NESS
PRODUCT INSTALLATION GUIDE
CONTENTS
Access Control
1-14
15-19
20-26
27-35
36-42
43-55
56
9.1-9.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDTeck FGR006 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ness IDTeck FGR006

Summary of Contents for Ness IDTeck FGR006

  • Page 1: Table Of Contents

    NESS Access Control PRODUCT INSTALLATION GUIDE CONTENTS 1. PRODUCT CATALOG 2. WIRING & INITIAL SETTING 1-14 3. INSTALLATION TIPS & CHECK POINT 15-19 4. SERIAL COMMUNICATION SETUP 20-26 5. LAN COMMUNICATION SETUP 27-35 6. DIAL-UP COMMUNICATION SETUP 36-42 7. DOOR LOCK INSTALLATION 43-55 8.

  • Page 2: Product Catalog

    Chapter PRODUCT CATALOG...

  • Page 3: Wiring & Initial Setting

    Chapter WIRING & INITIAL SETTING...
  • Page 4 2.WIRING & INITIAL SETTING 2-3. Ness - IDTeck FGR006 2-3-1. Star FGR006 Connection Diagram RS232 RS485 RS422 Wiegand ABA Track II Beep Control Blue LED Control Brown 485B Yellow 485A Gray Orange DATA-1 White DATA-0 DATA Green +12V DC +12V DC...
  • Page 5 NESS - IDTEck PRODUCT INSTALLATION GUIDE 2-4 NESS - FGR006SRB 2-4-1 FGR006SRB System Diagram Red Wire (+12V) DC12V Power Supply Black Wire (GND) Green Wire (Wiegand Data-0) White Wire (Wiegand Data-1) Access Control Panel (26-bit Wiegand) iTDC iCON100 Orange Wire (Fingerprint Error)
  • Page 6 Step 2. Receiver Fingerprint Data - Send registered fingerprint data to PRG2000B Step 3. Program Smart card - Program Encrypted fingerprint data and I.D to Smart card Step 1 Step 3 Click “ Receive Fingerprint Data” Step 2 Ness - IDTECK...
  • Page 7 NESS - IDTEck PRODUCT INSTALLATION GUIDE 2-6. Ness 505R 2-6-1. Ness 505R Connection Diagram Orange Wire Exit Button B lack Wire Exit Button Y ellow Wire R ed S tripe Door Contact Door Status B lack Wire G reen Wire...
  • Page 8 2 . W IR IN G & IN ITIAL S E TTIN G 2-6-2. Ness 505R initial setting Enter 4 or 6 key : Left / Right move Default Master No M ODE SELECTION STAR 505R [F1] (00000000) 2 or 8 key : Up / Down move...
  • Page 9 NESS - IDTEck PRODUCT INSTALLATION GUIDE 2-7. Ness - IDTeck FINGER007 2-7-1. Ness FINGER007 Connection Diagram Orange Wire Exit Button Exit Button B lack Wire Y ellow Wire R ed S tripe Door Contact Door Status B lack Wire G reen Wire...
  • Page 10 2 . W IR IN G & IN ITIAL S E TTIN G 2-7-2. Ness FINGER007 Initial Setting Enter Master No 4 or 6 key : Left / Right MOVE M ODE SELECTION FINGER_007 [F1] (Default : 00000000) 2 or 8 key : Up / Down MOVE...
  • Page 11 NESS - IDTeck P R ODU C T IN S TALLATION GU IDE 2-8. NESS ICON100 2-8-1. Ness ICON100 Connection Diagram DIP SW +12V DC12V Power Supply INPUT#5 Reader 2 TTL1 Jumper TTL2 INPUT#4 INPUT#3 Relay#1 F ail S afe...
  • Page 12 2.WIRING & INITIAL SETTING 2-8-2. Ness ICON Initial Setting Enter 4 or 6 key : Left / Right MOVE Default Master No MODE SELECTION 2 or 8 key : Up / Down MOVE STAR iCON100 [F1] (00000000) MM/DD HH:MM:SS RF ONly...
  • Page 13 NESS - IDTeck P R ODU C T IN S TALLATION GU IDE 2-8-3. Ness ICON100 setting manual Before Setting, make sure all wires are correctly connected referring its connection diagram. a. B AT T E R Y J UMP E R...
  • Page 14 2.WIRING & INITIAL SETTING 2-9. NESS iTDC - 2/4 Door Controller 2-9-1. iTDC Connection Diagram Initialize S/W IN #7 Board ID S/W Relay #1 IN #6 EIO Connector Lock #1 LED 21 IN #5 Relay #2 LED 20 Alarm #1...
  • Page 15 NESS - IDTeck PRODUCT INSTALLATION GUIDE 2-9-3. Ness - iTDC initial setting Before Setting, make sure all wires are correctly connected refering its connection diagram. a. Battery Jumper iTDC has a jumper for backup battery connection, that is left open circuit to JUMPER SWITCH SETTING prevent current consumption of backup battery.
  • Page 16 2.WIRING & INITIAL SETTING 2-9-4. User ID registration 1. ID[________] : ID number consists of 3-digits “Master No” STAR iTDC [F1] Select ID Registration Facility code from 000 to 255 and 5-digits ID MM/DD HH:mm:ss (MENU F3) “00000000” number from 00000 to 65535 so that the 8-digits ID number can not exceed 25565535.
  • Page 17 Facility-code: This Facility-code is including the tag ID (first 3 digit, 000~255) ID-number: This ID-number is including the tag ID (last 5 digit, 00001~65535) 2-10-3. Application of the Ness RF500 and IDA500 for Parking controls In case, In-Gate controls by IDA500 tag...

  • Page 18: Installation Tips & Check Point

    Chapter INSTALLATION TIPS & CHECK POINT...
  • Page 19 NESS - IDTeck P R ODU C T IN S TALLATION GU IDE 3-1. Check points before installation 3-1-1 Selection of cable S ys tem ins tallation cabling will be configured as follow. F ig.1 : S ys tem Ins tallation Layout 3-1-2.
  • Page 20 4 wires RS422 system. A termination resistor of less than 90Ω should not be used and no more than 2 terminations should be used in one networking system. 3-2-2. How to connect termination resistors Fig.2 : Termination resistors for 2 wires RS485 communication system Fig.3 : Termination resistors for 4 wires RS422 communication system NESS - IDTECK...
  • Page 21 3. INSTALLATION TIP & CHECKPOINT NESS - IDTeck PRODUCT INSTALLATION GUIDE 3-2-3. Grounding system for communication cable We recommend to using proper grounding system on the communication cable. The best method for grounding system is to put the shield wire of communication cable to the 1st class earth grounding;...
  • Page 22 NESS - IDTeck PRODUCT INSTALLATION GUIDE 3. INSTALLATION TIP & CHECK POINT 3-2-4. Reverse Diode connection If you connect an inductor (Door Locks or Alarm device) to the output relays, there will be a high surge voltage created while the inductor is turning on and off. If you do not connect reverse diode, the surge voltage will transfer and damage to the electronic circuit of the controller.

  • Page 23: Serial Communication Setup

    Chapter SERIAL COMMUNICATION SETUP...
  • Page 24 NESS - IDTeck PRODUCT INSTALLATION GUIDE 4-1. CNP-200A (RS-232C TO RS-422/485 Converter) 4-1-1. Specification • Convert RS-232C signal to RS-422/485 signal • Dip switch for Multi-Drop or Point To Point communication set-up • Built-in Terminal Resistance • Built-in Surge Protector •...
  • Page 25 4. SERIAL COMMUNICATION SETUP 4-2. Connection 4-2-1. Converter and controller connection PC RS-232C CNP-200A, RS-232C Female Female 4-2-2. RS-422/485 Converter to iTDC/iCON100 Connection RS-232 To RS-422 /485 Converter Red Wire TX + White Wire TX - RS-232C HOST Blue Wire RX + Black Wire RX -...
  • Page 26 NESS - IDTeck PRODUCT INSTALLATION GUIDE 4-2-4. RS-232C Converter to Host Connection HOST RS-232C Female Converter RS-232C Female 505R 4-2-5. RS-422/485 Converter to NESS 505R/Finger007 Connection 505R Finger007 Converter 505R/Finger007 Red Wire TX + Brown Wire RX + Blue Wire...
  • Page 27 4 . S E R IAL COM M UN ICATION S E TUP 4-3. Multiple Communication Capability • If using additional Multi-port device multiple communication is available • Supported Ness Products : iTDC, iCON100, FINGER007, FGR006, 505 HOST RS422/232 Serial Converter or TCP/IP LAN Converter...
  • Page 28 NESS - IDTeck PRODUCT INSTALLATION GUIDE 4-6. Serial chain communication definition • Communication speed and communication port must be set in order to communicate with between 505R / FINGER007 system and installed program in computer by serial communication. • Click ‘Controller -> Set Serial Communication’ in menu.
  • Page 29 4. SERIAL COMMUNICATION SETUP 4-8. Serial Chain Communication Status • As shown below click on Status, scroll to Communication Status to display communication status. If communication is successful, it will display as Image. < Serial Communication OK> < Serial Communication Fail> 4-9.

  • Page 30: Lan Communication Setup

    Chapter LAN COMMUNICATION SETUP...
  • Page 31 2) LAN converter (NetEye1000S) 3) LAN converter adapter 4) 9 Pin Female Connector 5-1-2. Connection via RS232 Ness 505R, FINGER007 And 9 PIN Connector Wire Table 505R,FINGER007 WIRE 9 PIN CONNECTOR PIN CONNECTION Black wire with White stripe(TXD) Pin No 2 (RXD)
  • Page 32 Once the connection is finished, move on to the LAN converter setup section (Figure 5) 5-1-3. Connection via RS422 Ness 505R, FINGER007 and 9 PIN Connector Wire Table 505R,FINGER007 WIRE 9 PIN CONNECTOR PIN CONNECTION Gray wire(TX+) Pin No 2 (RX+)
  • Page 33 NESS - IDTeck PRODUCT INSTALLATION GUIDE b. As shown below (Figure 7) connect the gray wire c. As shown below (Figure 8) connect the brown wire to #2 on the 9 pin connector. to #3 on the 9 pin connector.
  • Page 34 (-) Black wire connection for power to (Finger007, 505R). (Figure 13) LAN Converter IP Setup (Ness NetEye1000S setup program use) CD is provided for LAN converter IP setup and checking communication activity. The application program is installed for the IP setup from the PC to LAN converter a.
  • Page 35 NESS - IDTeck PRODUCT INSTALLATION GUIDE b. Setting Up IP with Setup Program. Upon program install completion, click on Start button, scroll to Program then to NetEye1000 to start the program. Once the program starts as shown below (Figure 17), all the LAN converters’ information connected to the same network is displayed.
  • Page 36 5. LAN COMMUNICATION SETUP If you click the remote search IP button, Remote Setup Box will be displayed. Type the remote NetEye IP address and click Add button. You can input multiple remote NetEyes IP addresses. When you click OK button, It searches remote NetEyes and display them on the screen.
  • Page 37 NESS - IDTeck PRODUCT INSTALLATION GUIDE As shown below (Figure 23), follow the instructions below to setup. (Figure 20) On the LAN converter Device Info (Figure 21), follow the instructions below to setup. (Figure 21) Select the LAN converter Device ID. (The maximum number of LAN converters able to connect to the same network is 10 units.
  • Page 38 5. LAN COMMUNICATION SETUP 5. LAN COMMUNICATION SETUP PRODUCT INSTALLATION GUIDE 5-2. LAN Communication via internal module of the Ness iTDC 5-2-1. Internal Module Configuration Program using IGM7100 Tool Click Start->Program->IIM7100tool->IIM_Cfgtool to run program. Check the selected module’s IP, Subnet, Gateway, Speed, Parity, Data Bit, Stop Bit, Flow, and Listen Port then modify if necessary.

  • Page 39: Dial-Up Communication Setup

    Chapter DIAL-UP COMMUNICATION SETUP...
  • Page 40 NESS - IDTeck PRODUCT INSTALLATION GUIDE 6-1. Dial-Up Communication 6-1-1. Required Systems 1. 3Com U.S Robotics 56K Fax External Modem 2sets (Remote Site, Host Site) 2. RS422 to RS232 Converter 1ea 3. Host, Remote Serial communication Cable 2pcs 4. Dial-Up Access Control Program(505R Software V1.5) 5.
  • Page 41 6. DIAL-UP COMMUNICATION 6-2. Host Cable Connection • Connect host cable as below referring 4. Serial cable configuration of the previous page. • Connect DB 9 to COM1 Port of PC. • Connect DB25 to 25 Pin Port of Dial-up Modem. 6-2-1.
  • Page 42 NESS - IDTeck PRODUCT INSTALLATION GUIDE 6-2-7. Connect DB9-9 to DB25-22. [MODEM] [COMPUTER] [DB 9 PIN] [DB 25 PIN] 6-2-8. Connect DB9-5 to DB9-6. [COMPUTER] [DB 9 PIN] 6-2-9. Connect DB9-9 to DB25-22. [DB 25 PIN] [MODEM] 6-3. Remote Cable Connection •...
  • Page 43 6. DIAL-UP COMMUNICATION 6-3-4. Connect DB25-4 to DB25-5 [COMPUTER] [DB 9 PIN] 6-3-5. Connect DB25-6 to DB25-20 [DB 25 PIN] [MODEM] 6-4. Dial-up Modem Connection • Connect Dial-up modem referring 7. Dial-up Modem Connection Flow Diagram as below. 6-4-1. Dial-up Modem Connection Flow Diagram Host Site Host Host Computer...
  • Page 44 NESS - IDTeck PRODUCT INSTALLATION GUIDE 6-4-3. Connect DB25 PIN-A to HOST MODEM. Host [MODEM] [COMPUTER] [DB 9 PIN-A] [DB 25 PIN-A] 6-4-4. Connect via telephone HOST MODEM and REMOTE MODEM. 6-4-5. Connect DB25 PIN-B to REMOTE MODEM. 6-4-6. Connect DB9 PIN-B to CONVERTER.
  • Page 45 6. DIAL-UP COMMUNICATION On the Dial-Up Modem Connection Info (Figure 3), follow the instructions below to setup. (Figure 3) In case of using external line, checks Out Line Option, then inputs out Line number.(Defaulted value is “9”) After input Phone number to receive in Phone No. filed, click “Save” button. To try to call by modem when to call input or selected phone number, click “Connect”...

  • Page 46: Door Lock Installation

    Chapter DOOR LOCK INSTALLATION...
  • Page 47 NESS - IDTeck PRODUCT INSTALLATION GUIDE 7-1. The Installation of Ness Electro Magnetic Lock • Door can be opened and closed just to one side direction in case of EM Lock. • In case of Outswing install as follow No.1 •...
  • Page 48 7. DOOR LOCK INSTALLATION 7-1-2. How to Install in Double Door (1 Lock) (Fire Protection Door, Wood Door, Glass Door) a. Outswing Door Open “L” Bracket : It is used in “Outswing Door” • It is used in case difficult to install EM lock in door frame How to install b.
  • Page 49 NESS - IDTeck PRODUCT INSTALLATION GUIDE 7-1-3. How to Install in Double Door (2 Lock) (Fire Protection Door, Wood Door, Glass Door) a. Outswing Door Open b. Inswing Door Open IDTECK...
  • Page 50 7. DOOR LOCK INSTALLATION 7-1-4. How to Install in Double Door(2 Lock)(Fire Protection Door, Wood Door, Glass Door) Controller Lock Relay Power Fail safe type Power Fail secure type 12VDC Power Locking Device <Connection> Specification • Rated Voltage and Current : DC12V 500mA DC24V 250mA Door Contact : COM, NO, NC...
  • Page 51 NESS - IDTeck PRODUCT INSTALLATION GUIDE 7-2. The Installation of Ness Deadbolt Lock • It is installed in Tempered Glass Door. • Door can be opened and closed to both sides in case of Deadbolt Lock • Card reader or Exit button can be used for Exit.
  • Page 52 7. DOOR LOCK INSTALLATION 7-2-3. How to Install in Single Door (tempered glass door) 7-2-4. How to install Deadbolt Case for glass without frame at the top of door (tempered glass door) • Open type Deadbolt Case for glass only Upper glass Upper glass Bottom glass...
  • Page 53 NESS - IDTeck PRODUCT INSTALLATION GUIDE 7-2-5. How to Install Deadbolt Case in case frame is existed just at the bottom of door (tempered glass door) • Open Case type Deadbolt 7-2-6. Drawing and Inner Circuit Controller Lock Relay Power Fail safe type...
  • Page 54 7. DOOR LOCK INSTALLATION 7-3. The Installation of the Ness Electric Strike Lock • Electric Strike Lock has to be installed at inswing door type. For access control purpose lock has not to be opened outside. • Able to open the door by trundling cylinder of lever on exit.
  • Page 55 NESS - IDTeck PRODUCT INSTALLATION GUIDE 7-3-3. How to cut Cylinder & Lever Latch Before cutting After cutting the wing of latch the wing of latch Pull and open the door. Unable to move latch. Both sides locking state. 7-3-4. Line Drawing and Inner Circuit...
  • Page 56 7. DOOR LOCK INSTALLATION 7-4. The Installation of Electronic Hinge(TEK-9) • It is used in case of newly-built door, because hole has to be drilled before installation • In Double Door it is installed between door frame of fixed door and door •...
  • Page 57 NESS - IDTeck PRODUCT INSTALLATION GUIDE 7-5. The installation of Door Cord • Door Cord has to be installed between the door and the door frame of fixed door in Double Door. • In this case connect lock cable with lock through Door cord.
  • Page 58 7. DOOR LOCK INSTALLATION 7-7. The Installation of Exit Button • In case of using the button for exit inside the door. • Decide whether install or not as the type of Lock. • Case that exit button needs : On cutting latch of Cylinder & Lever On installation of Electro Magnetic Lock &...

  • Page 59: Power Pack Connection

    Chapter POWER PACK CONNECTION...

  • Page 60: Trouble Shooting

    Chapter TROUBLE SHOOTING...
  • Page 61 NESS - IDTeck PRODUCT INSTALLATION GUIDE 9-1. Ness 505R S ys tem operates abnormal (Cause) Of that user mistake, memory (SRAM) is damaged, or the system is defective of the device. (Solution) 1. Check BAT connection S/W (place template hole of reverse side) You have to push up the S/W, and system initialize before system installation.
  • Page 62 9. TROUBLE SHOOTING Doesn’t enter the Setup Mode after entering the Master ID “00000000”. (Cause) The Master ID might be changed or components are defective. (Solution) 1. Try changing the Master ID through the application S/W.(It’ll be changed to “00000000”.) - Note that the Master ID for iTDC-SR is 10 times <0>, “0000000000”.
  • Page 63 NESS - IDTeck PRODUCT INSTALLATION GUIDE A valid card became unregistered after batch-downloading IDs from PC. (Cause) Wrong procedure during download, or a component defect. (Solution) 1. The card ID might be registered only to the controller and not registered in PC. The process of downloading IDs, 505R first erase the ID memory of the unit, therefore if the IDs from the PC didn’t contain the card ID,...
  • Page 64 9 . TR OU B LE S H OOTIN G Unable to communicate with P C after ins tallation of device (Cause) Cable defect, Cable connection defect, address setting up error, communication port error, demagnetization defect (Solution) 1. Check cable and connection of cable(RS232, RS422). 2.
  • Page 65 PRODUCT INSTALLATION GUIDE PRODUCT INSTALLATION GUIDE 9-2. Ness FINGER007 Broken or abnormal letters show on LCD, when the power on. (Cause) Of troubles of its battery in charge of the internal back-up or of circuits near around (Solution) 1. Initialize the controller referring “hardware initialization of the manual”...
  • Page 66 9. TROUBLE SHOOTING No operation after input of card number via keypad but proper operation after input of card number via RF CARD (Cause) Of set up error or internal element defect (Solution) 1. Check buzzer sound as key pad pressed. If it makes buzzer sound, “RF_PIN_ENABLE” is set improperly as “DISABLE”.
  • Page 67 NESS - IDTeck PRODUCT INSTALLATION GUIDE 9-3. Ness - IDTEck iCON100 System operates abnormal. (Cause) Of that user mistake, memory(SRAM) is damaged, or the system is defective of the device. (Solution) 1. Check BAT connection S/W. You have to connect the S/W, and system initialize before system installation.
  • Page 68 9. TROUBLE SHOOTING Lost Master ID (Cause) Lost master ID (Solution) 1. Initialize the device. (All stored date will be lost) The reader seems to read cards, but the controller does not respond or does not respond properly, such as displaying wrong card numbers in the reader test mode. (Cause) Reader defect, wiring error between the reader and the controller, or the electric noises around.
  • Page 69 NESS - IDTeck PRODUCT INSTALLATION GUIDE At the “RF + PW” mode of ICON100, door is opened without press password at IN reader and door is opened with press password at OUT reader. (Cause) 1. Position of In/Out reader is converted.
  • Page 70 NESS - IDTeck PRODUCT INSTALLATION GUIDE 9. TROUBLE SHOOTING 9-4. Ness - IDTeck iTDC Broken or abnormal letters show on the LCD, when powered on. (Cause) SRAM backup battery problem or LCD module problem. (Solution) 1. Initialize the controller and setup the date and time on SETUP MENU F2->SYS INITIALIZE and SETUP MENU F2->TIME SETTING.
  • Page 71 NESS - IDTeck PRODUCT INSTALLATION GUIDE (Cause) Reader defect, wiring error between the reader and the controller, or the electric noises around. (Solution) 1. Be sure that the reader reads the card ID when you present a card. 2. Be sure that the reader format is correct. 26bit Wiegand or 34bit Wiegand for iTDC-SR 3.
  • Page 72 NESS - IDTeck PRODUCT INSTALLATION GUIDE 9-6. Ness - IDTeck (PDL200) Q&A No res pons e when card is pres ented (Cause) 1. Unregistered card 2. Power is not supplied due to error on sensor (Solution) 1. Register card if presented cared is not registered device.
  • Page 73 9. TROUBLE SHOOTING 9-7. Software 1. General Check Points for Ness StarWatch Software series Reporting S/W trouble to IDTECK Service center (Solution) Please check trouble shooting before reporting. Enclose the following information when you report the trouble. 1. Configuration of the system (number of controllers on a line, RS422 or TCP/IP) 2.
  • Page 74 PRODUCT INSTALLATION GUIDE Recommended configuration for system of over 60controllers (Solution) 8 ports or no less is suitable for operation. Maximum users of no less than 500 users recommended in configuration. In this case, it is good to have a separate PC to operate independently. It is recommended to use general PC mfrs and servers matching configurations below.
  • Page 75 9. TROUBLE SHOOTING TX LED of controller is not blinking. (Cause) Controller receives signal from S/W but it is not sending back to PC. Check the controller side. (Solution) 1. Check whether the board ID of in controller is accord with the board ID set in S/W. 2.
  • Page 76 NESS - IDTeck PRODUCT INSTALLATION GUIDE 4. Via TCP/IP Communication Error message ‘Can`t Create Socket Error ‘ (Cause) Unstable socket connection betw.TCP/IP Converter(Module) and PC (Solution) 1. Check Lan card of PC Lan Card to make sure the network connection of the PC.
  • Page 77 9. TROUBLE SHOOTING Properly running s/w got in to a trouble in a sudden. So it is turned off and turned on. However it is not communicating any more. (Cause) The connection betw. PC and TCP/IP Converter(Module) has not disconnected although it is not shown in screen. The S/W is still in the memory of the PC.
  • Page 78 9. TROUBLE SHOOTING NESS - IDTeck PRODUCT INSTALLATION GUIDE - TX LED of controller is not blinking. 1. Controller is not sending signal. Check the controller side. 2. Make sure the controller ID is accord to the ID set in S/W.
