5. SUPPORT
• Construction......................................... Orange shockproof polycarbonate lens and black polyamide base.
What to do if...?
• Mounting............................................... Wall mounting bracket.
• Protection Index.................................... IP 54, IK 07.
• Dimensions........................................... Control box: L250 x W195 x D97,5 mm.
No broadcasting flash
• Dimensions entered by cables............... PG11 cable gland for power cable.
• Operating temperature range................ -20 to +50°C.
• Power supply......................................... 100 to 240VAC (± 10%) - 50/60Hz.
No DHCP server on the
• Consumption......................................... 0,5A at 230VAC.
network
• Electrical insulation.............................. Class I.
• Power supply connections.................... 2 terminals - N (neutral) and L (phase) for 2.5mm² max. wires.
• D istance between the controller and
the beacon............................................ 5 meters (the cable is supplied).
Harmonys does not
broadcast any sflash
14
1) The multicast address is identical between the master clock and Harmonys.
The information sign: 200 x 200, 4 mm thick.
2) Network parameters are compatible: Harmonys must be on the same Ethernet
The beacon: - Diameter: 105 mm.
network as the computer with the Sigma software.
- Weight: 690 gr.
- Lamp: H1 (70 W).
PG7 cable gland for beacon and Ethernet cables.
1) By default the Harmonys takes on the following IP setting (after 3min):
- IP: 192.192.223.100 (1st sounder), 192.192.222.101 (2nd
- MASK: 255.255.0.0
- Gateway: 0.0.0.0
- DNS: 0.0.0.0
(After 15 minutes, the sounder asks an address DHCP server).
2) U sing the Sigma software (Configuration> IP devices> Network button) to set the
network settings Harmonys (product identification with the MAC address on the tag
on the back of the product).
1) The length of the cable is lower than 100 meters (refer to the standards of network
cabling).
2) Harmonys sounder is on the broadcast area of the master clock Sigma.
3) The multicast address is identical between the master clock and Harmonys.
4) The version firmware of the switch is up to date.
... Check
sounder), etc.
EN
