PAC VCI-MCR Quick Start Manual

Class 2
VPW J1850
Arbitration
1 0 0 0 1 1 1 0 1 1 1 1 0 0 1 0 0 1 1 0 1 1 0 0
DISCLAIMER: Under no circumstances shall the manufacturer or the distributors of the VCI-MBZ/MCR parts be held liable for consequential
damages sustained in connection with the VCI-MBZ/MCR. The manufacturer and it's distributors will not, nor will they authorize any
representative or any other individual to assume obligation or liability in relation to the VCI-MBZ/MCR other than its replacement.
Inaccuracies or Typographical Errors: The information in these instructions could contain technical or other mistakes, inaccuracies or
typographical errors. PAC may make changes to the materials in these instructions at any time without notice. The information in these
instructions may be out of date, and PAC makes no commitment to update such information.
With face open, disconnect radio harness. On botton of
display, disconnect factory ribbon cable.
Connect supplied ribbon cable to the display section of
the navigation unit.
10-18-2006
Video Interface for factory Mercedes ML, CLK and R Class
J1850
EOD
Class 2
1 1 1 0 1 0 0 0 0 1 1 0 1 1 0 1 1 1 0 0 1 1 0 0
Pacific Accessory Corporation - 1502 S. Santa Fe Street, Santa Ana, CA 92705
techsupport@pac-audio.com • www.pac-audio.com
VCI-MBZ/MCR
W209 / W164 / W251
CRC
1 0 0 0 1 1 1 0 1 1 1 1 0 0 1 0 0 1 1 0 1 1 0 0
Pull ribbon cable back and leave exposed.
Route the supplied ribbon cable between the chassis and
display section.
Class 2 J1850
1 1 1 0 1 0 0 0 0 1 1 0 1 1 0 1 1 1 0 0 1 1 0 0
Class 2
