  • Page 1 Installation instructions VWZ MPS 40...
  • Page 2 Installation instructions For the competent person Installation instructions For the operator Instructions for use VWZ MPS 40...
  • Page 3 Safety ..............17 Symbols used ............17 Qualifi cations ............17 General safety advices ..........17 Intended use ............17 Regulations (directives, laws, standards) ....18 Notes on the documentation ........19 Observe other applicable documents ......19 Storing documents ..........19 Validity of the instructions ........19 Description of the product ........19 Product structure .............19 Type designation and serial number .......19 Data plate description ..........19...

  • Page 4: Safety

    Children must not play with the product. guidelines. Cleaning and user maintenance work must not be carried out by children unless they are supervised. 0020153953_05 - 03/15 - Vaillant...
  • Page 5 Any direct commercial or industrial use is also deemed to be improper. Regulations (directives, laws, standards) Please observe the existing national rules ► and regulations, standards, laws and guidelines. 0020153953_05 - 03/15 - Vaillant...

  • Page 6: Notes On The Documentation

    Code Product code of the appliance Central heating maximum pressure Sleeve for temperature Connector 1" sensor Connector 1"1/4 (temperature sensor VR 10 not supplied) Connector 1"1/4 Connector 1" Connector 1" Connector 1" 0020153953_05 - 03/15 - Vaillant...

  • Page 7: Mounting And Installation

    This will ensure that the connections to the water can be accessed and inspected. Additional clearances around the appliance may be advantageous for its installation and maintenance. >600* mini. mini. Notes * Clearance necessary for the installation or maintenance of the appliance. 0020153953_05 - 03/15 - Vaillant...

  • Page 8: Mounting The Product

    Foreign bodies such as welding remnants, sealing residue or dirt in the supply lines can cause damage Front casing to the product. ► Remove the front casing (1). Flush the supply lines thoroughly ► before installation. 0020153953_05 - 03/15 - Vaillant...

  • Page 9: Different Confi Gurations

    4.4.3 Case No 3 Connector G1" Connector G1" Connector G1" Connector G1"1/4 Connector G1" Connector G1"1/4 ► Only use the original seals supplied with the appliance. ► Connect the heating circuit as specifi ed. 0020153953_05 - 03/15 - Vaillant...

  • Page 10: Passage And Routing Of The Temperature Sensor Cable

    ► Close the vent as soon as water fl ows (repeat the operation several times if necessary). Temperature sensor Temperature sensor housing cable passage Temperature sensor cable Notes The temperature probe must be assembled using thermal paste for good heat transfer. 0020153953_05 - 03/15 - Vaillant...

  • Page 11: Installing The Casing

    The genuine component parts of the product have been certifi ed together with the product in the course of the CE conformity check. If you do not use certifi ed genuine Vaillant spare parts during maintenance or repair, the CE conformity of the product will expire.
