- Page 2 INTRODUCTION Congratulations and thank you for purchasing SKAR AUDIO amplifiers, the logical choice in mobile audio amplification. Your amplifiers have been designed and engineered with the highest quality components and top of the line workmanship to help you reach the superior sound you are after.
-
Page 3: Power Connection
MULTI-CHANNEL SPECIFICATIONS Rated power output RP-75.4AB RP-150.4AB RP-600.5 - RMS power @ 4 ohm 75Watts x 4 150Watts x 4 60Watts x 4 + 170Watts x 1 - RMS power @ 2 ohm 115Watts x 4 250Watts x 4 90Watts x 4 + 270Watts x 1 - RMS power @ 1 ohm 370Watts x 1 - RMS power @ 4 ohm mono... - Page 4 BATT 12V POWER ) Before mounting amplifiers, disconnect the negative cable from the battery to protect any accidental damage to your awesome amplifiers and audio system. All amplifiers are designed to use 4 gauge power and ground connection. Connect the power cables to power terminal 12V.
- Page 5 DIGITAL MONOBLOCK SPEAKER CONNECTION 4 ~ 1 ohms 4 ~ 2 ohms 4 ~ 2 ohms...
- Page 6 4 CHANNELS RCA INPUT CONNECTION HEAD UNIT Ch1/2 Input GAIN X-Over Bass EQ Power LP/BP 12dB Min Max 20Hz 5KHz 50Hz 500Hz Protect Full Remote Min Max 20Hz 5KHz 50Hz 500Hz LP/BP 12dB Ch3/4 Full 4 CHANNELS SPEAKER CONNECTIONS Mid Range Tweeter Passive POWER...
- Page 7 Mid Range Tweeter Passive POWER Bridged Bridged 8 ~ 4 ohms 5 CHANNELS RCA INPUT CONNECTION HEAD UNIT...
- Page 8 5 CHANNELS SPEAKER CONNECTIONS 8 ~ 4 ohms 8 ~ 4 ohms Mid Range Tweeter Passive...
- Page 9 TROUBLE SHOOTINGS RP-series amplifiers have the protection features to prevent any damages from misuse or faulty conditions. If RP-series amplifiers sense excessive heat, short circuited speakers DC, or voltage the protection indicator will light, and the system will be turned off. In order to check the problem, you should turn all levels down and all power off and carefully check the installation for wiring mistakes or short.
