101-091 / 101-091B Ultraprox Bluetooth Keypad/Reader INSTALLATIoN & USER MANUAL Rev 1.0 I n n o v a t i v e E l e c t r o n i c S o l u t i o n s...
INTRODUCTION The XK Series device is a single door multifunction standalone access controller or a Wiegand output reader. It uses Atmel MCU assuring stable performance. The operation is very user-friendly, and low-power circuit makes it long service life. The XK Series device supports 1,000 users (998 common users + 2 panic users), all user data can be transferred from one to another.
Page 4
Specifications User Capacity 1000 Common User Panic User Operating Voltage 12~28V AC/DC <35mA Idle Current Proximity Card Reader EM Format Radio Technology 125KHz Proximity Card Read Range 2~6 cm Wiring Connections Relay Output, Exit Button, Alarm, Door Contact, Wiegand Input, Wiegand Output Relay One (NO, NC, Common) Adjustable Relay Output Time...
Carton Inventory INSTALLATION Remove the back cover from the unit Drill 2 holes(A,C) on the wall for the screws and one hole for the cable Knock the supplied rubber bungs to the screw holes(A,C) Fix the back cover firmly on the wall with 4 flat head screws ...
Page 6
Sound and Light Indication Operation Status Buzzer Stand by Red light bright Enter into programming mode Green light Flashes on, then One beep RED Light flashes. In the programming mode Orange light bright One beep Operation error Three beeps Exit from the programming mode Red light bright One beep Open lock...
STANDALONE MODE The XK Series device can be worked as Standalone Reader for single door. (Factory default mode)---7 2 # Connection Diagram Attention: Install a 1N4004 or equivalent diode is needed when using a common power supply, or the keypad might be damaged. (1N4004 is included in the packing)
Page 8
Programming Programming will vary depending on access configuration. Follow the instructions according to your access configuration. Notes: User ID number: Assign a user ID to the access card / PIN in order to track it. The common user ID number can be any number from 0~997, the panic user ID is from 998~999.
Page 9
Add Panic Users Programming Step Keystroke Combination * (Master Code) # 1. Enter Program Mode 1 (User ID) # (Read Card / Input 8/10 digits 2. Add Card: Card number) # 1 (User ID) # (PIN ) # 2. Add PIN: (User ID is any number from 998-999) 3.
Page 10
Set Relay Configuration The relay configuration sets the behaviour of the output relay on activation. Programming Step Keystroke Combination * (Master Code) # 1. Enter Program Mode 3 (1-99) # 2. Pulse Mode (factory default) The relay time is 1-99 seconds. (1 is 50mS.) (Default is 5 seconds) 3 0 # 2.
Page 11
② Reset to factory default, the user’s information is still retained. NOTE: (The Ness XK Units have some factory set adjustments after it has been ‘defaulted’. It is set in the factory as 26 Bit Wiegand and 10 Digit Virtual Number for when a PIN is entered. If a factory reset is performed onsite then...
CONTROLLER MODE The XK Series device can work as Controller, connected with the external Wiegand reader. (Factory default mode)---7 2 # Connection Diagram Attention: Install a 1N4004 or equivalent diode is needed when use a common power supply, or the reader might be damaged.
Page 13
The XK Series device Connected with Keypad Reader: The keypad reader can be 4 Bits, 8 Bits (ASCII), or 10 Bits output format. (when set to 10 Bits Output Format, when the PIN is entered the output from the keypad is as per a Wiegand Card No. Choose the below operation according to the PIN output format of your reader.
WIEGAND READER MODE The XK Series device can work as Standard Wiegand Reader, connected to the third party Controller--- 7 3 # To set as Wiegand Reader Mode, programming option 73# must be seleted. Notes: It will read EM format 125 Khz Cards. Connection Diagram Notes: ...
ADVANCED APPLICATION User Information Transfer The XK Series device supports the User Information Transfer function, and the enrolled user (cards, PINs) can be transferred from one (let’s name it ‘Master Unit’) to another (let’s name it ‘Accept Unit’). Connection Diagram: Remarks: ●...
Page 16
Interlock The XK Series device supports the Interlock funciton. It is of two keypads for two doors, and mainly used for Control Rooms, banks, prisons, and other places where a higher level security is required. Connection Diagram: Remarks: The Door Contact must be installed and connected as the diagram. Let’s name the two Keypads as “A “and “B”...
Page 17
Programming Summary Function description Operation *- 123456 - # Enter the programming mode then you can do the programming (123456 is the factory default master code) 0 – new code - # - repeat the new code - # Change the master code (code: 6 digits) 1- Read Card - # Add card user...
Page 18
Ness Ultraprox Bluetooth Keypad/Reader Installation & User Manual Rev 1.0 For the product: www.nesscorporation.com 101-091 / 101-091B Ultraprox Bluetooth keypad/ National Customer Service Centre reader Ph: 1300 551 991 customerservice@ness.com.au...
