LCD Projector
MC-WU5506M
MC-WX5506M
User's Manual (detailed)
Operating Guide
Thank you for purchasing this projector.
WARNING
WARNING
CAUTION
NOTICE
NOTE
Trademark acknowledgment
®
®
Safety Guide
1
QM00121-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-WX5506M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Maxell MC-WX5506M

  • Page 1 LCD Projector MC-WU5506M MC-WX5506M User's Manual (detailed) Operating Guide Thank you for purchasing this projector. WARNING Safety Guide WARNING CAUTION NOTICE NOTE Trademark acknowledgment ® ® QM00121-1...
  • Page 2: Table Of Contents

    Introduction ....3 SCREEN menu ... . . 77 OPTION menu ... . . 83 NETWORK menu .
  • Page 3: Introduction

    Introduction Features HDMI/MHL/HDBaseT ® Checking the contents of package Contents of package User’s Manual (concise) WARNING NOTE QM00121-1...
  • Page 4 Introduction Part names Projector 31, 76 28 90...
  • Page 5 Introduction Part names (continued) WARNING CAUTION Control panel STANDBY/ON 32 51 INPUT MENU WIRELESS SECURITY LAMP TEMP 29 115 POWER QM00121-1...
  • Page 6 Introduction Part names (continued) Ports 12~21 COMPUTER IN AUDIO IN1 HDBaseT AUDIO IN2 L, R AUDIO OUT USB TYPE A MONITOR OUT HDMI 1 / MHL REMOTE CONTROL IN HDMI 2 REMOTE CONTROL OUT HDMI OUT CONTROL VIDEO WIRELESS QM00121-1...
  • Page 7 Introduction Part names (continued) Remote control INPUT MY BUTTON-1 MY BUTTON-2 STANDBY/ON MYBUTTON INPUT ASPECT ASPECT PbyP AUTO FREEZE PbyP MAGNIFY FOCUS ZOOM VOLUME AUTO FREEZE PAGE MAGNIFY ON GEOMETRY PICTURE MUTE FOCUS + DOWN INTERACTIVE NETWORK BLANK ZOOM + MENU VOLUME + ENTER...
  • Page 8: Setting Up

    Setting up...
  • Page 9 Setting up Arrangement User’s Manual (concise) Projector top Projector bottom...
  • Page 10 Setting up Arrangement (continued) WARNING Install the projector where you can access the power outlet easily. Do not subject the projector to unstable conditions. Do not install the pro things. Do not place the projector where any oils, such as cooking or machine oil, are used.
  • Page 11 Setting up Arrangement (continued) CAUTION ventilation. Avoid placing the projector in smoky, humid or dusty place. NOTICE NOTE QM00121-1...
  • Page 12 Setting up Connecting with your devices Network Guide WARNING Use only the appropriate accessories. CAUTION For a cable with a core at only one end, connect the end with the core to the projector. NOTE About Plug-and-Play capability COMPUTER IN QM00121-1...
  • Page 13 Setting up Connecting with your devices (continued) Computer Smartphone Tablet...
  • Page 14 Setting up Connecting with your devices (continued) NOTE QM00121-1...
  • Page 15 Setting up Connecting with your devices (continued) Computer External device Wireless adapter Access point...
  • Page 16 Setting up Connecting with your devices (continued) WARNING CAUTION QM00121-1...
  • Page 17 Setting up Connecting with your devices (continued) VCR/DVD/ Blu-ray Disc player...
  • Page 18 Setting up Connecting with your devices (continued) About HDBaseT™ connection NOTE HDMI HDMI QM00121-1...
  • Page 19 Setting up Connecting with your devices (continued) NOTE HDMI 1 / MHL QM00121-1...
  • Page 20 Setting up Connecting with your devices (continued) Speakers Another Monitor projector (Wired) Remote control...
  • Page 21 Setting up Connecting with your devices (continued) NOTE REMOTE CONTROL IN REMOTE CONTROL OUT REMOTE CONTROL IN REMOTE CONTROL IN QM00121-1...
  • Page 22 Setting up Fastening the cables screw No cable tie With cable tie HDMI cable cable tie holder WARNING CAUTION QM00121-1...
  • Page 23 Setting up Attaching the terminal cover QM00121-1...
  • Page 24 Setting up Using the security bar and slot Security slot 11mm 19mm 15mm security bar Anti-theft chain or wire WARNING CAUTION NOTE...
  • Page 25 Setting up Connecting power supply POWER WARNING NOTICE QM00121-1...
  • Page 26: Remote Control

    Remote control Installing the batteries WARNING QM00121-1...
  • Page 27 Remote control Changing the frequency of remote control signal MYBUTTON INPUT ASPECT PbyP AUTO FREEZE VOLUME - MAGNIFY MAGNIFY FOCUS ZOOM VOLUME VOLUME - RESET PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK RESET MENU MAGNIFY OFF ENTER OSD MSG RESET QM00121-1...
  • Page 28 Remote control About the remote control signal 30° 30° NOTE...
  • Page 29: Power On/Off

    Power on/off STANDBY/ON Turning on the power POWER POWER MYBUTTON INPUT ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU STANDBY/ON ENTER OSD MSG RESET POWER Selecting an input signal ENTER INPUT ENTER INPUT QM00121-1...
  • Page 30 Power on/off Turning off the power STANDBY/ON STANDBY/ON POWER POWER POWER WARNING NOTE QM00121-1...
  • Page 31: Operating

    Operating Adjusting the volume VOLUME + - VOLUME VOLUME INPUT MYBUTTON + / - ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET NOTE Temporarily muting the sound MUTE INPUT MYBUTTON...
  • Page 32 Operating Selecting an input signal INPUT INPUT COMPUTER IN HDMI 1 / MHL VIDEO HDBaseT HDMI 2 INPUT INPUT INPUT MYBUTTON ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET NOTE QM00121-1...
  • Page 33 Operating Selecting an aspect ratio ASPECT ASPECT ASPECT MYBUTTON INPUT ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET For a computer signal For HDMI , HDBaseT and MHL signals For a video signal For an input signal from the LAN port, or if there is no signal NOTE...
  • Page 34 Operating Adjusting the projector’s elevator 11° CAUTION ZOOM Adjusting the zoom and focus FOCUS ZOOM FOCUS...
  • Page 35 Operating Adjusting the lens shift VERTICAL VERTICAL HORIZONTAL HORIZONTAL V50% H4.6%: CP-WX5506M H4.4%: CP-WU5506M...
  • Page 36 Operating CAUTION QM00121-1...
  • Page 37 Operating Using the automatic adjustment feature AUTO AUTO AUTO INPUT MYBUTTON ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME For a computer signal PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET For a video signal For a component video signal NOTE QM00121-1...
  • Page 38 Operating Correcting the distortion GEOMETRY MYBUTTON INPUT GEOMETRY ASPECT PbyP AUTO FREEZE GEOMETRY MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET NOTE GEOMETRY ENTER KEYSTONE: ENTER NOTE ENTER QM00121-1...
  • Page 39 Operating Correcting the distortion (continued) PERFECT FIT: ENTER ENTER ENTER ENTER QM00121-1...
  • Page 40 Operating Correcting the distortion (continued) SAVE: ENTER LOAD: ENTER NOTE WARPING: QM00121-1...
  • Page 41 Operating Using the EDGE BLENDING features ENTER...
  • Page 42 Operating ENTER QM00121-1...
  • Page 43 Operating ENTER ENTER ENTER Input Image Cropping Input Image Cropping...
  • Page 44 Operating NOTE QM00121-1...
  • Page 45 Operating Using the magnify feature MAGNIFY ON MAGNIFY MAGNIFY MYBUTTON INPUT ASPECT PbyP AUTO FREEZE ON/OFF MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET MAGNIFY ON MAGNIFY ON For computer signals, HDMI (RGB) signals, HDBaseT signals, input signals from the LAN port...
  • Page 46 Operating Temporarily freezing the screen FREEZE FREEZE MYBUTTON INPUT FREEZE ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET FREEZE NOTE Temporarily blanking the screen BLANK INPUT MYBUTTON ASPECT PbyP AUTO...
  • Page 47: Pbyp (Picture By Picture)

    Operating PbyP (Picture by Picture) / PinP (Picture in Picture) PbyP INPUT MYBUTTON PbyP ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET PbyP PbyP PbyP PbyP NOTE PbyP MENU QM00121-1...
  • Page 48 Operating PbyP (Picture by Picture) / PinP (Picture in Picture) (continued) Setting information Changing the main area QM00121-1...
  • Page 49 Operating PbyP (Picture by Picture) / PinP(Picture in Picture) (continued) Changing the picture input signal INPUT NOTE QM00121-1...
  • Page 50 Operating PbyP (Picture by Picture) / PinP (Picture in Picture) (continued) PbyP /PinP SWAP function MY BUTTON NOTE Changing the size of main area in PbyP mode Changing the position of sub area in PinP mode QM00121-1...
  • Page 51: Menu

    Operating Using the menu function MENU MENU INPUT MENU MYBUTTON INPUT ASPECT PbyP AUTO FREEZE MAGNIFY FOCUS ZOOM VOLUME PAGE GEOMETRY PICTURE MUTE ENTER DOWN INTERACTIVE NETWORK BLANK MENU ENTER OSD MSG RESET OSD MSG RESET ENTER RESET MENU In the EASY MENU In the ADVANCED MENU ENTER ENTER...
  • Page 52 Operating Using the menu function (continued) MENU ENTER NOTE RESET Indication in OSD (On Screen Display) Indication Meaning MENU QM00121-1...
  • Page 53 Operating Using the menu function (continued) Containing items of each menu Menu Items EASY MENU PICTURE IMAGE INPUT SETUP AUDIO SCREEN OPTION NETWORK SECURITY QM00121-1...
  • Page 54: Easy Menu

    EASY MENU Item Description ASPECT KEYSTONE PERFECT FIT PICTURE MODE ® QM00121-1...
  • Page 55 EASY MENU Item Description ECO MODE INSTALLATION RESET FILTER TIME LANGUAGE ENTER ADVANCED MENU EXIT ENTER QM00121-1...
  • Page 56: Picture Menu

    PICTURE menu ENTER Item Description BRIGHTNESS CONTRAST COLOR TINT SHARPNESS QM00121-1...
  • Page 57 PICTURE menu Item Description ACTIVE IRIS ENTER PICTURE MODE PICTURE QUALITY GAMMA QM00121-1...
  • Page 58 PICTURE menu Item Description GAMMA (continued) ENTER COLOR TEMP PICTURE QUALITY (continued) ENTER QM00121-1...
  • Page 59 PICTURE menu Item Description ACCENTUALIZER PICTURE QUALITY (continued) HDCR ENTER MY MEMORY MY BUTTON QM00121-1...
  • Page 60: Image Menu

    IMAGE menu ENTER Item Description For a computer signal For HDMI , HDBaseT™, and MHL signals ASPECT For a video signal For an input signal from the LAN port, or if there is no signal QM00121-1...
  • Page 61 IMAGE menu Item Description OVER SCAN RESET V POSITION above • LAN HDMI 1 / MHL, HDMI 2 or HDBaseT RESET H POSITION above • LAN HDMI 1 / MHL, HDMI 2 or HDBaseT QM00121-1...
  • Page 62 IMAGE menu Item Description H PHASE LAN VIDEO HDMI 1 / MHL, HDMI 2 or HDBaseT LAN VIDEO HDMI 1 / MHL, HDMI 2 or HDBaseT H SIZE RESET For a computer signal For a video signal AUTO ADJUST EXECUTE QM00121-1...
  • Page 63: Input Menu

    INPUT menu ENTER Item Description PROGRESSIVE VIDEO NR COLOR SPACE QM00121-1...
  • Page 64 INPUT menu Item Description VIDEO VIDEO FORMAT VIDEO HDMI 1/MHL, HDMI2 HDBaseT DIGITAL FORMAT QM00121-1...
  • Page 65 INPUT menu Item Description HDMI 1 MHL, HDMI 2 HDBaseT DIGITAL RANGE COMPUTER IN COMPUTER IN FRAME LOCK QM00121-1...
  • Page 66 INPUT menu Item Description COMPUTER IN ENTER RESOLUTION ENTER ENTER QM00121-1...
  • Page 67 INPUT menu Item Description PinP POSITION PbyP / PinP FRAME LOCK PbyP / PinP SETUP MHL STANDBY PWR. QM00121-1...
  • Page 68: Setup Menu

    SETUP menu ENTER Item Description KEYSTONE Correcting the distortion PERFECT FIT GEOMETRY CORRECTION Correcting the distortion WARPING EDGE BLENDING 41 ~ 44 QM00121-1...
  • Page 69 SETUP menu Item Description PATTERN GEOMETRY CORRECTION (continued) ENTER ECO MODE LAMP & FILTER LAMP TIME RESET Replacing the lamp QM00121-1...
  • Page 70 SETUP menu Item Description FILTER TIME LAMP & FILTER RESET FILTER MESSAGE LAMP & FILTER (continued) IMAGE OPTIMIZER QM00121-1...
  • Page 71 SETUP menu Item Description PICTURE POSITION INSTALLATION ENTER INPUT QM00121-1...
  • Page 72 SETUP menu Item Description STANDBY MODE COLOR UNIFORMITY QM00121-1...
  • Page 73 SETUP menu Wake On LAN (WOL) function Operation QM00121-1...
  • Page 74 SETUP menu Item Description OSD MESSAGE FREEZE OSD MSG OSD MSG QM00121-1...
  • Page 75 SETUP menu Item Description HDMI OUTPUT STANDBY OUTPUT QM00121-1...
  • Page 76: Audio Menu

    AUDIO menu ENTER Item Description VOLUME SPEAKER AUDIO OUT AUDIO SOURCE AUDIO IN1 AUDIO IN2 HDMI 1 / MHL HDMI 2 HDBaseT VIDEO COMPUTER QM00121-1...
  • Page 77: Screen Menu

    SCREEN menu ENTER Item Description LANGUAGE ENTER MENU MENU POSITION Network Guide Network Guide BLANK BLANK QM00121-1...
  • Page 78 SCREEN menu Item Description AUTO BLANK START UP QM00121-1...
  • Page 79 SCREEN menu Item Description ENTER RESET MyScreen ENTER INPUT RESET INPUT • LAN, HDMI 1/ MHL, HDMI 2 or HDBaseT QM00121-1...
  • Page 80 SCREEN menu Item Description MyScreen Lock ENTER SOURCE NAME ENTER ENTER ENTER QM00121-1...
  • Page 81 SCREEN menu Item Description ENTER RESET ENTER SOURCE NAME continued ENTER ENTER ENTER ENTER MY BUTTON TEMPLATE RESET QM00121-1...
  • Page 82 SCREEN menu Item Description DISPLAY C.C. (Closed Caption) MODE CHANNEL QM00121-1...
  • Page 83: Option Menu

    OPTION menu ENTER Item Description below SOURCE SKIP AUTO SEARCH QM00121-1...
  • Page 84 OPTION menu Item Description DIRECT POWER below AUTO POWER CONTROL Turning off the power SHADE TIMER QM00121-1...
  • Page 85 OPTION menu Item Description MY BUTTON ENTER ENTER 6. My Image Function Network Guide 7. Messenger Function Network Guide MY BUTTON MY BUTTON QM00121-1...
  • Page 86 OPTION menu Item Description How to setup the item NOTE Item Description DATE & TIME SPECIFIC DATE PROGRAM EDIT How to activate (DATE AND TIME / SPECIFIC DATE) SCHEDULE QM00121-1...
  • Page 87 OPTION menu Item Description PROGRAM EDIT SCHEDULE (continued) RETURN SELECT COPY TO APPLY QM00121-1...
  • Page 88 OPTION menu Item Description How to edit the selected PROGRAM SCHEDULE (continued) NOTE QM00121-1...
  • Page 89 OPTION menu Item Description ENTER ALTITUDE AUTO ADJUST SERVICE GHOST * QM00121-1...
  • Page 90 OPTION menu Item Description KEY LOCK STANDBY/ON REMOTE RECEIV. REMOTE FREQ. 4 28 SERVICE (continued) REMOTE ID QM00121-1...
  • Page 91 OPTION menu Item Description CONTROL SERVICE COMMUNICATION (continued) Network Guide QM00121-1...
  • Page 92 OPTION menu Item Description COMMUNICATION TYPE CONTROL SERVICE COMMUNICATION (continued) (continued) CONTROL 8. Network Bridge Function Network Guide CONTROL QM00121-1...
  • Page 93 OPTION menu Item Description SERIAL SETTINGS CONTROL BAUD RATE PARITY SERVICE COMMUNICATION TRANSMISSION METHOD (continued) (continued) CONTROL QM00121-1...
  • Page 94 OPTION menu Item Description RESPONSE LIMIT TIME CONTROL SERVICE COMMUNICATION CONTROL (continued) (continued) STACK Instant Stack Guide QM00121-1...
  • Page 95 OPTION menu Item Description WIRED NETWORK HDBaseT NOTE HDBaseT CONTROL TERMINAL RS-232C CONTROL HDBaseT SERVICE (continued) NOTE CONTROL HDBaseT HDMI OUT RESOLUTION QM00121-1...
  • Page 96 OPTION menu Item Description MULTIMEDIA INFORMATION SERVICE (continued) FACTORY RESET QM00121-1...
  • Page 97: Network Menu

    NETWORK menu Network Guide QM00121-1...
  • Page 98: Security Menu

    SECURITY menu Enter to the SECURITY menu MC-WU5506M MC-WX5506M below If you have forgotten your password RESET INPUT Item Description SECURITY PASSWORD CHANGE ENTER QM00121-1...
  • Page 99 SECURITY menu Item Description 1 Turning on the MyScreen PASSWORD ENTER MyScreen PASSWORD 2 Turning off the MyScreen PASSWORD 3 If you have forgotten your password QM00121-1...
  • Page 100 SECURITY menu Item Description 1 Turning on the PIN LOCK ENTER INPUT PIN LOCK 2 Turning off the PIN LOCK 3 If you have forgotten your PIN code RESET INPUT QM00121-1...
  • Page 101 SECURITY menu Item Description 1 Turning on the TRANSITION DETECTOR ENTER TRANSITION DETECTOR ENTER 2 Turning off the TRANSITION DETECTOR 3 If you have forgotten your password QM00121-1...
  • Page 102 SECURITY menu Item Description 1 Turning on the MY TEXT PASSWORD MY TEXT PASSWORD ENTER 2 Turning off the MY TEXT PASSWORD 3 If you have forgotten your password QM00121-1...
  • Page 103 SECURITY menu Item Description ENTER MY TEXT DISPLAY ENTER RESET ENTER MY TEXT WRITING ENTER ENTER ENTER QM00121-1...
  • Page 104: Security

    SECURITY menu Item Description SECURITY INDICATOR SECURITY 100, 101 STACK LOCK Instant Stack Guide QM00121-1...
  • Page 105: Maintenance

    Maintenance Replacing the lamp Type number : DT01931 Replacing the lamp In case of replacement by yourself, follow the following procedure. 4, 5 MENU CAUTION NOTE QM00121-1...
  • Page 106 Maintenance Replacing the lamp (continued) Lamp warning HIGH TEMPERATURE HIGH PRESSURE HIGH VOLTAGE WARNING About disposal of a lamp: QM00121-1...
  • Page 107 Maintenance Type number : UX41161 4, 5 QM00121-1...
  • Page 108 Maintenance MENU ENTER RESET WARNING NOTE QM00121-1...
  • Page 109 Maintenance Installing or replacing the internal clock battery CR2032 CR2032H OPEN OPEN CLOSE 90° CLOSE 90° WARNING...
  • Page 110 Maintenance Other care Inside of the projector Caring for the lens QM00121-1...
  • Page 111 Maintenance Caring for the cabinet and remote control WARNING CAUTION NOTICE QM00121-1...
  • Page 112: Troubleshooting

    Troubleshooting WARNING Troubleshooting Related messages Message Description There is no input signal.
  • Page 113 Troubleshooting Related messages (continued) Message Description The horizontal or vertical frequency of the input An improper signal is input. The internal temperature is rising. User's Manual (concise) QM00121-1...
  • Page 114 Troubleshooting Related messages (continued) Message Description Cleaning and 70 108 The button operation is not available. QM00121-1...
  • Page 115 Regarding the indicator lamps Troubleshooting Regarding the indicator lamps Indicator Status Description The projector is in a standby state. Orange The projector is warming up. Green The projector is in an on state. Green The projector is cooling down. Orange...
  • Page 116 Regarding the indicator lamps Regarding the indicator lamps (continued) Indicator Status Description The projector is cooling down. A certain error has been detected. POWER discretionary The cooling fan is not operating. The lamp does not light. There is a possibility that interior portion has become heated.
  • Page 117 Regarding the indicator lamps Regarding the indicator lamps (continued) Indicator Status Description There is a possibility that the interior portion has become heated. Blinking at the same time Cleaning This is a Lamp Error. QM00121-1...
  • Page 118 Regarding the indicator lamps Regarding the indicator lamps (continued) Indicator Status Description PIN LOCK function or TRANSITION DETECTOR is active. Yellow There is a possibility that the interior portion Blinking has become overcooled. alternately Green AC BLACKOUT error has occurred. Green A wireless adapter is connected.
  • Page 119 Regarding the indicator lamps Regarding the indicator lamps (continued) NOTE SECURITY Resetting all settings QM00121-1...
  • Page 120 Troubleshooting Phenomena that may be easy to be mistaken for machine defects Reference Phenomenon Cases not involving a machine defect page The electrical power cord is not plugged in. The main power source has been interrupted during operation such as by a power outage (blackout), etc. Either there is no lamp and/or lamp cover, or either The signal cables are not correctly connected.
  • Page 121 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page The signal cables are not correctly connected. The volume is adjusted to an extremely low level. The AUDIO SOURCE/SPEAKER setting is not correct. The MUTE function is working.
  • Page 122 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page The batteries in the remote control are near the end. The FREEZE function is working. FREEZE Color settings are not correctly adjusted. COLOR SPACE setting is not suitable.
  • Page 123 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page The lens is dirty or misty. Caring for the lens When the projector is operating in Eco mode, When the vertical frequency of an input signal is The OVER SCAN ratio is too big.
  • Page 124 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page Blending Region is set. Blending - Mode is set to MANUAL. The SAVING/NETWORK(WOL) function is working. RS-232C is set to CONTROL. The SAVING/NETWORK(WOL) function is working.
  • Page 125 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page Check if the extension connector is compatible with CAT5e. HDBaseT The NETWORK BRIDGE function is turned off. The SAVING/NETWORK(WOL) function is working. The internal clock has been reset.
  • Page 126 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page Check if PROJECTOR is set in OPTION - SERVICE - HDMI OUT RESOLUTION. Check if EXTERNAL DEVICE is set in OPTION - SERVICE - HDMI OUT RESOLUTION.
  • Page 127 User’s Manual (concise) End User License Agreement for the Projector Software QM00121-1...
