Intercoax 01R-ECP Quick Start Manual page 2

[Simply IP and PoE over Coax]
ECP-01T
PoE
Camera
ECP-01T
PoE
Camera
ECP-01T
PoE
Camera
[High Power over Coax]
ECP-01T
PoE
Camera
ECP-01T
PoE
Camera
ECP-01T
PoE
Camera
[Extra PoE (60W) over Coax]
PoE
ECP-01T
Camera
PoE
ECP-01T
Camera
PoE
ECP-01T
Camera
Specification
Model
Coax
Interface
Ethernet
Transmission Rate
Ethernet
Transmission
Distance
PoE (PoC)
Ethernet
LED
Indication
Power
Input B-Linx or DC48V~57V
Power
PoE Output
with 57V Power Adaptor
Dimension
Mechanical
Weight
Operating
Temp
Storage
Environment
Temp
Relative
Humidity
Certification
Compliance
Surge
IEC 61000-4-5 4kV(1.2 / 50us), 2kA(8 / 20us)
Protection
Optional Accessories
57V DC/1.2A Power Supply
(Sold Separately)
57V DC/1.2A Power Supply
(Sold Separately)
57V DC/1.2A Power Supply
(Sold Separately)
ECP-01T ECP-01R
1 x 75Ω BNC (Female)
- Ethernet over Coax (B-LinX)
1 x RJ45 - 100 Base-T
100Mbps Full Duplex
(100Mbps between Intercoax devices)
up to 400meter (RG-59, RG-6)
up to 400meter (RG-59, RG-6)
1 x Data (Amber)
1 x Power On (Green)
PoE Switch or
DC48V~57V
IEEE802.3af (PoE),
PoE Not
IEEE802.3at (PoE+),
Supported
Extra PoE up to 60W
PoC Only
83(L) x 51(W) x 24(H)mm
52g
-20 ~ 60°C
-30 ~ 80°C
10% ~ 90%
FCC, CE, KC, RoHS
57VDC / 1.2A External Power Supply
Applications
Coaxial Cable
Coaxial Cable
Coaxial Cable
Coaxial Cable
Coaxial Cable
Coaxial Cable 57V DC/1.2A Power Supply
(Sold Separately)
57V DC/1.2A Power Supply
(Sold Separately)
57V DC/1.2A Power Supply
(Sold Separately)
Coaxial Cable
Coaxial Cable
Coaxial Cable
 DO NOT USE Non-PoE camera on Tx. (PoE IP Camera Only)
 Please install the device following the installation guide.
 Do not touch the device and cable with wet hands.
 Keep away from moisture and shock.
 Do not install near any heat sources such as radiators, heat
registers, stoves or other apparatus that produce heat.
 Indoor use only. (Use waterproof junction box when it is used in
outdoor)
 Do not use for other purposes.
 Do not disassemble or modify this device.
 Do not put any sticker or paint on it.
 If this device is defective or malfunctioning, please unplug the power
source immediately and contact dealer or service center.
 Please use the rated power supply for the product.
 Connect DC power to this device first and then to AC outlet.
 This device has passed the quality control and product inspection.
 Please install and use according to the installation guide.
 The warranty period for this product is 24 months from the date of
purchase.
 If this device is defective or malfunctioning, please unplug the power
adapter immediately and contact dealer or service center.
 Any damages or breakage from user's abuse, accident, modification
or natural disasters will not be covered manufacturer's warranty.
This device complies with part 15 of the fcc rules. Operation is subject to the
following two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference
that may cause undesired operation
PoE NVR
PoE NVR
PoE NVR
ECP-01R
ECP-01R
ECP-01R
NVR
NVR
NVR
ECP-01R
ECP-01R
ECP-01R
PoE NVR/NVR
PoE NVR/NVR
PoE NVR/NVR
ECP-01R
ECP-01R
ECP-01R
Caution
Warranty
Please visit below website for more detailed information.
Web: http://www.intercoax.com Tel: +82. 31. 365. 3133~4
E-mail: info@intercoax.com Fax: +82. 31. 365. 3135
