3.3 INLETS AND OUTLETS

The standard Monsoon Monitor inlet is CODE-RPF for direct connection to TFT's Extend-A-Gun RC4 (4 inch size). Monitor inlet CODE-
RLF is available for direct connection to Extend-A-Gun RC3 (3 inch size). The standard outlet is 3.5"-6 National Hose male. Various
other inlet and outlet adapters are available as shown in figure 3.3A.
MONITOR MOUNTED
CONTROL STATION
3" ANSI 150 (Y4410A)
OR
4" ANSI 150 (Y4415A)
OR
DN80 PN16 (Y4423A)
OR
DN100 PN16 (Y4425A)
FLANGE OUTSIDE
SIZE DIAMETER
3" ANSI 150 7.50"
4" ANSI 150 9.00"
DN80 PN16 200 mm
DN100 PN16 220 mm
CODE-RLF
OR
CODE-RPF
INLET
3" BSP MALE (Y4420A)
OR
4" BSP MALE (Y4430A)
THICKNESS BOLT HOLE
CIRCLE
.75"
.94"
22 mm 160 mm
22 mm 180 mm
3" NPT FMALE (Y4440NL)
OR
4" NPT FEMALE (Y4450NP)
NUMBER
OF BOLTS
6.00" 4
7.50" 8
8
8
Fig 3.3A
Inlets and Outlets
7
3.5" BSP MALE (Y4330ABN)
3.5" NH MALE (STANDARD)
3.5" NPSH MALE (Y4330AIN)
4.0" BSP MALE (Y4334ABP)
EXTEND-A-GUN RC3
OR
EXTEND-A-GUN RC4
SIZE OF TORQUE
BOLTS ON BOLTS
5/8" 76-80 FT-LBS
5/8" 76-80 FT-LBS
16 mm 100-110 NEWTON-METER
16 mm 100-110 NEWTON-METER
