DC IN 5V jack

Right side

The following figure shows the right side of the Compact
on / off switch
On / Off switch
English
The AC power adapter cable connects to this jack. Use only
the model of AC adapter that comes with the Compact
an adapter other than that supplied with the unit automatically
voids the warranty.
Pressing the small round orange button for half a second will
switch the unit on or off
+
.
+
Compact
+
. Use of
Page 9
