LSI SSA Series Installation Manual

SSA/SMA Series
BEFORE YOU BEGIN
Read and follow all safety instructions
RISK OF FIRE, EXPLOSION AND ELECTRIC SHOCK
•
This product should be installed, inspected, and maintained by a qualified electrician only,
in accordance with the NEC (National Electric Code) and all local codes.
•
Turn off electrical power before inspection, installation or removal.
• Use only UL (or other NTRL) approved wire for input/output connections.
Minimum size 18 AWG or 14 AWG for continuous runs.
•
Make sure LEDs and drivers are cool to touch when performing maintenance.
Make sure the supply voltage is the same as the rated voltage of the luminaire.
•
Do not install in a hazardous atmosphere, except where the ambient temperature does
not exceed the rated operating temperature of the fixture.
•
Keep tightly closed when in operation
Prepare Electrical Wiring

Electrical Requirements

The LED driver must be supplied with 120 to 277V, 50/60 Hz
and connected to an individual, properly grounded branch circuit
protected by a 20 Ampere circuit breaker. Use min. 75°C supply.

Grounding Instructions

The grounding and bonding of the overall system shall be
done in accordance with NEC Article 600 and local codes
LSI Industries
10000 Alliance Rd.
Cincinnati, OH 45242
SAVE THESE INSTRUCTIONS
WARNING
705077 010419
Installation Guide
Installation Question?
800-436-7800 ext 3300
LSI Field Service
Fax 513.984.9723
