Front Side - Optelec Compact+ User Manual

Optelec
4.3" wide screen display
Mode button
Magnification button

Front side

The following figure shows the front side of the Compact
snapshot button
Snapshot button
English
The 4.3" wide screen displays text and images
Pressing the mode button allows you to select one of the five
viewing modes
Turning the lever allows you to change the magnification
DC IN 5V jack
The snapshot button allows you to temporarily freeze an image
on the screen of an object or text that may be at arm's length,
enabling you to bring the image closer to your eyes
+
.
+
Compact
Page 8
