LCD Projector MC-WU8460/MC-WX8265/MC-X8170 User's Manual (detailed) Operating Guide – Technical Example of computer signal Resolution (H x V) H. frequency (kHz) V. frequency (Hz) Rating Signal mode 720 x 400 37.9 85.0 VESA TEXT 640 x 480 31.5 59.9 VESA...
Page 2
Refer to the number of display pixels above. • Although the projector can display signals with a resolution up to UXGA (1600x1200) or up to W-UXGA (1920x1200) for MC-WU8460, the signal will be converted to the projector’s panel resolution before being displayed. The best display performance will be achieved if the resolutions of the input signal and projector panel are identical.
Page 3
Initial set signals Initial set signals The following signals are used for the initial settings. The signal timing of some computer models may be different. In such case, adjust the items V POSITION and H POSITION in the IMAGE menu. Back porch (B) Front porch (D) Back porch (b)
Page 4
Connection to the ports Connection to the ports NOTICE input ports of the projector are recessed. COMPUTER IN1 or IN2 can be output from the MONITOR OUT port. COMPUTER IN1, MONITOR OUT ⑪ ⑫ ⑬ ⑭ ⑮ ⑥ ⑦ ⑧ ⑨...
Page 6
Connection to the ports (continued) COMPONENT Cb/Pb, Cr/Pr RCA jack x3 • Component video signal, Analog: • System: 480i@60, 480p@60, 576i@50, 720p@50/60, 1080i@50/60, 1080p@50/60 S-VIDEO Mini DIN 4pin jack • S-video signal, Analog: • System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL(60Hz) Signal C (color signal) Y (brightness signal)
Page 7
Connection to the ports (continued) AUDIO IN1, AUDIO IN2 Ø3.5 stereo mini jack • AUDIO IN3 AUDIO OUT RCA jack x2 RCA jack x2 • • CONTROL ⑨ ⑧ ⑦ ⑥ D-sub 9pin plug ⑤ ④ ③ ② ① * About the details of RS-232C communication, please refer to the next section.
Connection to the ports (continued) RJ-45 jack ② ④ ⑥ ⑧ ① ③ ⑤ ⑦ * About the details of network communication, please refer to the Network Guide. Signal Signal Signal USB TYPE A USB TYPE B ④ ③ ④ ③ ② ①...
Page 9
Connection to the ports (continued) To input SCART RGB signal; RCA plugs SCART cable Audio R (plug) Audio L Video SCART connector (jack) To input SCART RGB signal to the projector, use a SCART to RCA cable. Connect the plugs refer to above ex. For more reference, please consult your dealer.
Page 10
RS-232C Communication RS-232C Communication When the projector connects to the computer by RS-232C communication, the projector can be controlled with RS-232C commands from the computer. For details of RS-232C commands, refer to RS-232C Communication / Network 19). command table ( Connection Turn off the projector and the computer.
Page 11
RS-232C Communication (continued) Communicaion settings 1. Protocol 19200bps, 8N1 2. Command format ("h" shows hexadecimal) Byte Number Command Header Data Header Data Setting Action Type code size code Packet Action <SET>Change setting to desired value [(cL)(cH)] (aL) (aH) 01h 00h (bL) (bH) (cL) (cH) by [(bL)(bH)].
RS-232C Communication (continued) 3. Response code / Error code ("h" shows hexadecimal) (1) ACK reply: 06h When the projector receives the Set, Increment, Decrement or Execute item by [Type], and it returns the code. (2) NAK reply: 15h When the projector cannot understand the received command, the projector returns the error code.
Command Control via the Network Command Control via the Network When the projector connects network, the projector can be controlled with RS-232C commands from the computer with web browser. For details of RS-232C commands, refer to RS-232C Communication / Network 19).
Page 14
Command Control via the Network Communicaion Port The following two ports are assigned for the command control. TCP #23 TCP #9715 Port Settings Click the [Enable] check box to open [Network Port open Control Port1 (Port: 23)] to use TCP #23. Default setting is “Enable”.
Command Control via the Network (continued) Command control settings [TCP #23] 1. Command format Same as RS-232C communication, refer to RS-232C Communicaton command format. 2. Response code / Error code ("h" shows hexadecimal) Four of the response / error code used for TCP#23 are the same as RS-232C Communication (1)~(4).
Page 16
Command Control via the Network (continued) 2. Response code / Error code ("h" shows hexadecimal) The connection ID is attached for the TCP#23's response / error codes are used. The connection ID is same as the sending command format. (1) ACK reply: 06h + ××h (××h : connection ID) (2) NAK reply: 15h + ××h (3) Error reply: 1Ch + 0000h + ××h...
Page 17
Network Bridge Communication Network Bridge Communication This projector is equipped with NETWORK BRIDGE function. When the projector connects to the computer by wired or wireles LAN communicaton, an external device that is connected with this projector by RS- 232C communication can be controlled from the computer as a network terminal. For details, see the 6.
Network Bridge Communication Communication settings For communication setting, use the COMMUNICATION menu in the OPTION - SERVICE menu Item Condition BAUD RATE 4800bps / 9600bps / 19200bps / 38400bps Data length PARITY NONE/ODD/EVEN Start bit Stop bit Transmission method HALF-DUPLEX/FULL-DUPLEX NOTE •...
Page 19
RS-232C Communication / Network command table RS-232C Communication / Network command table Command Data Names Operation Type Header Action Type Setting code Turn off BE EF 06 00 2A D3 01 00 00 60 00 00 Turn on BE EF 06 00 BA D2 01 00...
Page 20
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code LENS MEMORY BE EF 06 00 A0 91 02 00 0D 24 00 00 LENS SHIFT - V LENS MEMORY BE EF 06 00 E4 91 02 00 0E 24...
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code TOP LEFT BE EF 06 00 02 23 01 00 01 23 00 00 TOP RIGHT BE EF 06 00 92 22 01 00 01 23 01 00 PinP POSITION...
Page 22
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 FD D3 02 00 04 20 00 00 Increment BE EF 06 00 9B D3 04 00 04 20 00 00 CONTRAST Decrement...
Page 23
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 08 FE 02 00 90 30 00 00 User GAMMA Increment BE EF 06 00 6E FE 04 00 90 30 00 00 Point 1...
Page 24
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code 1 HIGH BE EF 06 00 0B F5 01 00 B0 30 03 00 1 CUSTOM BE EF 06 00 CB F8 01 00 B0 30 13 00 2 MID...
Page 25
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code COLOR Reset Execute BE EF 06 00 80 D0 06 00 0A 70 00 00 BE EF 06 00 49 73 02 00 03 22 00 00 TINT...
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 F1 82 02 00 01 21 00 00 Increment BE EF 06 00 97 82 04 00 01 21 00 00 H POSITION Decrement...
Page 27
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code AUTO BE EF 06 00 BA 77 01 00 13 22 00 00 VIDEO BE EF 06 00 2A 76 01 00 13 22 01 00 HDMI 1 FORMAT...
Page 28
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code Disable BE EF 06 00 FE 88 01 00 20 21 00 00 PERFECT FIT Enable BE EF 06 00 6E 89 01 00 20 21 01 00 BE EF...
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 31 97 02 00 41 21 00 00 * PERFECT FIT Increment BE EF 06 00 57 97 04 00 41 21 00 00 Left Side...
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code NORMAL BE EF 06 00 D6 D2 01 00 01 60 00 00 STANDBY SAVING BE EF 06 00 46 D3 01 00 01 60 01 00 MODE...
Page 31
RS-232C Communication / Network command table (continued) RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 CD CC 02 00 60 20 00 00 VOLUME - Increment BE EF 06 00 AB CC 04 00...
Page 32
RS-232C Communication / Network command table (continued) RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code AUDIO IN1 BE EF 06 00 6E DC 01 00 30 20 01 00 AUDIO IN2 BE EF 06 00 9E DC...
Page 33
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code AUDIO IN1 BE EF 06 00 D6 DD 01 00 32 20 01 00 AUDIO IN2 BE EF 06 00 26 DD 01 00 32 20 02 00 AUDIO...
Page 34
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code TÜRKÇE BE EF 06 00 07 D6 01 00 05 30 0F 00 DANSK BE EF 06 00 A7 DF 01 00 05 30 11 00 BE EF 06 00...
Page 35
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 3B EF 01 00 C0 30 00 00 MyScreen Lock BE EF 06 00 AB EE 01 00 C0 30 01 00 BE EF 06 00...
Page 36
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code NORMAL BE EF 06 00 BA 78 01 00 23 22 00 00 SOURCE SKIP - SKIP BE EF 06 00 2A 79 01 00 23 22 01 00...
Page 37
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code SLIDESHOW BE EF 06 00 9A 2B 01 00 00 36 22 00 MY IMAGE BE EF 06 00 5A 3D 01 00 00 36 16 00 MESSENGER...
Page 38
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code SLIDESHOW BE EF 06 00 22 2A 01 00 02 36 22 00 MY IMAGE BE EF 06 00 E2 3C 01 00 02 36 16 00 MESSENGER...
Page 39
RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 FF 32 01 00 00 26 00 00 REMOTE BE EF 06 00 6F 33 01 00 00 26 01 00 RECEIV.
PJLink command PJLink command Commands Control Description Parameter or Response 0 = Standby POWR Power Contorol 1 = Power On 0 = Standby 1 = Power On POWR ? Power Status inquiry 2 = Cool Down 11 = COMPUTER IN1 12 = COMPUTER IN2 21 = COMPONENT 22 = S-VIDEO...
Page 41
INF1 ? Brand Name inquiry MAXELL MC-X8170 MC-WX8265 INF2 ? Model Name inquiry MC-WU8460 Responds with the factory information and so INFO ? Other Information inquiry CLSS ? Class Information inquiry 1 NOTE • The password used in PJLink is the same as the password set in the Web Control.
