AC Servo Drive
Rotary Servomotor
Safety Precautions
Type SGM
-
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end
user receives this manual.
MANUAL NO. TOEP C230260 00A

Advertisement

Table of Contents
loading

Related Manuals for YASKAWA SGM Series

Summary of Contents for YASKAWA SGM Series

  • Page 1 AC Servo Drive Rotary Servomotor Safety Precautions Type SGM To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance. Ensure the end user receives this manual. MANUAL NO. TOEP C230260 00A...
  • Page 2 Yaskawa. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.

  • Page 3: Before You Use The Product

    Please check the model number on the nameplate to confirm that you have received the correct model of Servomotor. If you have received the wrong model or if the Servomotor is damaged in any way, please contact your Yaskawa representative.  Part Names Encoder...

  • Page 4: Safety Information

    Safety Precautions  Safety Information To prevent personal injury and equipment damage in advance, the following signal words are used to indicate safety precautions in this document. The signal words are used to classify the hazards and the degree of damage or injury that may occur if a product is used incorrectly.
  • Page 5  Safety Precautions That Must Always Be Observed  General Precautions DANGER • Read and understand this manual to ensure the safe usage of the product. • Keep this manual in a safe, convenient place so that it can be referred to when- ever necessary.
  • Page 6 NOTICE • Do not attempt to use a SERVOPACK or Servomotor that is damaged or that has missing parts. • Install external emergency stop circuits that shut OFF the power supply and stops operation immediately when an error occurs. • Select the brake power supply for a Servomotor with a Holding Brake accord- ing to the power supply voltage and capacity required for the Servomotor model, as given in manuals and catalogs.
  • Page 7 If you store the product for more than six months, reapply an anticorrosive coating to machined surfaces, particularly the motor shaft. • Consult with your Yaskawa representative if you have stored products for an extended period of time. ...
  • Page 8 NOTICE • A SERVOPACK or Servomotor is a precision device. Do not drop it or subject it to strong shock. There is a risk of failure or damage. • Do not subject connectors to shock. There is a risk of faulty connections or damage. •...
  • Page 9 Continued from previous page. CAUTION • Do not step on or place a heavy object on the product. There is a risk of failure, damage, or injury. • Do not allow any foreign matter to enter the SERVOPACK or Servomotor. There is a risk of failure or fire.
  • Page 10 Continued from previous page. NOTICE • A Servomotor is a precision device. Do not subject the output shaft or the main body of the Servomotor to strong shock. • Design the machine so that the thrust and radial loads on the motor shaft during operation do not exceed the allowable values given in the catalog.
  • Page 11  Wiring Precautions DANGER • Do not change any wiring while power is being supplied. There is a risk of electric shock or injury. WARNING • Wiring and inspections must be performed only by qualified engineers. There is a risk of electric shock or product failure. •...
  • Page 12 • Whenever possible, use the Cables specified by Yaskawa. If you use any other cables, confirm the rated current and application environ- ment of your model and use the wiring materials specified by Yaskawa or equivalent materials. • Securely tighten cable connector screws and lock mechanisms.
  • Page 13  Operation Precautions WARNING • Before starting operation with a machine connected, change the settings of the switches and parameters to match the machine. Unexpected machine operation, failure, or personal injury may occur if opera- tion is started before appropriate settings are made. •...
  • Page 14 Continued from previous page. CAUTION • When overtravel occurs, the power supply to the motor is turned OFF and the brake is released. If you use the Servomotor to drive a vertical load, set the Servomotor to enter a zero-clamped state after the Servomotor stops. Also, install safety devices (such as an external brake or counterweight) to prevent the moving parts of the machine from falling.
  • Page 15 WARNING • Wiring and inspections must be performed only by qualified engineers There is a risk of electric shock or product failure. • If you replace a Servomotor with a Holding Brake, secure the machine before you replace the Servomotor. There is a risk of injury or equipment damage if the equipment falls.

  • Page 16: Warranty

    We will update the document number of the document and issue revisions when changes are made. • Any and all quality guarantees provided by Yaskawa are null and void if the customer modifies the product in any way. Yaskawa disavows any responsibil- ity for damages or losses that are caused by modified products.

  • Page 17: Limitations Of Liability

     Limitations of Liability • Yaskawa shall in no event be responsible for any damage or loss of opportunity to the customer that arises due to failure of the delivered product. • Yaskawa shall not be responsible for any programs (including parameter settings) or the results of program execution of the programs provided by the user or by a third party for use with programmable Yaskawa products.
  • Page 18  Suitability for Use • It is the customer’s responsibility to confirm conformity with any standards, codes, or regulations that apply if the Yaskawa product is used in combination with any other products. • The customer must confirm that the Yaskawa product is suitable for the systems, machines, and equipment used by the customer.

  • Page 19: Product Handling Precautions

    1 Product Handling Precautions Product Handling Precautions Handling Servomotors Observe the following precautions when you handle Servomotors. • Do not subject the Servomotor to shock. • Do not hold onto the motor shaft or cables when you move the Servomotor. Servomotor Installation Environment Install the Servomotor in the following environments.
  • Page 20 1 Product Handling Precautions • The surrounding air humidity is 20% to 80% relative humidity (with no condensation). • The vibration resistance (vibration acceleration rate) of the Servomotor is based on the flange surface of the Servomotor. The vibration resistance depends on the model.
  • Page 21 The protection class of a Servomotor depends on the model and option specifi- cations of the Servomotor. Confirm the protection class of your Servomotor in the Servomotor manual or catalog, or on Yaskawa’s product and technical information website (http:// www.emechatronics.com/). Observe the following precautions in reference to the protective structure (pro- tection class).
  • Page 22 1 Product Handling Precautions • The protective structure does not apply to the connectors (shown below with dotted circle) on Servomotors that have cables attached. Specified connectors Shaft opening Medium-Capacity Servomotors Specified connectors Connectors Shaft opening Shaft opening Small-Capacity Servomotors with Cables Attached Small-Capacity Servomotors without Cables E-20...

  • Page 23: Handling Cables

    (http://www.emechatronics.com/). If the application environment makes it difficult to provide an appropriate size of heat sink, contact your Yaskawa representative. Do not place packing or any other insulating material between the Servomotor and heat sink. Doing so will cause the motor temperature to increase, affect resistance to noise, and may cause motor failure.
  • Page 24 Main Circuit Cable connector first ( in the following figure) and then con- nect the Encoder Cable connector ( in the following figure). Servomotor Main Circuit Cable Encoder Cable • Always use the connectors specified by Yaskawa and insert them correctly. Specified connectors Connecting the Servomotor and Machine  Using a Coupling •...
  • Page 25 1 Product Handling Precautions in the manual. • When you attach the key to the motor shaft, do not subject the key slot to direct shock. Enlargement Key slot • When you attach the coupling, do not subject the shaft to shock. When you attach the load, do not exceed the allowable value of the thrust load or radial load specified in the manual or catalog.
  • Page 26 1 Product Handling Precautions • Select a suitable size of coupling for the operating conditions. A coupling that is too large or too small may cause damage. 0.03 mm max. • Rotate both shafts when you center the coupling. • We recommend that you use a dial gauge to check the accuracy of centering, but if using one is not possible, slide the coupling along both shafts and make adjustments so that it does not catch.
  • Page 27 1 Product Handling Precautions • Measure the belt tension at 45 intervals of the shafts. Turn the shafts and take measurements with a belt tension meter at each point. Turn to 45˚ intervals. Belt 8888 Servomotors with Oil Seals If the Servomotor is used where the shaft opening is subject to oil mist, use a Servomotor with an Oil Seal.
  • Page 28 1 Product Handling Precautions Using a Holding Brake The holding brake is designed to hold the motor in place. Do not use it to stop the motor. If you use the holding brake to stop the motor, the holding brake or encoder may be damaged.
  • Page 29 1 Product Handling Precautions  Play of the Output Shaft for Servomotors with Holding Brakes The following condition does not indicate a failure in the Servomotor. There is backlash in the holding brake even when power is not being supplied to the holding brake.

  • Page 30: Maintenance And Inspection

    • All inspection and maintenance work must be performed only by qualified engineers. There is a risk of electric shock or injury. • Contact your Yaskawa representative for help with failures, repairs, or part replacement. Basic Inspection and Main- Item...
  • Page 31 FG.) The insulation is normal if the resistance is 10 M or higher. This inspection Replace the At least once every Contact your Yaskawa rep- applies only to oil seal. 5,000 hours resentative. Servomotors with Oil Seals. At least once every...
  • Page 32  Standard Service Life of Product The following table gives the standard service lives of the parts of the Servo- motor. Contact your Yaskawa representative using the following table as a guide. After an examination of the part in question, we will determine whether the part should be replaced.

  • Page 33: Revision History

    Revision History The revision dates and numbers of the revised manuals are given at the bottom of the back cover. MANUAL NO. TOBP C230260 00A <1> Revision number Published in Japan August 2014 Date of publication   Date of Rev.
  • Page 34 E-32...
