1/2" air impact wrench
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1/2" AIR
IMPACT
WRENCH
67089
These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 67089 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Draper 67089

Summary of Contents for Draper 67089

  • Page 1 AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.

  • Page 2: Title Page

    Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact.

  • Page 3: Table Of Contents

    2. CONTENTS 2.1 CONTENTS 1. TITLE PAGE 1.1 INTRODUCTION ......................... 1 1.2 REVISION HISTORY ......................2 1.3 UNDERSTANDING THIS MANUAL..................2 1.4 COPYRIGHT NOTICE......................2 2. CONTENTS 2.1 CONTENTS ......................... 3 3. GUARANTEE 3.1 GUARANTEE ........................4 4. INTRODUCTION 4.1 SCOPE ..........................5 4.2 SPECIFICATION .........................

  • Page 4: Guarantee

    This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period.

  • Page 5: Introduction

    4.1 SCOPE This air impact wrench is designed for removal and installation of threaded fasteners. Any other use is forbidden. 4.2 SPECIFICATION Stock No..........................67089 Part no........................... 5209PRO/G Square drive anvil size .......................1/2" Ultimate torque ......................678Nm/500lb-ft Max. operating air pressure ..................90psi (6.2bar) Average air consumption..................

  • Page 6: Health And Safety Information

    5. HEALTH AND SAFETY INFORMATION 5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE When using any type of power tool there are steps that should be taken to make sure that you, as the user, remain safe. Common sense and a respect for the tool will help reduce the risk of injury. Read the instruction manual fully.

  • Page 7: Additional Safety Instructions For Air Impact Wrenches

    5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR AIR IMPACT WRENCHES Important: Draper Tools Limited recommends that this machine should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in writing and we will advise you.

  • Page 8: Residual Risk

    5. HEALTH AND SAFETY INFORMATION – Release the start and stop device in the case of an interruption of the energy supply; – Only lubricants recommended by the manufacturer shall be used; – Release pressure when not in use. Disconnect from air line; –...

  • Page 9: Technical Description

    6. TECHNICAL DESCRIPTION 6.1 IDENTIFICATION Variable speed trigger. Anvil. Anvil ring. Reverse/forward/speed selector. Machine body. 1/4" BSP (female) air inlet. - 9 -...

  • Page 10: Unpacking And Checking

    Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Draper Helpline (the telephone number appears on the Title page) and do not attempt to use the impact wrench.

  • Page 11: Assembly

    This air tool operates at a maximum pressure of 90psi and must be controlled via a combination pressure regulator, in-line lubricator and moisture filter such as the Draper range (see you local Draper stockist) which with proper maintenance will ensure a constant supply of dry air and lubricating oil at all times (see illustration below).

  • Page 12: Connection To The Air Supply

    Air tools are precision manufactured to close tolerances. In-line oiler and lubrication units can greatly extend the life of your air tools. The mini-oiler can also be purchased separately from Draper Tools. Mini oiler Stock No.22317 FIG.4 - 12 -...

  • Page 13: Operation And Use

    9. OPERATION AND USE Warning! ● Disconnect from the air supply before carrying out any adjustments, servicing or maintenance. 9.1 TRIGGER SWITCH – FIG. 5 Note: Before connecting the impact wrench to the air supply reduce the line pressure according to the specification.

  • Page 14: Maintenance

    10. MAINTENANCE Warning! ● Disconnect from the air supply before carrying out any adjustments, servicing or maintenance. ● Never use any sockets or accessories that are not hardened for impact use. 10.1 ANVIL – FIG. 7 – Ensure the anvil ring is correctly maintained and if damaged or missing is replaced immediately before work commences.

  • Page 15: Troubleshooting

    Use only high quality impact sockets as listed in the Draper Catalogue. Chrome plated sockets can shatter and cause injury. – Lubricant clutch housing. Tool runs at normal speed but loses –...

  • Page 16: Disposal

    12. DISPOSAL 12.1 DISPOSAL – At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations. – Contact your local authority for details of collection schemes in your area. In all circumstances: ●...

  • Page 17: Explanation Of Symbols

    13. EXPLANATION OF SYMBOLS 13.1 EXPLANATION OF SYMBOLS Single value noise marking. (Maximum declared A-Weighted Read the instruction manual. sound power level in decibels). Wear safety glasses. Wear ear defenders. Wear protective gloves. Long and loose hair must be contained or securely tied back. Do not abandon into the environment.
  • Page 18 ©Published by Draper Tools Limited. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
