Summary of Contents for Westinghouse WDE147WA
- Page 1 USER MANUAL ELEVATED COOKING APPLIANCES WDE147WA, WDE135WA, WDG103WB, WDG101WB...
-
Page 2: Table Of Contents
Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Westinghouse manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING TIPS & INFORMATION WARNING IMPORTANT To avoid an electric shock or fire Check for any damage or marks • This appliance is NOT intended for use by persons (including children) with reduced physical, sensory If you find the appliance is damaged or marked, you must or mental capability, or lack of experience and report it within 7 days if you wish to claim for damage/ knowledge, unless they have been given supervision... - Page 4 IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) WARNING WARNING WARNING WARNING Grill warnings Hotplate and burner warnings • DO NOT leave grill on unattended. • DO NOT allow pots to boil dry, as damage to the hotplate (and pan) may result. • Fat left on a grill dish is a fire hazard! Keep grill clean and turn off grill immediately after use.
-
Page 5: General Appliance Description - Electric Elevated
GENERAL APPLIANCE DESCRIPTION – ELECTRIC ELEVATED (R.H VARIANT SHOWN) Grill Door Oven Vent Removable Grill Dish Fan and Element Cover Control Panel Oven Element Hotplate Anti-tilt Plate Grill Reflector Oven Fan Grill Element Removable Shelf Grill Vent Removable Inner Glass 3 Button Programmable Clock Oven Door PRODUCT DESCRIPTION... -
Page 6: General Appliance Description - Gas Elevated
GENERAL APPLIANCE DESCRIPTION – GAS ELEVATED (R.H VARIANT SHOWN) Grill Door Fan Cover Removable Grill Dish Anti-tilt Plate Grill Burner Reflector Oven Fan Removable Hotplate Burner Oven Burner Cover Removable Trivet Removable Shelf Grill Vent Removable Inner Glass Grill Burner Oven Door Oven Vent PRODUCT DESCRIPTION... -
Page 7: Installing The Electric Elevated Cooker
INSTALLING THE ELECTRIC ELEVATED COOKER Safety Warnings about installation • In order to avoid overheating of the cooker, the cooker must not be installed behind a decorative door WARNING WARNING • The appliance MUST be installed using the flexible hose supplied. •... - Page 8 TEMP MODEL RATING SECTION RATING (AMPS) (°C) WDE135WA WDE147WA Gland • A functional switch MUST be provided near the appliance in an accessible position (AS/NZS3000 – Clause 4.7.1). • Wiring MUST be protected against mechanical failure (AS/NZS3000 – Clause 3.9).
-
Page 9: Installing The Gas Elevated Cooker
INSTALLING THE GAS ELEVATED COOKER Safety Warnings about installation • In order to avoid overheating of the cooker, the cooker must not be installed behind a decorative door. WARNING WARNING • The appliance MUST be installed using the flexible hose supplied. •... - Page 10 INSTALLING THE GAS ELEVATED COOKER (CONTINUED) Gas requirements The cooker also comes supplied with a propane gas conversion kit, should you need to convert the gas from This appliance must be installed by an authorised person, NG to propane. Alternatively, you can obtain these by according to all codes and regulations of: contacting the Customer Care Centre.
-
Page 11: Control Panel
INSTALLING THE GAS ELEVATED COOKER Gas connection Operation on SNG Read these points before connecting to the gas supply: • If the cooker is to be used with SNG, then the grill burner MUST be modified by the replacement of the •... -
Page 12: Hotplate
INSTALLING THE GAS ELEVATED COOKER (CONTINUED) Checking the gas supply Testing Burner Performance Check the manometer zero point is correct. • Observe the flame appearance on each burner when set to max. If it is smaller or larger than expected, Connect the manometer to the cooker pressure then the injector size needs checking (refer to table). -
Page 13: Operating For The First Time
OPERATING FOR THE FIRST TIME Installation and Service Warning Before operating first time TIPS & INFORMATION Read all the Warning and Safety information. WARNING WARNING Remove all internal boxes and bags from oven. • Only an authorised person must install and service this appliance (Certificate of Compliance Clean out the oven interior with detergent and warm to be retained). -
Page 14: Installing Your Oven Accessories
INSTALLING YOUR OVEN ACCESSORIES Fitting oven shelves Fitting the grill dish Ensure shelf orientation is correct (refer to diagram). Ensure rear of the dish is engaged with the side support before sliding backwards. To remove simply pull forwards Slide oven shelves onto oven supports (side runners) and upwards. -
Page 15: Using The Electric Elevated Cooker
WDG103WA USING THE ELECTRIC ELEVATED COOKER Electric oven features and descriptions Ceramic hotplates fan force oven model WDE147WA WDE147WA WDG101WA Solid hotplate fan forced oven model WDE135WA WDE135WA Radiant/Solid/Ceramic Hotplate Control Knob Timer 60 Minute – (where fitted) sets reminder time. -
Page 16: Button Programmable Clock
USING THE ELECTRIC ELEVATED COOKER (CONTINUED) Ceramic Hotplates Cookware For best cooking results with electric ovens, silver or shiny trays are recommended. WARNING WARNING NOTE: Three button timer models MUST have clock set If the surface is cracked, switch off the appliance to after a power outage to operate oven. - Page 17 To check or cancel settings Setting the cooking duration • To check your settings, press the MODE button until • Select the desired oven function and temperature. the indicator you want is flashing. • The oven indicator light will glow and the heating •...
-
Page 18: Using The Gas Elevated Cooker
USING THE GAS ELEVATED COOKER Gas oven features and Descriptions Fan Forced Oven Model WDG103WA oven model WDG101WA Burner Control Knob – sets burner temperature. Oven Piezo Ignitor – ignites oven burner when appropriate control knobs are set. Grill Control Knob – sets grilling temperature. Grill Piezo Ignitor –... - Page 19 Gas oven conventional baking Gas hotplate The heat comes from the bottom oven burner. The Ensure burner caps, crowns and trivets are properly temperature at the centre of the oven is the same assembled. temperature set on the control knob. When oven is used Burner cap and burner crown must be clean and located on this mode, shelf position is important, (refer to ‘Oven correctly for the burner to light.
-
Page 20: General Hints And Tips
USING THE GAS ELEVATED GENERAL HINTS AND TIPS COOKER (CONTINUED) WARNING CAUTION Grill Ignition – Electronic Using the Grill While pressing the electronic ignitor switch, depress the corresponding knob fully and while continuing to depress • Grill with door open. the knob for approximately 5 seconds, turn anti-clockwise to ‘HI’... -
Page 21: Getting To Know Your Oven
GETTING TO KNOW YOUR OVEN Using the Conventional Oven Getting to know your new oven with this simple ‘Test Cake’ • The shelf position is critical. The temperature in centre of the oven is the temperature shown on the When baking, it is normal to experience some slight oven control knob. -
Page 22: Oven Guide
OVEN GUIDE The following is intended as a guide. Cooking variation is natural and to be expected. You should experiment with times, temperatures and recipes to obtain the best results to your own taste. Get to know your oven before making a service call. -
Page 23: Cleaning And Caring For The Elevated Cooker
CLEANING AND CARING FOR THE ELEVATED COOKER Ovens and hotplates are made from steel and enamel. Ceramic Hotplates Do not use abrasives and harsh scourers as they may Remove all spilt food with a razor blade scraper while the scratch the surface. hotplate is still warm –... - Page 24 CLEANING AND CARING FOR THE ELEVATED COOKER (CONTINUED) Cleaning the Oven Door Re-Assembling the oven door inner glass This product has a removable inner glass door for ease of • Position the inner glass back onto the door. cleaning. • The Electric elevated has a heat reflective coating on the inner glass.
-
Page 25: Trouble Shooting
TROUBLE SHOOTING PROBLEM CAUSES WHAT TO DO Select shelf that puts food in centre Incorrect shelf position of oven Oven tray too large Try other trays or dishes Uneven cooking Trays not in centre Put trays in centre Air flow in oven uneven Rotate food during cooking Remove grill tray from oven on Grill tray affecting thermostat... - Page 26 TROUBLE SHOOTING If you have a problem with your appliance check the following before you ring the service line. PROBLEM WHAT TO DO Check the electricity is turned on Check your fuses. If the fuse continues to blow, call the Service Centre Check the circuit breaker Ensure correct knob is turned Operational problems...
-
Page 27: Gas Conversion Procedure
GAS CONVERSION PROCEDURE Turn off gas supply to appliance. necessary to repeat the checks whilst measuring both the inlet and outlet pressure to determine if Disconnect appliance from electrical power (if the inlet pressure is in the range 2.75-7.00kPa. applicable). •... -
Page 28: Covert Ng Regulator To Suit Propane Gas
CONVERT NG REGULATOR TO SUIT PROPANE GAS Top hat nut assembly, fully Turn top hat nut Configuration for screwed down anti-clockwise and remove Natural Gas Configuration for Propane INJECTORS NATURAL GAS PROPANE Large hotplate burner 1.60 mm 0.95 mm Medium hotplate burner 1.35 mm 0.82 mm Small hotplate burner... -
Page 29: Notes
NOTES NOTES... - Page 30 NOTES NOTES...
-
Page 31: Warranty
(c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004... - Page 32 NEW ZEALAND phone: 0800 10 66 10 email: customercare@electrolux.co.nz web: westinghouse.co.nz Westinghouse. We are part of the Electrolux family. Share more of our thinking at electrolux.com.au and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license. All Rights Reserved.
