QUICK-START INSTALLATION GUIDE
CONNECTING TO THE WEB-BASED
USER INTERFACE
Infinity Link Gateway is configured, controlled, and monitored through a web-based user interface.
Enter the IP address of either port into the web browser of your choice; once connected, enter the
default user name of "user" (minus the quotes). There is no default password, so leave this field blank.
Home Screen
The Home screen is displayed showing the unit's serial number and software version along with basic
networking and PTP clock information and other statistics.
It also displays the Device ID, which by default is a unique value based on the unit's MAC address. We
recommend you leave this value unchanged and use the Label field to create an easily-recognized name
for the Link Gateway.
If you do elect to change the ID, it must maintain a unique value among all devices in the system as
this is the field Infinity Dashboard software uses to identify the hardware in its database.
Important!
It is highly recommended that if you intend to change the Device ID, you do so
before adding it to your system configuration in Dashboard. If the Gateway has
already been added using its original Device ID and the value is then changed,
duplicate instances of input and outputs will be created in the database which can
result in corrupted paths.
Figure 6: Home screen
