  • Page 1 SuperCross-Laser SCL 3 Bedienungsanleitung 3 - 6 Operating instructions 7-10 Gebruiksaanwijzing 11-14 Betjeningsvejledning 15-18 Mode d´emploi 19-22 Instrucciones para su uso 23-26 Istruzioni d'uso 27-30 Instrukcja Obsługi 31-34 Käyttöohje 35-38 Instruções de uso 39-42 Bruksanvisning 43-46 Bruksanvisning 47-50 Kullanma kılavuzu...
  • Page 2 SuperCross-Laser SCL 3...

  • Page 3: General Safety Instructions

    SuperCross-Laser SCL 3 The automatic 3 line laser for professional do-it-yourself enthusiasts The 3 laser lines are readily visible and outstanding for aligning tiles, wall studding, windows, doors, etc. The 90° position of the vertical laser lines can be used to produce a right angle on the floor and project a plumb line on slanted walls (see Figure C on Pg.
  • Page 4 SuperCross-Laser SCL 3 1 Laser output windows 2 Battery compartment (SCL 3 underside) 3 Tripod/wall bracket with 63 mm height adjustment 4 ON / OFF switch, transport retainer 5 Laser line selection button 6 Height adjustment knob 7 Magnetic pin for unit centring...
  • Page 5 SuperCross-Laser SCL 3 Horizontal and vertical levelling: Open the battery compartment (2) and insert batteries according to the symbols. Correct polarity must be observed. Release the transport restraint, put the ON/OFF switch (4) into its right position ("ON" ). Now the tilt function is active and the indicator LED (11) will light up green if the device is set up correctly.
  • Page 6 SuperCross-Laser SCL 3 Preparing the calibration check: It is possible for you to check the calibration of the laser. To do this, position the device midway between 2 walls, which must be at least 5 metres apart. Do this by turning the unit on, thus releasing the transport restraint (cross laser on).
  • Page 7 Zubehör (optional) Lisämahdollisuuksia valinnaisvarusteilla Accessories (optional) Acessórios (opcional) Accessoires (optioneel) Tillbehör Tilbehør (ekstra-udstyr) Tilbehør Accessoires (en option) Faydalı aksesuarları Accesorios (opcional) Полезные принадлежности Accessori (optional) Akcesoria (opcja) Art.-Nr: 080.29 Art.-Nr: 023.61A Art.-Nr: 090.120A...
  • Page 8 SuperCross-Laser SCL 3 Laserstrahlung! Nicht in den Strahl blicken oder direkt mit optischen Instrumenten betrachten. Laser Klasse 2 M EN60825-1:2007-10 Laser radiation! Do not stare into the beam or observe it directly with optical instruments. Laser class 2 M EN60825-1:2007-10 Service- und Versand-Anschrift Serwis i sprzedaż...
