PR electronics 9202 Manual

Pulse isolator
Hide thumbs Also See for 9202:
Table of Contents
  • Dansk

    • Table of Contents
    • Advarsel
    • Signaturforklaring
    • Sikkerhedsregler
    • Afmontering Af System 9000
    • EF-Overensstemmelseserklæring
    • Avancerede Features
    • Anvendelse
    • Teknisk Karakteristik
    • Applikationer
    • PR 4501 Display- / Programmeringsfront
    • Bestillingsskema 9202B
    • Elektriske Specifikationer
    • Konfigurering Af Kabelfejlscheck
      • Diagnosticering
      • Kabelfejlsdetektering
      • Hardware- / Softwarefejl
    • Funktionsbeskrivelse
    • Tilslutninger
    • Blokdiagram
    • Visning Af Signal- Og Kabelfejl Uden Displayfront
    • Programmering / Betjening Af Trykknapper
    • Rullende Hjælpetekster I Displaylinie 3
    • Rutediagram
    • Rutediagram,Avancerede Indstillinger (ADV.SET)
  • Français

    • Iecex Installation Drawing ATEX Installation Drawings UK, FR, DE, DK
    • Avertissement
    • Consignes de Securite
    • Signification des Symboles
    • Demontage du Systeme 9000
    • Declaration de Conformite CE
    • Application
    • Caractéristiques Techniques
    • Options Avancées
    • Applications
    • PR 4501 Indicateur / Façade de Programmation
    • Référence de Commande : 9202B
    • Spécification Électriques
    • Configuration du Contrôle D'erreur de Câble
      • Diagnostic
      • Détection D'erreur de Câble
      • Indications Erreur Matériel / Logiciel
    • Déscription des Fonctions
    • Connexions
    • Schema de Principe
    • Indications D'erreur Signal Et Câble Sans la Façade 4501
    • Programmation / Operation des Touches de Fonction
    • Menu Deroulant en Ligne 3 de L'indicateur
    • Diagramme de Programmation
    • Diagramme de Programmation, Reglage Avance (ADV.SET)
  • Deutsch

    • Iecex Installation Drawing ATEX Installation Drawings UK, FR, DE, DK
    • Sicherheitsregeln
    • Warnung
    • Zeichenerklärungen
    • Zerlegung des Systems 9000
    • EG-Konformitätserklärung
    • Erweiterte Merkmale
    • Technishe Merkmale
    • Verwendung
    • Anwendungen
    • PR 4501 Display / Programmierfront
    • Bestellangaben: 9202B
    • Elektrische Daten
    • Konfiguration der Kabelfehlerüberprüfung
      • Diagnosen
      • Kabelfehler Erkennung
      • Hardware / Software Fehler
    • Funktionsbeschreibung
    • Anschlüsse
    • Blockdiagramm
    • Signalfehler- und Kabelfehler Erkennung ohne Frontdisplay
    • Konfiguration / Bedienung der Funktionstasten
    • Scrollender Hilfstext IM Display Zeile 3
    • Flussdiagramm, Erweiterte Einstellungen (ADV.SET)
      • Appendix
        • Iecex Installation Drawing ATEX Installation Drawings
        • Uk, Fr, De, Dk
        • FM Installation Drawing
        • Safety Manual
      • Observed Standards
      • Acronyms and Abbreviations
      • Purpose of the Product
      • Assumptions and Restrictions for Use of the Product
        • Basic Safety Specifications
        • Associated Equipment
          • Relay Output
          • Opto Output
          • Field Device
        • Failure Rates
        • Safe Parameterisation
        • Installation in Hazardous Areas
      • Functional Specification of the Safety Functions
      • Functional Specification of the Non-Safety Functions
      • Safety Parameters
      • Hardware and Software Configuration
      • Failure Category
      • Periodic Proof Test Procedure
      • Procedures to Repair or Replace the Product
      • Maintenance
      • Documentation for Routing Diagram
        • In General
        • Further Explanations
          • Password Protection
          • Cable Fault Information Via Display Front 4501
        • Advanced Functions
          • Display Setup
          • Password
          • Language
          • Power Rail
          • Safety Integrity Level
      • Safe Parameterisation - User Responsibility
        • Safety-Related Configuration Parameters
        • Verification Procedure
          • If no Password Is Set
      • User Interface
        • Scrolling Help Texts in Display Line
        • Routing Diagram
        • Routing Diagram - Advanced Settings (ADV.SET)
      • Connections Diagram

Advertisement

Available languages

Available languages

Quick Links

9 2 0 2
P u l s e i s o l a t o r
N o . 9 2 0 2 V 1 0 2 - I N ( 0 9 2 7 )
P r o d u c t v e r s i o n : 9 2 0 2 - 0 0 2
S I G N A L S T H E B E S T
Side 1
DK
Page 21
UK
Page 41
FR
Seite 61
DE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9202 and is the answer not in the manual?

Questions and answers

Summary of Contents for PR electronics 9202

  • Page 1 Side 1 Page 21 Page 41 Seite 61 9 2 0 2 P u l s e i s o l a t o r N o . 9 2 0 2 V 1 0 2 - I N ( 0 9 2 7 ) P r o d u c t v e r s i o n : 9 2 0 2 - 0 0 2 S I G N A L S T H E B E S T...
  • Page 2 PR electronics A/S tilbyder et bredt program af analoge og digitale signalbehandlingsmoduler til industriel automation. Programmet består af Isolatorer, Displays, Ex-barrierer, Temperaturtransmittere, Universaltransmittere mfl . Vi har modulerne, du kan stole på i selv barske miljøer med elektrisk støj, vibrationer og temperaturudsving, og alle produkter opfylder de strengeste internationale standarder.
  • Page 3: Table Of Contents

    Programmering / betjening af trykknapper ......16 Rullende hjælpetekster i displaylinie 3 ....... 18 Rutediagram ............... 19 Rutediagram,Avancerede indstillinger (ADV.SET) ....20 Appendix ................81 IECEx Installation drawing ATEX Installation drawings UK, FR, DE, DK FM Installation drawing Safety manual 9202 - Product Version 9202-002...
  • Page 4: Advarsel

    Operatører er personer, som under normal drift med produktet skal indstille og betjene produktets trykknapper eller potentiometre, og som er gjort bekendt med indholdet af denne manual. 9202 - Product Version 9202-002...
  • Page 5 Hvis der er tvivl om modulets rette håndtering, skal der rettes henvendelse til den lokale forhandler eller alternativt direkte til: PR electronics A/S, Lerbakken 10, 8410 Rønde, Danmark, tlf: +45 86 37 26 77. Ved tilslutning af flerkorede ledninger med farlig spænding skal ledningsenderne forsynes med ledningstyller.
  • Page 6: Afmontering Af System 9000

    ANSVAR: I det omfang instruktionerne i denne manual ikke er nøje overholdt, vil kunden ikke kunne rette noget krav, som ellers måtte eksistere i henhold til den indgå- ede salgsaftale, mod PR electronics A/S. AFMONTERING AF SYSTEM 9000 Billede 1: Modulet frigøres fra power railen ved...
  • Page 7: Ef-Overensstemmelseserklæring

    EN 60079-11 : 2007, EN 60079-15 : 2005, EN 60079-26 : 2007 ATEX-certifikat: KEMA 07ATEX0146 X Bemyndiget organ: KEMA Quality B.V. (0344) Utrechtseweg 310, 6812 AR Arnhem P.O. Box 5185, 6802 ED Arnhem The Netherlands Rønde, 26. november 2008 Peter Rasmussen Producentens underskrift 9202 - Product Version 9202-002...
  • Page 8: Avancerede Features

    • SIL 2-funktionaliteten skal aktivt tilvælges via menupunkt. Anvendelse • 9202 kan monteres i sikkert område samt i zone 2 / division 2 og modtage signaler fra zone 0, 1, 2, 20, 21 og 22 / Class I/II/III, Div. 1, Gr. A-G.
  • Page 9: Applikationer

    Forsyning +19,2...31,2 VDC Modulstatus N.C. Modulstatus Zone 0, 1, 2, Forsyning via 20, 21, 22 / power rail Cl. I/II/III, div. 1 Zone 2 / Cl. 1, div. 2, gr. A-D eller sikkert område gr. A-G 9202 - Product Version 9202-002...
  • Page 10: Pr 4501 Display- / Programmeringsfront

    ”Programmering / betjening af trykknapper”. Anvendelse: • Kommunikationsinterface til ændring af driftsparametre i 9202. • Som fastmonteret display til visualisering af procesdata og status. Teknisk karakteristik: • Fire liniers LCD-display, linie 1 (5,57 mm høj) viser hver kanals status (OK eller fejl).
  • Page 11: Bestillingsskema 9202B

    Relativ luftfugtighed ........< 95% RH (ikke kond.) Mål, uden displayfront (HxBxD) ....109 x 23,5 x 104 mm Mål, med displayfront (HxBxD) ....109 x 23,5 x 116 mm Kapslingsklasse ........... IP20 Vægt ............170 g / 185 g med 4501 9202 - Product Version 9202-002...
  • Page 12 EMC 2004/108/EF ........EN 61326-1 LVD 2006/95/EF .......... EN 61010-1 ATEX 94/9/EF ..........EN 60079-0, -11, -15 , -26 og EN 61241-0, -11 IECEx ............IEC 60079-0, -11, -15 og -26 IEC 61241-0 og -11 9202 - Product Version 9202-002...
  • Page 13: Konfigurering Af Kabelfejlscheck

    Konfiguration, fælles for begge kanaler Kabelfejlsdetektering: CA.BR = Yes eller CA.SH = Yes 9202 Ellers: Kabelfejlsdetektering Kabelfejlsdetektering (CA.BR, CA.SH): Indgang Hændelse Visning Grænse Alle Kabelbrud CA.BR < 0,1 mA Alle Kortsluttet kabel CA.SH > 6,5 mA 9202 - Product Version 9202-002...
  • Page 14: Hardware- / Softwarefejl

    Hardware- / softwarefejl Visning ved hardwarefejl Fejlsøgning Visning Årsag Test af kommunikation mellem 4501 / 9202 NO.CO Fejl i stikforbindelse Konfigurationsfejl eller crc- EEprom-fejl - check konfiguration FL.ER mismatch, recovery- konfiguration er indlæst Ugyldig recovery- Hardwarefejl DE.ER konfiguration i modulet...
  • Page 15: Tilslutninger

    Relæ, N.C. Relæ, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 Relæ, N.C. Relæ, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 9202 - Product Version 9202-002...
  • Page 16: Blokdiagram

    BLOKDIAGRAM 9202 - Product Version 9202-002...
  • Page 17: Visning Af Signal- Og Kabelfejl Uden Displayfront

    Visning af signal- og kabelfejl uden displayfront 9202 - Product Version 9202-002...
  • Page 18: Programmering / Betjening Af Trykknapper

    BETJENING AF TRYKKNAPPER Dokumentation til rutediagram Generelt: Når du skal konfigurere 9202, bliver du guidet igennem samtlige parametre og kan vælge netop de indstillinger, der passer til applikationen. Til hver menu findes en rullende hjælpetekst, som vises i displaylinie 3.
  • Page 19 FR, IT, ES, SE og DK. Power rail: I menuen ”RAIL” vælges om fejl på modulet skal overføres til en central overvågning i PR 9410 power control unit. Safety Integrity Level: Se Safety Manual for yderligere informa- tion. 9202 - Product Version 9202-002...
  • Page 20: Rullende Hjælpetekster I Displaylinie 3

    [16] Angiv Nyt password [ NEW.PAS ] [17] Vælg sprog [ LANGUA ] Kortsluttet kabel [ I CA.SH ] [ II OFF ] [18] Afbrudt kabel [ I ON ] [ II CA.BR ] [19] 9202 - Product Version 9202-002...
  • Page 21: Rutediagram

    1.2 = Hvis password er valgt Linie 1 symboler:   = OK. Blinkende = fejl. Linie 2 og 3 symboler:   Indgangsfrekvens > 1 Hz = Linie 4 symboler: Statisk prik = SIL-låst. Blinkende prik = ikke SIL-låst. 9202 - Product Version 9202-002...
  • Page 22: Rutediagram,Avancerede Indstillinger (Adv.set)

                       Verificer SIL-konfiguration               9202 - Product Version 9202-002...
  • Page 23 Scrolling help texts in display line 3 ........38 Routing diagram ..............39 Routing diagram, Advanced settings (ADV.SET) ....40 Appendix ................81 IECEx Installation drawing ATEX Installation drawings UK, FR, DE, DK FM Installation drawing Safety manual 9202 - Product Version 9202-002...
  • Page 24: Warning

    General mounting, connection and disconnection of wires. Troubleshooting the module. Repair of the module and replacement of circuit breakers must be done by PR electronics A/S only. WARNING Do not open the front plate of the module as this will cause damage to the connector for the display / programming front PR 4501.
  • Page 25 Should there be any doubt as to the correct handling of the module, please contact your local distributor or, alternatively, PR electronics A/S, Lerbakken 10, 8410 Rønde, Danmark tel: +45 86 37 26 77. The use of stranded wires is not permitted for mains wiring except when wires are fitted with cable ends.
  • Page 26: How To Dismantle System 9000

    LIABILITY: To the extent that the instructions in this manual are not strictly observed, the customer cannot advance a demand against PR electronics A/S that would otherwise exist according to the concluded sales agreement. HOW TO DISMANTLE SYSTEM 9000...
  • Page 27: Ec Declaration Of Conformity

    EN 60079-11 : 2007, EN 60079-15 : 2005, EN 60079-26 : 2007 ATEX certificate: KEMA 07ATEX0146 X Notified body KEMA Quality B.V. (0344) Utrechtseweg 310, 6812 AR Arnhem P.O. Box 5185, 6802 ED Arnhem The Netherlands Rønde 26 November 2008 Peter Rasmussen Manufacturer’s signature 9202 - Product Version 9202-002...
  • Page 28: Advanced Features

    • Monitoring of error events and cable breakage via the individual status relay and/or a collective electronic signal via the power rail. • The 9202 has been designed, developed and certified for use in SIL 2 applications according to the requirements of IEC 61508.
  • Page 29: Applications

    Module status N.C. Module status Zone 0, 1, 2, Supply via 20, 21, 22 / power rail Cl. I/II/III, div. 1 Zone 2 / Cl. 1, div. 2, gr. A-D or safe area gr. A-G 9202 - Product Version 9202-002...
  • Page 30: Pr 4501 Display / Programming Front

    Functions and configuration options are described in the section ”Configuration / operating the function keys”. Application: • Communications interface for modification of operational parameters in 9202. • When mounted in the process, the display shows process values and module status. Technical characteristics: •...
  • Page 31: Order: 9202B

    Dimensions, without display front (HxBxD) 109 x 23.5 x 104 mm Dimensions, with display front (HxBxD) ..109 x 23.5 x 116 mm Protection degree ........IP20 Weight ............170 g / 185 g with 4501 9202 - Product Version 9202-002...
  • Page 32 EMC 2004/108/EC ........EN 61326-1 LVD 2006/95/EC .......... EN 61010-1 ATEX 94/9/EC ..........EN 60079-0, -11, -15 , -26 and EN 61241-0, -11 IECEx ............IEC 60079-0, -11, -15 and -26 IEC 61241-0 and -11 9202 - Product Version 9202-002...
  • Page 33: Configuration Of Cable Fault Check

    Cable fault detection: CA.BR = Yes or CA.SH = Yes 9202 Else: Cable fault detection Cable fault detection (CA.BR, CA.SH): Input Event Readout Limit Cable break CA.BR < 0.1 mA Short-circuited cable CA.SH > 6.5 mA 9202 - Product Version 9202-002...
  • Page 34: Hardware / Software Error

    Hardware / Software error Readout at hardware error: Error search Readout Cause Communications test 4501 / 9202 NO.CO Connection error Configuration error or crc EEprom error - check configuration FL.ER mismatch, recovery confi- guration is loaded Invalid recovery configura- Hardware error DE.ER...
  • Page 35: Connections

    Relay, N.C. Relay, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 Relay, N.C. Relay, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 9202 - Product Version 9202-002...
  • Page 36: Block Diagram

    BLOCK DIAGRAM 9202 - Product Version 9202-002...
  • Page 37: Signal Error And Cable Fault Indications Without Display Front

    Signal error and cable fault indications without display front 9202 - Product Version 9202-002...
  • Page 38: Configuration / Operating The Function Keys

    Documentation for routing diagram. In general: When configuring the 9202, you will be guided through all parameters and you can choose the settings which fit the application. For each menu there is a scrolling help text which is automatically shown in line 3 on the display.
  • Page 39 Power rail: In the menu ”RAIL” you can choose if errors in the module are transmitted to the central surveillance in the PR 9410 power control unit. Safety integrity level: See Safety Manual for details 9202 - Product Version 9202-002...
  • Page 40: Scrolling Help Texts In Display Line 3

    Set New password [ NEW.PAS ] [16] Select Language [ LANGUA ] [17] Cable short circuit [ I CA.SH ] [ II OFF ] [18] Cable breakage [ I ON ] [ II CA.BR ] 9202 - Product Version 9202-002...
  • Page 41: Routing Diagram

    Line 1 symbols:   = OK. Flashing = error Line 2 and 3 symbols:   Input frequency > 1 Hz = Line 4 symbols: Static dot = SIL-locked Flashing dot = not SIL-locked 9202 - Product Version 9202-002...
  • Page 42: Routing Diagram, Advanced Settings (Adv.set)

                     Verification of SIL configuration               9202 - Product Version 9202-002...
  • Page 43: Iecex Installation Drawing Atex Installation Drawings Uk, Fr, De, Dk

    Menu deroulant en ligne 3 de l’indicateur......58 Diagramme de programmation .......... 59 Diagramme de programmation, Reglage avance (ADV.SET) . 60 Appendix ................81 IECEx Installation drawing ATEX Installation drawings UK, FR, DE, DK FM Installation drawing Safety manual 9202 - Product Version 9202-002...
  • Page 44: Avertissement

    électrostatiques (ESD) : montage général, raccordement et débranchement de fils et recherche de pannes sur le module. Seule PR electronics SARL est autorisée à réparer le module et à remplacer les dis joncteurs. AVERTISSEMENT Ne pas ouvrir la plaque avant du module vu que cela peut endommager le connecteur de l’indicateur / la façade...
  • Page 45 Vous pouvez également vous adresser à PR electronics SARL, Zac du Chêne, Activillage, 4, allée des Sorbiers, F-69673 Bron Cedex (tél. : (0) 472 140 607) ou à PR electronics A/S, Lerbakken 10, DK-8410 Rønde, Danemark (tél. : +45 86 37 26 77).
  • Page 46: Demontage Du Systeme 9000

    Dans la mesure où les instructions de ce guide ne sont pas strictement respectées par le client, ce dernier n’est pas en droit de faire une réclamation auprès de PR electronics SARL, même si cette dernière figure dans l’accord de vente conclu.
  • Page 47: Declaration De Conformite Ce

    Certificat ATEX : KEMA 07ATEX0146 X Organisme notifié : KEMA Quality B.V. (0344) Utrechtseweg 310, 6812 AR Arnhem P.O. Box 5185, 6802 ED Arnhem The Netherlands Rønde, le 26 novembre 2008 Peter Rasmussen Signature du fabricant 9202 - Product Version 9202-002...
  • Page 48: Options Avancées

    • Surveillance de cas d’erreur et rupture câble par le relais d’état individuel et / ou un signal électronique collectif par le rail d’alimentation. • Le 9202 a été conçue, développé et certifié pour utilisation dans les applications SIL 2 en conformité avec les exigences du CEI 61508.
  • Page 49: Applications

    Etat du module N.F. Etat du module Zone 0, 1, 2, 20, 21, 22 / Alimentation par rail Cl. I/II/III, div. 1 Zone 2 / Cl. 1, div. 2, gr. A-D oo zone non-dangereuse gr. A-G 9202 - Product Version 9202-002...
  • Page 50: Pr 4501 Indicateur / Façade De Programmation

    • Afin de protéger la configuration contre les modifications non-autorisées, l’accès aux menus peut être bloqué par un mot de passe. Montage / installation : • Cliquer le 4501 sur la face avant du 9202. 9202 - Product Version 9202-002...
  • Page 51: Référence De Commande : 9202B

    Dimensions, sans façade 4501 (HxLxP) ..109 x 23,5 x 104 mm Dimensions, avec façade 4501 (HxLxP) ..109 x 23,5 x 116 mm Degré de protection ........IP20 Poids ............170 g / 185 g avec 4501 9202 - Product Version 9202-002...
  • Page 52 CEM (EMC) 2004/108/CE ......EN 61326-1 DBT 2006/95/CE ......... EN 61010-1 ATEX 94/9/CE ..........EN 60079-0, -11, -15, -26 et EN 61241-0, -11 IECEx ............IEC 60079-0, -11, -15 et -26 IEC 61241-0 et -11 9202 - Product Version 9202-002...
  • Page 53: Configuration Du Contrôle D'erreur De Câble

    CA.BR = Yes ou CA.SH = Yes 9202 Autre : Détection d’erreur de câble Détection d’erreur de câble (CA.BR, CA.SH): Entrée Evénement Affichage Limite Toutes Rupture câble CA.BR < 0,1 mA Toutes Court-circuit câble CA.SH > 6,5 mA 9202 - Product Version 9202-002...
  • Page 54: Indications Erreur Matériel / Logiciel

    Indications erreur matériel / logiciel Indication erreur matériel : Recherche erreurs Affichage Cause d’erreur Vérification de la communication entre 4501 / 9202 NO.CO Erreur de connexion Erreur de config. ou discor- Erreur de l’EEprom - vérifier la configuration FL.ER dance crc, la config. de récupération a été...
  • Page 55: Connexions

    Relais, N.C. Relais, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 Relais, N.C. Relais, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 9202 - Product Version 9202-002...
  • Page 56: Schema De Principe

    SCHEMA DE PRINCIPE 9202 - Product Version 9202-002...
  • Page 57: Indications D'erreur Signal Et Câble Sans La Façade 4501

    Indications d’erreur signal et câble sans la façade 4501 9202 - Product Version 9202-002...
  • Page 58: Programmation / Operation Des Touches De Fonction

    Documentation pour le diagramme de programmation. Généralités : Lors de la configuration du 9202 vous êtes guidés tout au long des paramètres du menu ; ainsi vous pouvez choisir le réglage qui correspond à votre application. Pour chaque menu il y a un texte d’aide qui défile en ligne 3 de l’indicateur.
  • Page 59 Rail d’alimentation : Dans le menu ”RAIL” vous pouvez choirsir si des erreurs dans le module doivent être transmis à l’unité de surveillance du module PR 9410 Contrôleur d’alimentation. Safety integrity level: Voir le ”Safety Manual” (en Anglais) pour information supplémentaire. 9202 - Product Version 9202-002...
  • Page 60: Menu Deroulant En Ligne 3 De L'indicateur

    Entrer Nouveau mot de passe [ NEW.PAS ] [17] Sélectionner langue [ LANGUA ] [18] Court-circuit câble [ I CA.SH ] [ II OFF ] [19] Rupture câble [ I ON ] [ II CA.BR ] 9202 - Product Version 9202-002...
  • Page 61: Diagramme De Programmation

    = OK. Clignotant = erreur Symboles en ligne 2 et 3 :   Fréquence d’entrée > 1 Hz = Symboles en ligne 4 : Balle statique = vérrouillage SIL Balle clignotante = aucun vérrouillage SIL 9202 - Product Version 9202-002...
  • Page 62: Diagramme De Programmation, Reglage Avance (Adv.set)

                 Vérification de la    configuration SIL               9202 - Product Version 9202-002...
  • Page 63: Iecex Installation Drawing Atex Installation Drawings Uk, Fr, De, Dk

    Konfiguration / Bedienung der Funktionstasten ....76 Scrollender Hilfstext im Display Zeile 3 ......78 FlussDiagramm, erweiterte einstellungen (ADV.SET) ..80 Appendix ................81 IECEx Installation drawing ATEX Installation drawings UK, FR, DE, DK FM Installation drawing Safety manual 9202 - Product Version 9202-002...
  • Page 64: Warnung

    Installation, Montage und Demontage von Leitungen. Fehlersuche im Gerät. Reparaturen des Gerätes und Austausch von Sicherungen dürfen nur von PR electronics A/S vorgenommen werden. WARNUNG Die Frontplatte des Gerätes darf nicht geöffnet werden, weil hier- durch die Kontakte zur Kontaktierung des Frontdisplays 4501 beschädigt werden können.
  • Page 65 Händler vor Ort Kontakt aufnehmen. Sie können aber auch direkt mit PR electronics GmbH, Im Erlengrund 26, D-46149 Oberhausen, (Tel.: (0) 208 62 53 09-0) oder mit PR electronics A/S, Lerbakken 10, DK-8410 Rønde, Dänemark (Tel.: +45 86 37 26 77) Kontakt aufnehmen.
  • Page 66: Zerlegung Des Systems 9000

    Wasser leicht angefeuchtet ist. HAFTUNG: In dem Umfang, in welchem die Anweisungen dieses Handbuches nicht genau eingehalten werden, kann der Kunde PR electronics gegenüber keine Ansprüche geltend machen, welche ansonsten entsprechend der eingegange- nen Verkaufsvereinbarungen existieren können.
  • Page 67: Eg-Konformitätserklärung

    EN 60079-11 : 2007, EN 60079-15 : 2005, EN 60079-26 : 2007 ATEX-Zertifikat: KEMA 07ATEX0146 X Zulassungsstelle: KEMA Quality B.V. (0344) Utrechtseweg 310, 6812 AR Arnhem P.O. Box 5185, 6802 ED Arnhem The Netherlands Rønde, 26. November 2008 Peter Rasmussen Unterschrift des Herstellers 9202 - Product Version 9202-002...
  • Page 68: Erweiterte Merkmale

    • Kontrolle von Fehlern und Kabelbruch über das einzelne Statusrelais und / oder eine gemeinsame elektronische Sammelmeldung über die Power Rail. • Der Impulsisolator 9202 wurde entwickelt und zertifiziert für SIL 2- Anwendungen entsprechend den Anforderungen der Richtlinie IEC 61508.
  • Page 69: Anwendungen

    Versorgung +19,2...31,2 VDC Gerätestatus N.C. Gerätestatus Zone 0, 1, 2, Versorgung über 20, 21, 22 / Power Rail Cl. I/II/III, div. 1 oder sicheres Bereich Zone 2 / Cl. 1, Div. 2, Gr. A-D gr. A-G 9202 - Product Version 9202-002...
  • Page 70: Pr 4501 Display / Programmierfront

    Status für Relais 1 und Relais 2 an. • Zum Schutz der jeweiligen Konfiguration gegen unbefugte Änderungen kann der Zugang zum Menü durch ein Passwort blockiert werden. Montage / Installation: • Stecke das 4501 auf die Front des 9202. 9202 - Product Version 9202-002...
  • Page 71: Bestellangaben: 9202B

    Relative Luftfeuchtigkeit ......< 95% RF (nicht kond.) Abmessungen, ohne Frontdisplay (HxBxD) .. 109 x 23,5 x 104 mm Abmessungen, mit Frontdisplay (HxBxD) ... 109 x 23,5 x 116 mm Schutzart ............. IP20 Gewicht ............170 g / 185 g mit 4501 9202 - Product Version 9202-002...
  • Page 72 Norm: EMV 2004/108/EG ........EN 61326-1 LVD 2006/95/EG .......... EN 61010-1 ATEX 94/9/EG ..........EN 60079-0, -11, -15, -26 und EN 61241-0, -11 IECEx ............IEC 60079-0, -11, -15 og -26 IEC 61241-0 und -11 9202 - Product Version 9202-002...
  • Page 73: Konfiguration Der Kabelfehlerüberprüfung

    Konfiguration, gebräuchlich für beide Kanäle Kabelfehler Erkennung: CA.BR = Ja oder CA.SH = Ja 9202 Sonst: Kabelfehler Erkennung Kabelfehler Erkennung (CA.BR, CA.SH): Eingang Vorfall Anzeige Grenze Alle Kabelbruch CA.BR < 0,1 mA Alle Kabel kurzgeschlossen CA.SH > 6,5 mA 9202 - Product Version 9202-002...
  • Page 74: Hardware / Software Fehler

    (2) Mechanischer Schalter mit Kabelfehlererkennung für Bruch und Kurzschluss, wenn Rs und Rp auf dem Schalter montiert ist. (3) Mechanischer Schalter mit Kabelfehlererkennung für Bruch, wenn Rp auf dem Schalter montiert ist (4) Mechanischer Schalter ohne Kabelfehlererkennung. 9202 - Product Version 9202-002...
  • Page 75: Anschlüsse

    Relais, N.C. Relais, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 Relais, N.C. Relais, N.O. Opto, NPN 11 12 13 14 11 12 13 14 11 12 13 14 9202 - Product Version 9202-002...
  • Page 76: Blockdiagramm

    BLOCKDIAGRAMM 9202 - Product Version 9202-002...
  • Page 77: Signalfehler- Und Kabelfehler Erkennung Ohne Frontdisplay

    Signalfehler- und Kabelfehler Erkennung ohne Frontdisplay 9202 - Product Version 9202-002...
  • Page 78: Konfiguration / Bedienung Der Funktionstasten

    Dokumentation für das Flussdiagramm. Grundsätzliches: Bei der Konfiguration des 9202 werden Sie durch alle Parameter geleitet und Sie können die Einstellungen wählen, welche zur Applikation passt. Für jedes Menü existiert ein scrollender Hilfetext welcher automatisch in der 3. Zeile im Display gezeigt wird.
  • Page 79 Power Rail: Im Menü ”Rail” können Sie wählen, ob Fehler im Gerät an die zentrale Überwachung im Power Control Unit PR 9410 weitergegeben werden sollen. Safety Integrity Level (SIL): Für Details sehen Sie bitte im Sicherheitshandbuch (Safety Manual) nach. 9202 - Product Version 9202-002...
  • Page 80: Scrollender Hilfstext Im Display Zeile 3

    [15] Eingabe Neues Passwort [ NEW.PAS ] [16] Sprachauswahl [ LANGUA ] [17] Kabel Kurzschluss [ I CA.SH ] [ II OFF ] [18] Kabel Drahtbruch [ I ON ] [ II CA.BR ] [19] 9202 - Product Version 9202-002...
  • Page 81 Zeile 1 Symbole:   = OK. Blinken = Fehler Zeile 2 und 3 Symbole:   Eingangsfrequenz > 1 Hz = Zeile 4 Symbole: Statischer Punkt = SIL-verriegelt Blinkender Punkt = nicht SIL verriegelt 9202 - Product Version 9202-002...
  • Page 82: Flussdiagramm, Erweiterte Einstellungen (Adv.set)

                      Bestätigung der SIL-Konfiguration               9202 - Product Version 9202-002...
  • Page 83: Appendix

    APPENDIX IECEx Installation drawing ATEX Installation drawings UK, FR, DE, DK FM Installation drawing Safety manual 9202 - Product Version 9202-002...
  • Page 84 For Installation in Zone 2 / Division 2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way.
  • Page 85 9202QI01 LERBAKKEN 10, 8410 RØNDE DENMARK Terminal (31,32) Supply: Voltage 19.2 – 31.2 VDC Power max. Terminal (33,34) Status Relay: Non Hazardous location Zone 2 installation Voltage max. 125 VAC / 110 VDC 32 VAC / 32 VDC Power max. 62.5 VA / 32 W 16 VA / 32 W Current max.
  • Page 86 For Installation in Zone 2 / Division 2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way.
  • Page 87 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Terminal (31,32) Supply: Voltage 19.2 – 31.2 VDC Power max. Terminal (33,34) Status Relay: Non Hazardous location Zone 2 installation Voltage max. 125 VAC / 110 VDC 32 VAC / 32 VDC Power max. 62.5 VA / 32 W 16 VA / 32 W Current max.
  • Page 88 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Schéma d’installation ATEX 9202 Pour une installation sûre du 9202B vous devez observer ce qui suit. Le module sera seulement installé par un personnel qualifié qui est informé des lois, des directives et des normes nationales et internationales qui s'appliquent à...
  • Page 89 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Bornes (31,32) d’alimentation : Tension 19,2 – 31,2 Vcc Puissance max. Bornes (33,34) Relais d’état Localisation zone non dangereuse Installation en Zone 2 Tension max. 125 Vca / 110 Vcc 32 Vca / 32 Vcc Puissance max.
  • Page 90 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK ATEX Installationszeichnung 9202 Für die sichere Installation von 9202B ist Folgendes zu beachten: Das Gerät darf nur von qualifiziertem Personal eingebaut werden, das mit den nationalen und internationalen Gesetzen, Richtlinien und Standards auf diesem Gebiet vertraut ist.
  • Page 91 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Klemmen (31,32) Versorgung: Spannung: 19,2 – 31,2 VDC Leistung max. Klemmen (33,34) Relaisstatus: Nicht explosionsgefährdeter Bereich : Zone 2-Installation Spannung max: 125 VAC / 110 VDC 32 VAC / 32 VDC Leistung max. 62,5 VA / 32 W 16 VA / 32 W Strom max.
  • Page 92 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK ATEX Installationstegning 9202 For sikker installation af 9202B skal følgende overholdes: Modulet må kun installeres af kvalificerede personer, som er bekendt med national og international lovgivning, direktiver og standarder i det land, hvor modulet skal installeres. Produktionsår fremgår af de to første cifre i serienummeret.
  • Page 93 9202QA01 LERBAKKEN 10, 8410 RØNDE DENMARK Klemme (31,32) Forsyning: Spænding: 19,2 – 31,2 VDC Max. forbrug. Klemme (33,34) Relæstatus: Ikke eksplosionsfarligt område Zone 2-installation Max spænding 125 VAC / 110 VDC 32 VAC / 32 VDC Max. forbrug 62,5 VA / 32 W 16 VA / 32 W Max.
  • Page 94 For Installation in Zone 2 / Division 2 the following must be observed. The 4501 programming module is to be used solely with PR electronics modules. It is important that the module is undamaged and has not been altered or modified in any way.
  • Page 95 9202QF01 LERBAKKEN 10, 8410 RØNDE DENMARK Terminal (31,32) Supply: Voltage 19.2 – 31.2 VDC Power max. 3 W Terminal (33,34) Status Relay: Non Hazardous location: Division 2 or Zone 2 installation: Voltage max. 125 VAC / 110 VDC 32 VAC / 32VDC Power max.
  • Page 96: Safety Manual

    SAFETY MANUAL PULSE ISOLATOR 9202 VERSION NO. V2R0 This safety manual is valid for the following product versions: 9202-002...
  • Page 97 9202 Pulse Isolator Safety Manual 0. CONTENTS 1. Observed standards ................2. Acronyms and abbreviations ..............3. Purpose of the product ................4. Assumptions and restrictions for use of the product ......4.1 Basic safety specifications ............. 4.2 Associated equipment ..............
  • Page 98: Observed Standards

    Safety Manual 9202 Pulse Isolator 1. Observed standards Standard Description Functional Safety of electrical / electronic / programmable IEC 61508 electronic safety-related systems IEC 61508- Part 2: Requirements for electrical / electronic / programmable 2:2000 electronic safety-related systems IEC 61508-...
  • Page 99: Purpose Of The Product

    Error events, including cable breakage, are monitored and signalled via the individual status relay and/or a collective electronic signal via the power rail. The 9202 has been designed, developed and certified for use in SIL 2 applications according to the requirements of IEC 61508.
  • Page 100: Safe Parameterisation

    Safety Manual 9202 Pulse Isolator Safe parameterisation The user is responsible for verifying the correctness of the configuration parameters. (See section 14 Safe parameterisation - user responsibility). Manual override may not be used for safety applications. Installation in hazardous areas...
  • Page 101: Hardware And Software Configuration

    12 years, according to IEC 61508. Note : The maximum frequency for Pulse Isolator 9202 with relay output is 20 Hz. The user must calculate the product lifetime with regard to the relay lifetime.
  • Page 102: Documentation For Routing Diagram

    The routing diagram is shown in section 16.2. 13.1 In general When configuring the 9202, you will be guided through all parameters and you can choose the settings which fit the application. For each menu there is a scrolling help text which is automatically shown in line 3 on the display.
  • Page 103: Display Setup

    9202 Pulse Isolator Safety Manual 13.4.1 Display setup Here you can adjust the brightness contrast and the backlight. Setup of tag numbers with 5 alphanumerics. Selection of functional readout in line 2 and 3 of the display - choose between readout of digital output or tag no.
  • Page 104: Safe Parameterisation - User Responsibility

    Safety Manual 9202 Pulse Isolator 14 Safe parameterisation - user responsibility 14.1 Safety-related configuration parameters Parameters Value Description CH1.FUN DIR / INV Direct / inverted channel function CH2.FUN. DIR / INV Direct / inverted channel function PASSW 0 - 9999...
  • Page 105 10 shall be used. 15 Fault reaction and restart condition When the 9202 detects a fault the output will go to Safe State, in which the opto output will go to “high impedance” or the relay output will go to “de-energised”.
  • Page 106: User Interface

    Safety Manual 9202 Pulse Isolator 16 User interface 16.1 Scrolling help texts in display line 3 Set correct password [ PASS ] [01] Enter advanced setup [ ADV.SET ] [02] Enable cable short circuit error indication [ CA.SH ] [03] Enable cable breakage error indication? [ CA.BR ]...
  • Page 107: Routing Diagram

    9202 Pulse Isolator Safety Manual 16.2 Routing diagram If no key is activated for 1 minute, the display will return to the default state 1.0 without saving configuration changes. Increase value / choose next parameter Decrease value / choose previous parameter...
  • Page 108: Routing Diagram - Advanced Settings (Adv.set)

    Safety Manual 9202 Pulse Isolator 16.3 Routing diagram - Advanced settings (ADV.SET) !'1. . 11 * ,% 0 '* -32 12 2 !'1. 2 % 2 % 12 2 1#23. "-,20 *'%&2 2 %,- 2 %,- !'1. 2SP  2SP ...
  • Page 109: Connections Diagram

    9202 Pulse Isolator Safety Manual 17. Connections diagram Supply and Power rail status relay connections 31 32 33 34 91 92 93 94 95 N.C. Error Gnd. Gnd. +24 V +24 V Inputs: NC = no connection NAMUR sensor, Switch,...
  • Page 110 Displays Programmable displays with a wide se- lection of inputs and outputs for display of temperature, volume and weight, etc. Feature linearisation, scaling, and difference measurement functions for programming via PReset software. Ex interfaces Interfaces analogue digital ® signals as well as HART signals between sensors / I/P converters / frequency signals and control systems in Ex zone 0, 1 &...
  • Page 111 PR electronics AB sales@prelectronics.se August Barks gata 6A tel. +46 (0) 3149 9990 S-421 32 Västra Frölunda fax +46 (0) 3149 1590 PR electronics UK Ltd Middle Barn, Apuldram sales@prelectronics.co.uk Chichester tel. +44 (0) 1243 776 450 West Sussex, PO20 7FD...

Table of Contents
