YVL/301I e/and YVC/301I
Manuale di Installazione
IT
Installation Manual
EN
24801762 – 22-11-2012

Advertisement

loading

Related Manuals for Bpt YVL/301I

Summary of Contents for Bpt YVL/301I

  • Page 1 YVL/301I e/and YVC/301I Manuale di Installazione Installation Manual 24801762 – 22-11-2012...

  • Page 3: Installazione

    - INSTALLAZIONE - INSTALLATION ATTENZIONE. Si raccomanda di installare il moni- WARNING. It is recommended to install the moni- tor in ambiente asciutto. tor in a dry place. Aprire il videocitofono come indicato in figura 1 e 2. Open the video entry control as shown in figures 1 and Togliere il connettore (fig.

  • Page 4: Terminal Boards

    YVL/301I e/and YVC/301I HEVC/MI 18VDC Rosso Blue Blau Rouge Bleu Rojo Azul Vermelho Azul – Giallo Bianco Yellow White Gelb Weiß Blanc Jaune Blanco Amarillo Branco Amarelo MODELLO PRECEDENTE PREVIOUS MODEL YVL/301I e/and YVC/301I HEVC/MI 18VDC – – NUOVO MODELLO...
  • Page 5 Temperatura di funzionamento - Operating temperature 0 °C +35 °C Grado IP - IP Degree IP 20 YVL/301I CCIR (EIA) Standard video - Standard video YVC/301I PAL YVL/301I CRT 4” (10 cm) Monitor - Monitor YVC/301I LCD TFT 3,5”, 4:3...
  • Page 6 - PROGRAMMAZIONE – - PROGRAMMING beep Ingresso in Programmazione. Sollevare la cornetta e preme- re per 5 volte il pulsante A entro 5 s. Un breve segnale acustico conferma l’ingresso in programmazione a. Accessing programming. Lift the receiver and press the but- ton A 5 times within 5 s.
  • Page 8 Components that qualify as recyclable waste feature the relevant symbol and the material’s abbreviation. BPT S.p.A. Via Cornia, 1 33079 Sesto al Reghena-PN-Italy www.bpt.it-info@bpt.it...

This manual is also suitable for:

Yvc/301i
