  • Page 1 Accessories for stand-alone grid inverter BATFUSE Technical Description BATFUSE-TEN082310 | 98-2004410 | Version 1.0...
  • Page 3: Table Of Contents

    SMA Solar Technology AG Table of Contents Table of Contents Notes on this Manual......5 Validity .
  • Page 4 Table of Contents SMA Solar Technology AG Electrical Connection ......19 BatFuse A.01 and BatFuse A.03 ..... . . 20 BatFuse B.01 and BatFuse B.03 .
  • Page 5: Notes On This Manual

    SMA Solar Technology AG Notes on this Manual 1 Notes on this Manual The external DC fuse BatFuse is available in four different models. The BatFuse A.01 and A.03 are suitable for connection to the Sunny Island 2224. BatFuse models B.01 and B.03 are suitable for all Sunny Islands.
  • Page 6: Symbols Used

    SMA Solar Technology AG Notes on this Manual 1.4 Symbols Used The following types of warning messages are used in this document: DANGER! DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury! WARNING!
  • Page 7: Safety Instructions

    8 A secured battery tap that can be used, for example, to supply DC-fed consumers. You can also connect multiple devices in parallel. You can obtain the following specifications from SMA Solar Technology AG : For the connection of one Sunny Island BatFuse A.01-0...
  • Page 8: General Safety Notices

    SMA Solar Technology AG Safety Instructions Principle of DC Wiring with a BatFuse You can connect three inverters, two batteries, and up to four charge controllers to the BatFuse B.03. Sunny Island 5048 BatFuse B.03 Battery Charge controller 2.2 General Safety Notices...
  • Page 9: Unpacking

    SMA Solar Technology AG Unpacking 3 Unpacking 3.1 Packing List BatFuse A.01 BatFuse A.01 DC fuse box Wall mounting plates Replacement fuses (NH00 125 A) installation guide BatFuse A.03 BatFuse A.03 DC fuse box Wall mounting plates Replacement fuses (NH00 125 A) installation guide BatFuse B.01...
  • Page 10: Check For Transport Damage

    Ensure that all parts are included in the delivery (see section 3.1 "Packing List" (Page 9)). If something is missing or if the BatFuse was damaged during shipping, immediately call SMA Solar Technology AG . For more information, please see section 8 "Contact" (Page 30).
  • Page 11: Identification Of The Batfuse

    SMA Solar Technology AG Unpacking 3.3 Identification of the BatFuse You can identify the DC fuse through the type label. The type label can be found inside the housing. BatFuse A.01 BatFuse A.03 Technical Description BATFUSE-TEN082310 Page 11...
  • Page 12: Batfuse B.01

    SMA Solar Technology AG Unpacking BatFuse B.01 BatFuse B.03 The nominal current strength (I ) and voltage (V ) are dependent upon the utilized Sunny Island. V lies in the range 12 - 48 V; I in the range 125 - 250 A.
  • Page 13: Mounting

    SMA Solar Technology AG Mounting 4 Mounting 4.1 Dimensions 4.1.1 BatFuse A.01 4.1.2 BatFuse A.03 Technical Description BATFUSE-TEN082310 Page 13...
  • Page 14 SMA Solar Technology AG Mounting 4.1.3 BatFuse B.01 4.1.4 BatFuse B.03 Page 14 BATFUSE-TEN082310 Technical Description...
  • Page 15: Observe Minimum Clearances

    SMA Solar Technology AG Mounting 4.2 Observe minimum clearances Observe the following minimum clearances when mounting the BatFuse. These apply to all housing types. 4.3 Wall Mounting WARNING! Fire and explosion hazard. Do not mount the BatFuse • on flammable construction materials, •...
  • Page 16: Batfuse A.01 And Batfuse A.03

    SMA Solar Technology AG Mounting 4.3.1 BatFuse A.01 and BatFuse A.03 Mount the BatFuse on the wall. Proceed as follows: Remove the lid. There are two options for aligning the mounting plates (see the following illustrations): BatFuse A.01 190 mm...
  • Page 17 SMA Solar Technology AG Mounting BatFuse A.03 345 mm 370 mm Insert wall mounting plates. Mark drill holes on the wall. Drill holes and insert wall anchors. Fasten housing on the wall. Technical Description BATFUSE-TEN082310 Page 17...
  • Page 18: Batfuse-B.01 And Batfuse-B.03

    SMA Solar Technology AG Mounting 4.3.2 BatFuse-B.01 and BatFuse-B.03 Mount the BatFuse on the wall. Proceed as follows: There are three options for aligning the mounting plates (see the following illustrations): BatFuse B.03 BatFuse B.01 Mark drill holes on the wall.
  • Page 19: Electrical Connection

    Information Use the preassembled cables from SMA Solar Technology AG for the connection of the charge controllers. They are available in lengths of 3 m, 6 m or 9 m with M8 pipe cable lugs.
  • Page 20: Batfuse A.01 And Batfuse A.03

    SMA Solar Technology AG Electrical Connection 5.1 BatFuse A.01 and BatFuse A.03 BatFuse A.01 BatFuse A.03 Maximum number of terminals: 2 x M32 2 x M32 and 2 x M25 Battery side per pin per pin Maximum number of terminals:...
  • Page 21 SMA Solar Technology AG Electrical Connection Guide the cables into the housing through the double membrane adapters. Attach suitable pipe cable lugs to the exposed cable ends. Connect the Sunny Island to the top side of the BatFuse and the battery and charge controller to the bottom side.
  • Page 22: Batfuse B.01 And Batfuse B.03

    SMA Solar Technology AG Electrical Connection 5.2 BatFuse B.01 and BatFuse B.03 BatFuse B.01 BatFuse B.03 Maximum number of terminals: 1 x M 32 and 2 x M 25 2 x M 32 and 4 x M 25 Battery side...
  • Page 23 SMA Solar Technology AG Electrical Connection First connect potential consumers to the battery voltage tap. Sunny Island side Battery voltage tap Battery side Cut and strip the battery cables as well as the charge controller cables. Guide the cables into the housing through the double membrane adapters.
  • Page 24: Using Or Replacing Nh Fuses

    SMA Solar Technology AG Electrical Connection Connect the Sunny Island to the top side of the BatFuse and the battery and charge controller to the bottom side. Screw the pipe cable lugs to the appropriate connection terminals and tighten each screw at 20 Nm.
  • Page 25: Batfuse A.01 And Batfuse A.03

    SMA Solar Technology AG Electrical Connection 5.3.1 BatFuse A.01 and BatFuse A.03 DANGER! Risk of lethal electric arcs • Always pull and insert NH fuses with an NH handle (as per DIN VDE 0680-4). Inserting First place the bottom of the NH fuse on the bracket using the NH handle (as per VDE 0680-4).
  • Page 26: Batfuse B.01 And Batfuse B.03

    SMA Solar Technology AG Electrical Connection Replacement Pull the NH fuse plugs from the bracket using the NH handle (as per VDE 0680-4). Remove the defective NH fuse. Insert the new NH fuse; see "Inserting" (Page 25). Put the lid on and lock it.
  • Page 27 SMA Solar Technology AG Electrical Connection Replacement Press the NH fuse downwards. Then pull the NH fuse from the bracket. Remove the defective NH fuse. Insert the new NH fuse, see "Inserting" (Page 26) . Put the lid on and lock it.
  • Page 28: Opening And Closing

    SMA Solar Technology AG Opening and Closing 6 Opening and Closing The housing of the BatFuse has a removable lid. Only remove the lid when mounting the device, when separating the Sunny Island from the battery, or when replacing the NH fuses.
  • Page 29: Technical Data

    SMA Solar Technology AG Technical data 7 Technical data BatFuse A.01 and BatFuse A.03 BatFuse A.01 BatFuse A.03 Output values Nominal DC voltage Sunny Island 2224 24 V 24 V Rated DC current Sunny Island 2224 125 A 125 A...
  • Page 30: Contact

    SMA Solar Technology AG Contact 8 Contact If you have technical problems concerning our products, contact the SMA Service Line. We require the following information in order to provide you with the necessary assistance: • BatFuse serial number • Connected inverters •...
  • Page 31 The information contained in this document is the property of SMA Solar Technology AG. Publishing its content, either partially or in full, requires the written permission of SMA Solar Technology AG. Any internal company copying of the document for the purposes of evaluating the product or its correct implementation is allowed and does not require permission.
  • Page 32 SMA Solar Technology AG www.SMA.de Sonnenallee 1 34266 Niestetal, Germany Tel.: +49 561 9522 4000 Fax: +49 561 9522 4040 E-Mail: Vertrieb@SMA.de Freecall: 0800 SUNNYBOY Freecall: 0800 78669269...
