- Page 1 Installation Instructions Temperature transmitters TA3xxx TA4xxx TA5xxx TU3xxx TU4xxx TU5xxx...
-
Page 2: Safety Instructions
1 Safety instructions • The device described is a subcomponent for integration into a system. - The manufacturer of the system is responsible for the safety of the system. - The system manufacturer undertakes to perform a risk assessment and to create a documentation in accordance with legal and normative requirements to be provided to the operator and user of the system. - Page 3 3 Function TAxxxx: Fig. 1: Current output In the measuring range the output I [mA] signal is between 4 and 20 mA. 20.6 If the temperature is above or below the measuring range, the analogue output behaves as follows: Temperature above the measuring range: 20...20.6 mA.
-
Page 4: Electrical Connection
The national and international regulations for the installation of electrical equipment must be adhered to. Voltage supply to EN 50178, SELV, PELV. ► Disconnect power. ► Connect the unit as follows: TA3xxx OUT: analogue output 4...20 mA TA4xxx DEUTSCH DT04-3P → Datasheet at www.ifm.com OUT: analogue output 4...20 mA... -
Page 5: Technical Data
OUT: analogue output 0.5...4.5 V Colours to DIN EN 60947-5-2 BK: black, BN: brown, BU: blue, WH: white 6 Operation After power on, the unit is in the Run mode (= normal operating mode). 7 Technical data Technical data and scale drawing at www.ifm.com.
