Fig. 7:
Installation of the corner cutter
Guide the corner cutter (no. 20, fig. 7) with the two sliding shoes (no. 22, fig. 7) into the guide profile (no. 21, fig. 7)
at the right side of the device, until the same stops at the locking bolt (no. 26, fig. 8). The corner cutter is now in ope-
rating position. Subsequently position the cord into the slot (no. 27, fig. 4 and fig. 8a) provided for this purpose at the
rear side of device. The corner cutter is now ready for operation.
29
20
28
22
21
Fig. 8a Fig. 8
26
