Knape & Vogt TDRO-CW Installation Instructions

Parts Included

A. Tray Dividers
B. Pre-assembled Mounting Board
C. Mounting Screw Package
A.
B.
C.

Tools Required

• Phillips Screwdriver
• Measuring Tape
• Pencil
• Drill with 1/16˝ bit for pilot holes
(optional)

Product Assemblies

TDRO-CW
2700 Oak Industrial Drive NE , Grand Rapids, MI 49505 USA
800.253.1561 • 616.459.3311 • www.kv.com
WOOD & WIRE TRAY DIVIDER ROLL OUT

Installation Instructions

Inspect all parts and read all instructions prior to beginning assembly and installation.
Place sliding base assembly on cabinet
floor, right behind the back edge of the
cabinet face frame. If installing in a
frameless cabinet, measure 1/2" back
from front of cabinet opening, and align
sliding base assembly parallel to cabinet
opening. Close door to make sure the
assembly will not hold cabinet door open.
Also, check to see if unit will clear the
door opening when fully extended. Once
position is determined, extend mounting
board and fasten in place using four
mounting screws provided and the Phillips
head screwdriver.

Optional Step:

Mark placement of mounting holes with a
pencil, remove sliding base assembly and drill pilot
holes for fastening screws. Place sliding base
assembly back into position and fasten with the
provided screws.
Fit tray dividers onto mounting board. as shown in
Figure 2. Installation is now complete.
