Apply grease to the steering gear assembly. CAUTION: If the unit is operated in dry areas that have sand, use a dry graphite spray to lubricate the unit. -
Page 29: How To Level The Mower Housing
MAINTENANCE HOW TO LEVEL THE MOWER HOUSING If the mower housing is level, the blade will cut easier and the lawn will look better. Level Adjustment WARNING: Before you make an inspection, Position adjustment, or repair to the unit, disconnect the wire Lift Lever to the spark plug. -
Page 30: How To Remove The Mower Housing
MAINTENANCE HOW TO REMOVE THE MOWER HOUSING HOW TO INSTALL THE MOWER HOUSING Move the blade rotation control to the DISENGAGE position. Push the mower housing under the right side of the unit. Move the lift lever to the level adjustment position (Figure 29). 2. -
Page 31: How To Replace The Motion Drive Belt
MAINTENANCE HOW TO REPLACE THE MOTION DRIVE BELT REMOVAL top pulley of the stack pulley. Make sure the “V” side of the belt is against the pulley. 1. Remove the mower housing. See the instructions on “How To Install the end of the motion drive belt around the drive Remove The Mower Housing”. -
Page 32: How To Replace The Mower Drive Belt
MAINTENANCE HOW TO REPLACE THE MOWER DRIVE BELT Remove the mower housing. See the instructions on “How To Pull the belt retainer away from the idler pulley. Put the Remove The Mower Housing”. mower drive belt around the idler pulley. Pull the belt retainer away from the idler pulley and remove the mower drive belt (Figure 32). -
Page 33: How To Install The Wheels
MAINTENANCE HOW TO INSTALL THE WHEELS Cotter Pin If the wheels must be removed for service, make sure they are Hub Cap installed as follows. Washer Washer Front Wheel Make sure the valve stem is to the outside of the tractor. Slide the front wheel on the spindle (See Figure 33). - Page 34 MAINTENANCE HOW TO REPLACE THE FUSE If the fuse is blown, the engine will not start. The location of the fuse is next to the battery. Remove the fuse and replace with an Automotive automotive fuse (Figure 35). Fuse Figure 35 HOW TO CLEAN THE MOWER HOUSING frequently clean the top of the mower housing.
-
Page 35: Trouble Shooting Chart
TROUBLE SHOOTING CHART PROBLEM: The engine will not start. PROBLEM: Excessive vibration. Follow the steps, “How To Start The Engine” in this book. Replace the blade. 2. Electric-Start Models: Clean the battery terminals. Tighten the 2. Check for loose engine bolts. cables. - Page 36 Only use a factory repair part. Repair parts, except for the engine or the transmission, are available from the store where the unit was purchased, a service shop recommended by the store, or an authorised service shop. If you cannot get a repair part or service as described above, call the number shown below. When you order, include the following information: (1) Complete Model Number (see nameplate), (2) Date of Manufacture, (3) Complete Part Number, (4) Description, (5) Quantity.
- Page 37 NOTES...
- Page 38 12530 Ride On Mower WE12530 REPAIR PARTS CHASSIS & HOOD...
- Page 39 12530 Ride On Mower WE12530 REPAIR PARTS CHASSIS & HOOD PART NO DESCRIPTION PART NO DESCRIPTION WE‐690566 Seat WE‐1401240 Fuel Tank WE‐1401027E245 Hood WE‐06x111 Screw WE‐017x47 Washer WE‐26x253 Screw WE‐1001054 Wing Bolt WE‐1401110 Hood Prop Rod WE‐002x53 Carriage Bolt WE‐1401282 Seat Deck Spring WE‐1401036E701 Hinge Bracket WE‐1401352E701 Propr Rod Bracket WE‐009x29 Shoulder Bolt WE‐26x201 Screw WE‐009x56 Shoulder Bolt WE‐15x116 Nylon Lock Nut WE‐1401113...
- Page 40 12530 Ride On Mower WE12530 REPAIR PARTS MOTION DRIVE...
- Page 41 12530 Ride On Mower WE12530 REPAIR PARTS MOTION DRIVE PART NO DESCRIPTION PART NO DESCRIPTION B&S Engine WE‐1401078 Clutch Rod WE‐01x134 Hex Bolt WE‐1401128E701 Clutch Arm Assembly WE‐1401207 Heat Shield Assembly WE‐0011x7 Retainer Ring WE‐018x32 Lockwasher WE‐1401077 Drive Pulley WE‐0025x2 Screw WE‐002x53 Carriage Bolt WE‐1401251 Muffler WE‐009x39 Shoulder Bolt WE‐091309 Muffler Gasket WE‐1401252 Idler Pulley WE‐165x75 Extension Spring WE‐37x110 Motion Drive Belt WE‐165x148 Extension Spring...
- Page 42 12530 Ride On Mower WE12530 REPAIR PARTS STEERING...
- Page 43 12530 Ride On Mower WE12530 REPAIR PARTS STEERING PART NO DESCRIPTION PART NO DESCRIPTION WE‐095185 Steering Wheel WE‐01x146 Hex Bolt WE‐711326 Steering Insert WE‐011x23 E‐Clip WE‐1401044 Steering Console WE‐030x35 Cotter Pin WE‐26x270 Screw WE‐094131 Spring Retainer Upper Steering WE‐1401090 WE‐1401046E701 Steering Rack Bearing WE‐1401226 Steering Tube WE‐17x201 Washer WE‐1401100 Steering Shaft WE‐1401376E701 Front Axle Bracket WE‐1401055E701 Steering Support WE‐17x157 Washer Axle & Spindle ...
- Page 44 12530 Ride On Mower WE12530 REPAIR PARTS MOWER HOUSING SUSPENSION...
- Page 45 12530 Ride On Mower WE12530 REPAIR PARTS MOWER HOUSING SUSPENSION PART NO DESCRIPTION PART NO DESCRIPTION WE‐092697 Lift Lever Grip WE‐093349 Guide Screw WE‐1401117 Lift Lever WE‐015x79 Flange Nut WE‐165x154 Extension Spring WE‐015x84 Flange Nut WE‐094137 Friction Pad WE‐1401147 Leaf Spring WE‐017x45 Washer WE‐1401040E701 Front Hanger WE‐095004 Wingnut WE‐1401116 PTO Lever WE‐1401033E701 Lift Link WE‐26x263 Screw WE‐1401096 Spacer Tube WE‐094198 PTO Grip...
- Page 46 12530 Ride On Mower WE12530 REPAIR PARTS MOWER HOUSING...
- Page 47 12530 Ride On Mower WE12530 REPAIR PARTS MOWER HOUSING PART NO DESCRIPTION PART NO DESCRIPTION WE‐37x111 Blade Drive Belt WE‐009x42 Shoulder Bolt WE‐1401092 Input Pulley WE‐030x20 Cotter Pin WE‐15x140 Locknut WE‐1401185E701 Brake Arm Assembly WE‐015x98 Flange Nut WE‐1401119 Idler Arm Link WE‐1401252 Idler Pulley WE‐0025x7 Bolt WE‐015x84 Flange Nut WE‐1401052E701 Brake Mounting Bracket WE‐1401031E701 Rear Arm WE‐1401094 Jackshaft Spacer WE‐015x79 Flange Nut WE‐1401259 Z Idler Mounting Plate WE‐009x58...
- Page 48 12530 Ride On Mower WE12530 REPAIR PARTS ELECTRICAL SYSTEM...
- Page 49 12530 Ride On Mower WE12530 REPAIR PARTS ELECTRICAL SYSTEM PART NO DESCRIPTION WE‐250x145 Chassis Wire Harness WE‐1001995 Ignition Switch WE‐327349 Ignition Key WE‐094136 Limit (PTO) Switch WE‐302031 Fuse WE‐407078 Fuse Holder WE‐1002004 Solenoid WE‐26x229 Mounting Screw WE‐15x116 Locknut WE‐024x37 Battery Ground Cable WE‐23x229 Ground Cable Screw WE‐021075 Battery Ground Cable WE‐960604 Battery Terminal Cover WE‐002x82 Carriage Bolt WE‐014x79 Wingnut WE‐024273 Select Reverse Switch WE‐26x270 Mounting Screw WE‐094159...
-
Page 50: Index
INDEX Storage, 34 Mulcher Cover, Remove, 19 Throttle Control, 16 Adjustments Blade Rotation Control, 25 Clutch, 26 Filter, Fuel, 28 Check, 20 Drive Brake, 26 Type, 20 Fuel, Type, 20 Mower Housing, Level, 29 Operation Shift Lever, 27 Fuse, 34 Attachments, 15 Attachments, 15, 52 Blade Control Lever, 16... - Page 51 EC Declaration of Conformity We, Importer Handy Distribution SN3 4NS Declare that the product Designation: RIDE-ON LAWNMOWER Model: WE12530 Complies with the following directives: 2006/42/EC- Machinery Directive (Not Annex IV Equipment) The conformity assessment procedure followed was in accordance with Council Directive 2006/42/EC.
