Owner and installer guide
Rinnai Smart Cylinders™
Low-medium pressure indoor stainless steel
Models: Rinnai Smart Cylinders: Low-medium pressure duplex stainless steel
(LS13555030S, LS18055030S, LS25055030S)
Hello installer
Please leave this guide with the home owner as it contains important safety
and warranty information.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rinnai Smart Cylinders LS13555030S
Summary of Contents for Rinnai Smart Cylinders LS13555030S
- Page 1 Owner and installer guide Rinnai Smart Cylinders™ Low-medium pressure indoor stainless steel Models: Rinnai Smart Cylinders: Low-medium pressure duplex stainless steel (LS13555030S, LS18055030S, LS25055030S) Hello installer Please leave this guide with the home owner as it contains important safety and warranty information.
- Page 2 For more information about buying, using, and servicing of Rinnai appliances call: 0800 RINNAI (0800 746 624) Rinnai New Zealand Limited 105 Pavilion Drive, Mangere, Auckland...
-
Page 3: Table Of Contents
About your Rinnai Smart Cylinder ....4 Maintenance and servicing ......7 Troubleshooting ..........8 Installation Specification summary ........12 Dimensions ............13 Plumbing setup ..........14 Storage and delivery temperatures ....15 Water quality ........... 16 Electrical supply and connections ....17 Valves and fittings ........... -
Page 4: About Your Rinnai Smart Cylinder
Your Rinnai Smart Cylinder comes factory preset to operate in automatic mode at a level setting of three. We recommend staying with this setting to achieve a balance between running cost savings and ensuring you have enough hot water. - Page 5 Clause G12.3.9 Legionella is a bacterium that can cause Legionnaires’ disease―a severe form of pneumonia Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 5...
- Page 6 Any work carried out by a - cold water expansion valve non-licensed tradesperson - tempering valve is illegal and will void any - energy cutout thermostat warranty. 6 | Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15...
-
Page 7: Maintenance And Servicing
Rinnai product. Regular maintenance and servicing is not covered by the Rinnai warranty. For help locating a service person in your area call 0800 RINNAI (0800 746 624). Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 7... -
Page 8: Troubleshooting
Most hot water cylinders are controlled at peak times by your electricity supplier via a ripple relay. Contact your electricity supplier to determine if there have been any issues with the power supply. 8 | Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15... - Page 9 If you reset during normal operation it will lose all the water usage history as well as the memory setting and will default back to the preset factory setting of iQ automatic mode, level setting three. Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 9...
- Page 10 This page intentionally left blank...
-
Page 11: Installation
Installation Installation, servicing and repair shall be carried out only by authorised personnel. -
Page 12: Specification Summary
Maximum working pressure = 120 kPa Element 3 kW Incoloy 825 alloy sheath element positioned at the bottom of the tank. Incoloy 825 curved element Cotherm thermostat with control 12 | Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15... -
Page 13: Dimensions
& eco solar Element Top view * B measurement - eco inlet is not applicable for Rinnai Smart Cylinders as system is not suitable for connecting to open loop solar or hot water heat pump systems. Tank size A (mm) B (mm) C (mm) Height (mm) Diam. -
Page 14: Plumbing Setup
Drip tray non-return valve, and a line strainer To drain The appliance is not intended to be connected by a hose-set. 14 | Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15... -
Page 15: Storage And Delivery Temperatures
Drip tray/catch pan (MUST be fitted) The Rinnai warranty does not cover any consequential loss from leaks to the cylinder, so it’s important a suitably drained drip tray/catch pan is fitted. Position of control Make sure the control is in a position that is easily seen and accessible for the homeowner. -
Page 16: Water Quality
The higher the PREN number the greater the resistance. In comparison 304 grade stainless, which is commonly used in domestic cookware and kitchen sinks, has a PREN number of 19. This means that Rinnai stainless steel tanks are highly resistant to pitting corrosion, but not completely immune from it. -
Page 17: Electrical Supply And Connections
The appliance is intended to be connected to cables of fixed wiring which has a cross-sectional area of 1.5 mm - 2.5 mm Element Thermostat Terminal Block Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 17... -
Page 18: Valves And Fittings
Failure to allow air into the water heater may cause the tank to implode WARNING when you drain it. 4. Open the drain valve and drain the cylinder—make sure no damage will occur from discharged water. 18 | Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15... -
Page 19: Limited Warranty
Except for certain travel and transport costs, refer to the ‘Warranty terms and conditions’ (9). Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 19... - Page 20 8. Rinnai reserve the right to have the installed product returned to the factory for inspection. 9. Where the cylinder is installed outside the metropolitan area or further than 40 km from a Rinnai authorised service centre, travel costs shall be the owner’s responsibility.
- Page 21 Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 21...
-
Page 22: Warranty Examples In The Real-World
If damage is caused by a leaking cylinder that has not been installed with a drip tray the owner can seek compensation through the installer or consider claiming on insurance. 22 | Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15... -
Page 23: Proof Of Purchase
Product details: Please keep these details in a safe place for future reference. Installer details Company name: Installer name: Address: Phone: Mobile: Signed: Date: Rinnai Smart Cylinders low-medium pressure indoor stainless steel: Owner and installer guide: 20432-A 01-15 | 23... - Page 24 Experience our innovation Rinnai.co.nz 0800 746 624 http://www.youtube.com/rinnainz 20432-A http://www.facebook.com/rinnainz...
