Titan Controls Apollo 2 Easy Manual

®
Apollo
Cycle Timer with Photocell
Easy Guide
Note: This unit has been set to perform day only control. For
night only or 24 hour control, refer to 'Optional' settings.
VANCOUVER, W ASHINGTON U.S.A.
INSTRUCTIONS – REV. B
2
®
Step 1
Set values for ON time & OFF time
ON Time: Duration for which equipment will run
OFF Time: Duration in between ON times
OPTIONAL SETTINGS
Change to '24 hour' control
A. Set both values to minimum
B. Plug in, then set both values to maximum within 5 seconds
C. Output light turns on or off according to actual setting
D. Follow instructions as shown in Step 1 & 2
Change to 'night only' control
A. Set both values to maximum
B. Plug in, then set bottom value to minimum
value to minimum
C. Output light turns on or off according to actual setting
D. Follow instructions as shown in Step 1 & 2
Light sensor
(photocell): see
Optional settings
A
B
C
Action 2
A
B
Action 1
C
(Action 1), followed by top
(Action 2) within 5 seconds
Step 2
Plug into 120VAC outlet Connect equipment to be controlled
Installation is now complete
A
C
Change to 'day only' control
A. Set both values to maximum
B. Plug in, then set top value to minimum (Action
by bottom value to minimum (Action 2) within 5 seconds
C. Output light turns on or off according to actual setting
D. Follow instructions as shown in Step 1 & 2
www.titancontrols.net
For technical assistance call us at
1-888-80-Titan or 1-888-808-4826.
