The rest of stages the process profile parameter include more inputs for
each heating zone power setting
In the main tab
buttons for stages parameter inputs or to review the stage prarameter.
To set a stage's parameter press Up or Down button to the parameter
location change the input value (increase) by press Right button (decrease)
by press Left button.
In each stage parameters are as follow:
- Stage ends temperature value
- Time in ends temperature (Dwell time)
- Upper heater power Level from (0% to 100%)
- Middle heater power Level from (0% to 100%)
- Side heaters power Level from (0% to 100%)
4.2.2 Save process profile
After input the process profile paramters save the profile in the machine
memory (Memory can save up to 50 profiles).
Press enter and choose Save profile
