Mannesmann 12330 Instruction Manual

Finishing Sander
item-no. 12330
CE
This tool is interference-suppressed
according to
CE EN 55014 + EN 61000
I N S T R U C T I O N - M A N U A L
Before using electric power-tools, please read and
understand the attached safety-instructions!
Additional safety-hints for impact-drill:
Always wear safety-goggles and a dust-mask
•
during your work with the finishing-sander.
Always secure the workpiece by clamps or else to
•
avoid slipping away.
Make sure, that there are no nails, screws or other
•
metal-parts in your workpiece, before starting your
job.
Always keep the holes in the baseplate clean from
•
dust.
Always connect a vacuum cleaner to the attached
•
adaptor during your work.
Description
1. front-handle
2. on-/off-switch
3. lock button
4. handle
5. sanding paper
6. base plate
7. paper clamp
8. adaptor for vacuum-cleaner
9. power cord
Technichal dates
voltage
power input
sanding area
sandpaper-size
no. of vibrations
sound pressure level (LPA)
sound power level (LWA)
vibration
(acc. to EN 50144/13)
protection class
weight
Always wear safety-goggles, dust-mask and ear-
protection, when machine is in use!
Recommended nominal operating time: approx. 20
minutes under permanent load.
230 V AC∼ / 50 Hz
150 W
187 x 90 mm
230 x 90 mm
-1
10.000 min
80,0 dB(A)
93,0 dB(A)
2,5 m/s²
/ II
1,29 kgs
Rest after permanent operation: approx. 5-10
minutes.
Fastening of sanding-paper
Disconnect the tool from the power-supply
•
before changing sanding paper.
Open the paper-clamps on both sides of the
•
base-plate and remove the worn-out sanding-
paper.
Place a new sanding-paper on the base-plate
•
observing the holes in the sanding-paper fit to
the holes of the base-plate.
Bend the paper to the base-plate and fasten one
•
clamp first. Press the sanding-paper against the
base-plate, bend the other end and fasten
second clamp.
Attention: This finishing sander is not suit-
•
able for wet-sanding jobs.
Operation
To start the sander pull the trigger upwards
•
For continious operation press the lock-button at
•
the same time.
To stop the machine, pull the trigger again and
•
release.
Put the sander on the workpiece, as soon as the
•
motor has reached its maximum speed.
Let the sander slide smoothly over the surface of
•
your workpiece and do not apply too much
pressure. This will lead to reduce the speed, to
increase the wear of the sanding-paper and the
motor and to an uneven surface.
Stop the sander only after having lifted from the
•
workpiece.
Do not use the sander without sanding-paper.
•
Do not cover the ventilation-slots by your hands,
•
in order to achieve adequate cooling of the
motor.
Maintenance
The sander has no need to be maintained.
•
Before cleaning the sander, be sure to
•
disconnect the machine from the power-supply.
Only use a dry brush or cloth for cleaning the
•
housing from sanding-dust.
Do not use any detergents, since they will attack
•
the plastic-housing and do not let any liquids
enter the inside of the machine.
