INSTRUCTIONS FOR
10.8V Li-ion
Cordless Impact Driver
Stock No.20847
Part No.ID108VLI
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.
GENERAL INFORMATION
These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Draper ID108VLI
Summary of Contents for Draper ID108VLI
- Page 1 AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
-
Page 2: Title Page
Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact. -
Page 3: Table Of Contents
CONTENTS 2.1 CONTENTS PAGE CONTENT PAGE TITLE PAGE INTRODUCTION ....................2 REVISION HISTORY................... 2 UNDERSTANDING THIS MANUAL ..............2 COPYRIGHT NOTICE ..................2 CONTENTS CONTENTS ......................3 GUARANTEE GUARANTEE ..................... 4 INTRODUCTION SCOPE ....................... 5 SPECIFICATION ....................5 HANDLING & STORAGE ................... 5 HEALTH &... -
Page 4: Guarantee
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period. -
Page 5: Introduction
It is intended for domestic and light commercial use only. Any other application is considered misuse. 4.2 SPECIFICATION Stock no..........................20847 Part no..........................ID108VLI Battery ..........................10.8V Maximum torque ......................80Nm Revolutions per minute (no load) ................0-2500rpm Impact rate .........................0-3500bpm... -
Page 6: Health & Safety Information
HEALTH & SAFETY INFORMATION 5.1 GENERAL SAFETY INSTRUCTIONS Do not overreach. Keep proper footing and balance at all times. This enables better control of General Power Tools Safety Warnings the power tool in unexpected situations. Dress properly. Do not wear loose clothing or WARNING: Read all instructions. -
Page 7: General Instructions For Battery Powered Tools & Chargers
HEALTH & SAFETY INFORMATION 5.2 GENERAL INSTRUCTIONS FOR Check that cutting tools are undamaged and are kept clean and sharp, this will maintain their operating BATTERY POWERED TOOLS & performance and lessen the loading on the tool. CHARGERS 5.3 SAFETY INSTRUCTIONS FOR MAINS POWERED BATTERY Good Working Practices/Safety The following suggestions will enable you to observe... -
Page 8: Instructions For Chargers And Batteries
NOTE: This information relates to the battery charging system for the Draper 10.8V cordless range. 5.6 LITHIUM-ION MATERIAL DATA SHEET a. -
Page 9: Technical Description
TECHNICAL DESCRIPTION 6.1 IDENTIFICATION Variable speed trigger switch Battery charge indicator Forward/Reverse selector Belt clip ¼" Hex. (Female) quick release collet 10.8V battery pack LED work light... -
Page 10: Unpacking & Checking 7.1 Packaging
Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Draper Help Line (the telephone number appears on the Title page) and do not attempt to use the product. -
Page 11: Basic Cordless Impact Driver Operations
BASIC CORDLESS IMPACT DRIVER OPERATIONS 8.1 BATTERY CHARGING - FIGS. 1 - 2 FIG.1 Check the mains voltage. Make sure the voltage of the power source is the same as the voltage specified on the rating plate of the charger unit. Plug your mains plug into the power source. -
Page 12: Installing And Removing Bits
BASIC CORDLESS IMPACT DRIVER OPERATIONS 8.2 INSTALLING AND REMOVING BITS - FIG. 3 This driver is supplied with a ¼" Female Hex. Pull and hold the quick release collet outwards to insert and to release the bit. NOTE: This product is equipped with an electric brake. Never use any bits or accessories that are not hardened for impact use. -
Page 13: Holding The Impact Driver
BASIC CORDLESS IMPACT DRIVER OPERATIONS 8.6 HOLDING THE IMPACT DRIVER - FIG.6 FIGS. 6 - 7 The impact driver casing is designed to be held comfortably in two ways, 1. By the handle. 2. Or by the in-line support grip. FIG.7... -
Page 14: Maintenance
MAINTENANCE 9.1 MAINTENANCE Regular inspection and cleaning reduces the necessity for maintenance operations and will keep your tool in good working condition. The motor must be correctly ventilated during tool operation. For this reason avoid blocking the air inlets. -
Page 15: Troubleshooting
10. TROUBLESHOOTING Problem Cause Remedy Driver does not 1. Flat battery. 1. Charge battery. work. 2. Forward/Reverse 2. Select forward or reverse. not selected. 11. OPTIONAL ACCESSORIES 11.1 OPTIONAL ACCESSORIES (Available separately) Stock No. Part No. Description 41543 CB108LI/A 10.8V Battery 41556 C108LI/A 10.8V Charger... -
Page 16: Explanation Of Symbols
12. EXPLANATION OF SYMBOLS 12.1 EXPLANATION OF SYMBOLS Class II construction (Double insulated). WEEE Do not dispose of Waste Electrical & Electronic Equipment in with domestic rubbish For indoor use only. Do not expose to rain. Li-ion battery must be recycled or disposed of properly. Li-ion Fuse protective device. -
Page 17: Disposal
13. DISPOSAL 13.1 DISPOSAL At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations. Contact your local authority for details of collection schemes in your area. In all circumstances: •... - Page 18 NOTES...
- Page 19 NOTES...
- Page 20 - Sales Desk: (023) 8049 4333 - General Enquiries: (023) 8026 6355 - Service/Warranty Repair Agent For aftersales servicing or warranty repairs, please contact the Draper Tools Help Line for details of an agent in your local area. YOUR DRAPER STOCKIST RDKC0916...
