- Page 1 DS-K2600 Series Access Controller Quick Setup Guide Ness V1.0...
-
Page 2: Table Of Contents
Access Controller· · · · User Manual This is a Quick Setup Guide for Ness Version of Hikvision DS-K2604 4 Door Access Controllers. For full details refer Ness Full User Manual Safety Instruction WARNING Please note: There is high voltage (240VAC) inside the housing of the controller. Extreme caution should be taken and only installed and serviced by licensed trained installers. -
Page 3: Ds-K2604 Terminal Description
Access Controller· · · · User Manual DS-K2604 Terminal Description DS-K2604 External Terminals DS-K2604 Terminal descriptions are as follows: DS-K2604 Grounding Power Supply of E-Lock +12V Power Supply of E-Lock Output Power Supply Grounding of Card Reader +12V Power Supply of Card Reader Output Grounding Wiegand Card Wiegand Card Reader Data Input Data0... - Page 4 Access Controller· · · · User Manual DS-K2604 Cresset of Card Reader Control Output (Invalid Card Output) Cresset of Card Reader Control Output (Valid Card Output) Grounding Wiegand Card Reader Data Input Data0 Wiegand Card Reader Data Input Data1 Wiegand Card Buzzer of Card Reader Control Output Reader 3 Cresset of Card Reader Control Output (Invalid...
- Page 5 Access Controller· · · · User Manual DS-K2604 E-Lock 3 Door 3 Door Relay Input (Dry Contact) E-Lock 4 Door 4 Door Relay Input (Dry Contact) Door 1 Magnetic Detector Input Signal Grounding Door 2 Magnetic Detector Input Door Magnetics Input Door 3 Magnetic Detector Input Signal Grounding...
- Page 6 Access Controller· · · · User Manual DS-K2604 Event Alarm Input 6 Grounding Event Alarm Input 5 Event Alarm Input 4 Grounding Event Alarm Input3 Event Alarm Input 2 Grounding Event Alarm Input 1 Notes: The Alarm input hardware interface is normally open by default. So only the normally open signal is allowed.
-
Page 7: Card Reader Installation
Access Controller· · · · User Manual Card Reader Installation The Connection of Wiegand Card Reader Note: Minimal wiring required is 4 Wire (+12VDC, Gnd, W0 and W1) Optionally you may connect the OK/ERR/BZ, for when wanting to control the LED and buzzer of the Wiegand card reader. -
Page 8: Activating The Access Control Terminal
Access Controller· · · · User Manual Activating the Access Control Terminal Purpose: You are required to activate the terminal first before using it. Activation via SADP, and Activation via client software are supported. The default values of the control terminal are as follows. The default IP address: 192.0.0.64. -
Page 9: Client Operation
Access Controller· · · · User Manual Client Operation You can set and operate the access control devices via the client software. This chapter will introduce the access control device related operations in the client software. For integrated operations, refer to User Manual of iVMS-4200 Client Software. We recommend using iVMS4200 Version V2.7.1.4 Build 20180403 (or later) Function Module Control Panel of iVMS-4200:... -
Page 10: User Registration And Login
Access Controller· · · · User Manual User Registration and Login For the first time to use iVMS-4200 client software, you need to register a new super user for login. When opening iVMS-4200 after registration, you can log into the client software with the registered user name and password. -
Page 11: Access Control Wizard
Access Controller· · · · User Manual Access Control Wizard. Step 1. Adding the ‘Access Controller’ online into iVMS4200 Ensure the Access controller is ‘Activated’ via SADP tool (or via iVMS4200) From the ‘Online Device’ window select the controller and then click on ‘Add to Client’ Give it a name (e.g. -
Page 12: Nd Step - Add A 'User / Card
Access Controller· · · · User Manual Step 2. Adding a person / User / Card First step is to add a ‘group’ organisation for the user(s) Click on Add on the far left of screen. Once an Organisation is added click on ‘Add’ Person to add a card holder Add a name to the person you wish to add, along with any... - Page 13 Access Controller· · · · User Manual Select Card Type = Normal To add a card for this person it can be added 3 ways. 1. Via any Access Reader on the system, 2. Via a card Enrollment Reader, 3. By manually entering the card To auto read the card into the system from a card reader in the system, leave the option set to ‘Card Reader Mode’...
-
Page 14: Rd Step - Assigning Permissions (Access Levels)
Access Controller· · · · User Manual Assigning Permissions to the user Step 3. Before a card will work ‘permissions’ (Access Levels (i/e what doors can the card user during what times) Click ‘Next’ to move to ‘Add Permissions’. Click on ‘Add’ to add a new Access Permission. 1. -
Page 15: Th Step - Setting Up Auto Backup
Access Controller· · · · User Manual Step 4. Auto Backup Click ‘Next’ and select if ‘auto Backup’ of the database is required and if so what days and time the Auto Backup of iVMS4200 database will take place. Note: As default the backup location is C:/iVMS-4200. It is advisable to change this default location to a different drive to that of C: Drive. - Page 16 Access Controller· · · · User Manual This manual has been modified by Ness Corporation for our valued customers. www.nesscorporation.com For support contact Ness Customer Support customerservice@ness.com.au...
