Keysight N9355B/C/F and
N9356B/C Power Limiter
Operating and
Service Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N9355B and is the answer not in the manual?

Questions and answers

Related Manuals for Keysight Technologies N9355B

Summary of Contents for Keysight Technologies N9355B

  • Page 1 Keysight N9355B/C/F and N9356B/C Power Limiter Operating and Service Manual...
  • Page 2 Federal Acqui- DOCUMENT IS PROVIDED “AS IS,” sition Regulation (“FAR”) 2.101. Pursu- AND IS SUBJECT TO BEING © Keysight Technologies 2019 ant to FAR 12.212 and 27.405-3 and CHANGED, WITHOUT NOTICE, IN No part of this manual may be repro- Department of Defense FAR Supple- FUTURE EDITIONS.

  • Page 3: Waste Electrical And Electronic Equipment Directive 2002/96/Ec

    Waste Electrical and Electronic Equipment Directive 2002/96/EC This instrument complies with the WEEE Directive (2002/96/EC) marking requirement. This affixed product label indicates that you must not discard this electrical or electronic product in domestic household waste. Product Category With reference to the equipment types in the WEEE directive Annex 1, this instrument is classified as a “Monitoring and Control Instrument”...

  • Page 4: Sales And Technical Support

    Sales and Technical Support To contact Keysight for sales and technical support, refer to the support links on the following Keysight websites: – www.keysight.com/find/power-limiters (product-specific information and support, software and documentation updates) – www.keysight.com/find/assist (worldwide contact information for repair and service) Keysight N9355x and N9356x Power Limiter Operating and Service Manual...

  • Page 5: Table Of Contents

    Table of Contents Waste Electrical and Electronic Equipment Directive 2002/96/EC ..3 Product Category ........3 Printing Copies of this Document .
  • Page 6 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK Keysight N9355x and N9356x Power Limiter Operating and Service Manual...

  • Page 7: General Information

    Keysight N9355x and N9356x Power Limiters Operating and Service Manual General Information Power Limiter Overview Key Features This chapter provides an overview of the Keysight N9355x and N9356x Power Limiters.

  • Page 8: Power Limiter Overview

    Table 1-1 List of Power Limiters Model Frequency Range Typical Limiting Threshold Connector Type N9355B 10 MHz to 18 GHz 10 dBm Type N (m), (f) N9355C 10 MHz to 26.5 GHz 10 dBm 3.5 mm (m), (f)

  • Page 9: Specifications

    Keysight N9355x and N9356x Power Limiter Operating and Service Manual Specifications Specifications Environmental Specifications This chapter provides the specifications of the power limiters. Specifications describe the warranted performance of the power limiters.

  • Page 10: Specifications Specifications

    Typical characteristics are included for additional information only and they are not specifications. These are denoted as “typical”, “nominal” or “approximate” and are printed in italics. Table 2-2 RF Specifications for N9355B and N9356B Power Limiters Keysight Model Number N9355B N9356B...
  • Page 11 Specifications Table 2-3 RF Specifications for N9355C and N9356C Power Limiters Keysight Model Number N9355C N9356C Frequency Range 10 MHz to 26.5 GHz Insertion Loss <2.00 dB <2.25 dB >15 dB (1.43) Return Loss (VSWR) Maximum Continuous Input Power Limiting Threshold 10 dBm (typical) 25 dBm (typical) 24 dBm...
  • Page 12 Specifications Table 2-4 RF Specifications for N9355F Power Limiter Keysight Model Number N9355F Frequency Range 10 MHz to 50 GHz <2.00 dB (10 MHz to 26.5 GHz) Insertion Loss <2.75 dB (26.5 GHz to 40 GHz) <3.50 dB (40 GHz to 50 GHz) >10 dB (1.92) Return Loss (VSWR) Maximum Continuous Input Power...
  • Page 13 Specifications Figure 2-1 illustrates the typical insertion loss and return loss of N9355B and N9356B below the limiting threshold. Figure 2-1 Typical Insertion Loss and Return Loss of N9355B and N9356B Keysight N9355x and N9356x Power Limiter Operating and Service Manual...
  • Page 14 Specifications Figure 2-2 illustrates the typical insertion loss and return loss of N9355C and N9356C below the limiting threshold. Figure 2-2 Typical Insertion Loss and Return Loss of N9355C and N9356C Keysight N9355x and N9356x Power Limiter Operating and Service Manual...
  • Page 15 Specifications Figure 2-3 illustrates the typical insertion loss and return loss of N9355F below the limiting threshold. Figure 2-3 Typical Insertion Loss and Return Loss of N9355F Keysight N9355x and N9356x Power Limiter Operating and Service Manual...
  • Page 16 Specifications Power limiting is non-linear and depends on the input power and the ambient temperature. The typical measurements shown on Figure 2-4 are measured at ambient temperature of 25 Figure 2-4 Typical Output Power Versus Input Power Keysight N9355x and N9356x Power Limiter Operating and Service Manual...

  • Page 17: Environmental Specifications

    Specifications Environmental Specifications The N9355B/C/F and N9356B/C power limiters are designed to fully comply with Keysight Technologies’ product environmental specifications as shown in Table 2-5. Table 2-5 N9355B/C/F and N9356B/C Power Limiters Environmental Specifications Parameter Specification Temperature C to +55 –...
  • Page 18 Specifications THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK Keysight N9355x and N9356x Power Limiter Operating and Service Manual...

  • Page 19: Installation

    Keysight N9355x and N9356x Power Limiter Operating and Service Manual Installation Installation Operating and Service Instruction This chapter provides you installation information and simple verification steps of the power limiters.

  • Page 20: Initial Inspection

    Installation Installation Initial Inspection 1 Inspect the shipping container for damage. If the shipping container or cushioning material is damaged, it should be kept until the contents of the shipment have been checked for completeness and the instrument has been checked both mechanically and electrically.

  • Page 21: Operating And Service Instruction

    The operator’s check is supplied to allow the operator to make a quick check on the power limiters prior to use or if a failure is suspected. DO NOT apply more than 1W average power for N9355B/C, 0.63W average CAUTION power for N9355F, 6W average power for N9356B and 4W average power for N9356C.

  • Page 22: S-Parameter Measurement

    Installation The limiting threshold of the power limiter can be measured using a signal source, a power sensor, a power meter and an attenuator as illustrated in Figure 3-6. Please check the maximum input power of the power sensor. If the output power NOTE from the power limiter exceeds the maximum input power of the power sensor, an attenuator is required to avoid damaging the power sensor.

  • Page 23: Limiting Threshold Measurement

    1 Increase signal source power slowly from below 10 dBm to 30 dBm for N9355B/C/F, or from 25 dBm to 35 dBm for N9356B/C, and observe the output power. 2 Compare your results with the graphs in Figure 2-4.
  • Page 24 Installation THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK Keysight N9355x and N9356x Power Limiter Operating and Service Manual...
  • Page 25 This information is subject to change without notice. Always refer to the English version at the Keysight website for the latest revision. © Keysight Technologies 2019 Edition 4, April 30, 2019 Printed in Malaysia N9355-90001 www.keysight.com...
