Lifebreath 1500I-ECM Installation Instruction

Lifebreath 1500I-ECM Installation Instruction

Interior/outdoor, exterior rooftop design, exterior horizontal ducting design
Hide thumbs Also See for 1500I-ECM:
Table of Contents

Advertisement

Quick Links

INTERIOR MODEL
1500I-ECM
Caution
Before installation, careful consideration must be
given
to
how
this
connected
to any other piece of mechanical
equipment, i.e. a forced air furnace or air handler,
operating at a higher static. After installation, the
compatibility of the two pieces of equipment must
be confirmed by measuring the airflows of the
Heat Recovery Ventilator (HRV) by using the
balancing procedure found in this manual.
It
is
always
important
operation
of any
vented
combustion
Furnaces, Oil Furnaces, Wood Stoves, etc.).
NEVER install a ventilator in a situation where
its normal operation, lack of operation or partial
failure may result in the backdrafting or improper
functioning of vented combustion equipment!
Application
Heat Recovery Ventilators (HRV) are designed to provide
fresh air while exhausting an equal amount of stale air.
General
The HRV is equipped with an aluminum core. The
device uses the stale air that is being exhausted to
condition the fresh air as it is being brought in.
These instructions are intended as a general guide and
do not supersede local codes in any way. Consult
authorities who have jurisdiction before installation.
Do not apply electrical power to the unit
until installation has been fully completed
(including low voltage control wiring).
OUTDOOR MODELS
1500E-ECM (EXTERIOR ROOFTOP DESIGN)
1500E-ECM-E (EXTERIOR HORIZONTAL DUCTING DESIGN)
system
will
operate
to
assess
how
HRV
may
interact
equipment
(ie.

Table of Contents

if
General........................................................................1
Engineering Data.......................................................2-4
Duct Configurations .....................................................5
Optional Ventilation Control
Optional 3 Speed Control .............................................6
Optional Dehumidistat .................................................7
Connecting Optional Ventilation Control ........................8
the
Connecting Optional Dehumidistat ................................9
with
Optional Timers ....................................................10-12
Gas
Function and Controls .................................................13
Aircom Relays ............................................................14
Servicing.....................................................................15
Mounting the 1500......................................................16
Roof Curb Assembly Instructions ..................................17
Roof Curb Detail .........................................................18
Ducting -- General ......................................................19
Balancing....................................................................20
The Integrated HVAC System ......................................21
Defrost Time Adjustment ............................................22
Pitot Tube Air Flow Balancing ......................................23
Wiring Diagram...........................................................24
Warranty ...................................................................25
* LEAVE WITH EQUIPMENT
NOTE: Due to ongoing research and product development,
specifications, ratings and dimensions are subject to change without notice.
69-1500
012616

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1500I-ECM and is the answer not in the manual?

Questions and answers

Related Manuals for Lifebreath 1500I-ECM

Summary of Contents for Lifebreath 1500I-ECM

  • Page 1: Table Of Contents

    INTERIOR MODEL OUTDOOR MODELS 1500I-ECM 1500E-ECM (EXTERIOR ROOFTOP DESIGN) 1500E-ECM-E (EXTERIOR HORIZONTAL DUCTING DESIGN) Caution Table of Contents Before installation, careful consideration must be Application given this system will operate General................1 connected to any other piece of mechanical Engineering Data............2-4 equipment, i.e.
