Cub Cadet 19A40037100 Operator's Manual page 5

4
Slide Washers, Spacers and Wheels onto Stub Axles and install Cotter Pin.
Bend legs of Cotter Pin to secure.
5
Align holes in Swivel Clevis and
Undercarriage and install Pin as shown.
Secure Pin on both ends with Hairpins.
6
Insert Hitch into Drawbar and tighten
hardware. Install Hitch Pin as shown.
19
6
Assembly Instructions
31
17
DO NOT OVERTIGHTEN, HITCH MUST SPIN FREELY.
10
8
20
34
7
5
4
10
9
34
33
