- Page 1 MCB 115 Programmable I/O Option Module Instructions TR200 BAS-SVX34A-EN BAS-SVX34A-EN May 2009...
- Page 2 Support the Extended PI controllers with I/Os for setpoint inputs, transmitter/sensor inputs and outputs for actuators. • Digital output used for either driving a relay, input to commonly used PLC I/O card or as input to another drive in a sequential controlled application. TR200 MCB 115 Programmable I/O Option Module...
- Page 3 This option has three outputs which can work as voltage 0-10V or 2-10V, current 0-20 mA or 4-20 mA or digital output. The analog inputs can be used for reference or process feedback for all the PID controllers. TR200 MCB 115 Programmable I/O Option Module...
- Page 4 Max cables length for temperature sensors, is 50 metres non-screened / non-twisted wires. Cable im- pedance should be kept low as every 3.85 Ω in cable will give a misreading of 1 Kelvin. TR200 MCB 115 Programmable I/O Option Module...
- Page 5 Follow proper lock-out/tag-out procedures to ensure the power cannot be inadvertently energized. For frequency converters or other energy storing components provided by Trane or others, refer to the appropriate manufacturer’s literature for allowable waiting periods for discharge of capacitors. Verify with an appropriate voltmeter that all capacitors are discharged.
- Page 6 Connect the control cables and relieve the cable by the enclosed cable strips • Fit the cradle • Fit the keypad A2, A3 and B3 enclosures A5, B1, B2, B4, C1, C2, C3, C4, D, E and F enclosures TR200 MCB 115 Programmable I/O Option Module...
- Page 7 May 2009 Supersedes www.trane.com For more information, contact your local Trane Trane has a policy of continous product and product data improvement and reserves the right to change design and specifications without notice. office or e-mail us at comfort@trane.com 130R0486...
